- Page 1 SAC MT9020C / SAC MT9021C SAC MT1220C / SAC MT1224CH SAC MT1225CH EN Portable Air Conditioner Translation of the original manual Copyright © 2019, Fast ČR, a.s. - 1 - 10/2019...
-
Page 2: Portable Air Conditioner
Portable Air Conditioner Important safety instructions READ CAREFULLY AND STORE FOR FUTURE USE. This symbol indicates that not adhering to instructions may result it death or serious injuries. WARNING: To prevent the death or injury of the user or other persons or damage to property, the following instructions must be adhered to. - Page 3 The appliance is designed for use at home, in offices and similar types of areas. ■ Do not use it in very dusty or humid rooms such as laundries or bathrooms, in areas where chemical or explosive substances are stored, in industrial surroundings or outdoors! Do not place the appliance in the vicinity of an open flame or appliances ■...
- Page 4 Disconnect the appliance from the power socket by pulling on the plug, ■ never pulling on the power cord. Otherwise, this could damage the power cord or the socket. In the event that the power cord or power plug are damaged in any way, do ■...
-
Page 5: Fire Hazard
■ This appliance must be located in rooms with an area greater than 13 m ■ This appliance contains approx. 205 g (SAC MT9020C / SAC MT9021C), ■ approx. 235 g (SAC MT1220C) or 260 g (SAC MT1224CH / SAC MT1225CH) of refrigerant gas R290. - Page 6 explosion or fire as a result of the refrigerant igniting following the start up of electrical heaters, cookers or other sources of ignition. The appliance must be stored in such a manner that its mechanical damage ■ is prevented. Persons working with or repairing cooling circuits must have appropriate ■...
- Page 7 Copyright © 2019, Fast ČR, a.s. - 7 - 10/2019...
- Page 8 3 4 5 Copyright © 2019, Fast ČR, a.s. - 8 - 10/2019...
-
Page 9: Installation
Portable Air Conditioner User's manual ■ Prior to using this appliance, please read the user’s manual thoroughly, even in cases, when one has already familiarised themselves with previous use of similar types of appliances. Only use the appliance in the manner described in this user’s manual. Keep this user’s manual in a safe place where it can be easily retrieved for future use. ■... -
Page 10: Operating Modes
Operating modes 1. Cooling mode ■ Repeatedly press button MODE C13 until the cooling indicator C2 is lit. Use buttons –/+ C10 a C11 to set the desired temperature. You can set the temperature in the range from 18 to 32 °C. ■... -
Page 11: Changing Temperature Units
– Auto (automatic speed). Each time the button is pressed, the arrow at the speed bar on the display D1 will switch. ■ For models SAC MT9020C and SAC MT1220C (without the heating function) – the portable air conditioner will start in the fan mode, when the temperature in the room is less than 23 °C, and in the cooling mode when the temperature in the room is higher than 23 °C. -
Page 12: Troubleshooting
Cleaning the outer case ■ To clean the outer case, use a soft wiping cloth dipped in a solution of lukewarm water and neutral detergent. Then wipe the surface dry. ■ When cleaning it, do not spray the portable air conditioner with water or any other liquid, do not pour water on it or submerge it in water or in any other liquid. ■... -
Page 13: Instructions And Information Regarding The Disposal Of Used Packaging Materials
TECHNICAL SPECIFICATIONS SAC MT9020C / SAC MT9021C Power supply..........................................................220–240 V ~ / 50 Hz Cooling power ............................................................9 kBtu / hour Power input ................................................................1,000 W Current consumption ............................................................4.35 A EER cooling factor ................................................................2.6 Dehumidification capacity ..........................................................1 l / hour Capacity of the built-in condensate tank ......................................................0.4 l Refrigerant type and weight ........................................................R290/205 g...
