Page 1: Foreword
LEICA ULTRAVID 8/10 x 32 BR LEICA ULTRAVID 7/8/10 x 42 BR/BL LEICA ULTRAVID 8/10/12 x 50 BR Anleitung Instructions Notice d’utilisation Gebruiksaanwijzing Istruzioni Instrucciones... -
Page 2: Table Of Contents
Accessories ..........................20 Replacements ...........................20 Trouble shooting guide ......................21 Technical data ........................22-23 Leica in the Internet and Leica Academy ..................24 Leica Information Service......................24 Leica Customer Service ......................24 Warning notices Never look directly at the sun or other sources of bright light with your binoculars! -
Page 3: Possible Applications
Possible applications Attaching the protective lens caps The Leica Ultravid binoculars have hermetic- To attach the caps, their rubber ring is pulled ally sealed and nitrogen-filled magnesium over the binoculars from the lens side (image housings. They are therefore suited for rough A). -
Page 4: Adjusting The Eyecups / Use With And Without Glasses
Adjusting the eyecups / Use with and without glasses The eyepiece cups (1) can be easily adjusted If the eyepieces are very dirty, it is recom- by turning them and they lock securely into mended to remove the cups for cleaning the selected positions. -
Page 5: Adjusting The Eyebase
Adjusting the eyebase To set the eyebase, adjust the binoculars at the hinged joint. The left and right fields of view must merge and produce a single circu- lar image. -
Page 6: Focusing / Diopter Adjustment
Focusing / Diopter adjustment With the Leica Ultravid binoculars the central Using one of the rings, then focus the respec- focusing ring (4) is used to set the focus for tive barrel on the desired subject. Continue variously distant objects. -
Page 7: Indications On The Scale
Notes: – The diopter ring rotates freely, i.e. it can accidentally be rotated by more than 360° with respect to the central focusing ring. Depending on the latter's previous setting, the combined system's focusing range can be limited considerably by this. Therefore, take care to turn the diopter ring only as far as necessary for the eyesight adjust- ment. -
Page 8: Care And Maintenance
Care and maintenance Accessories Order No. Your Leica Ultravid binoculars need no spe- Tripod adapter with 1 / 4 " thread ..42220 cial maintenance. Use a soft lens brush or a Floating carrying strap, orange ..42163 blower to remove large particles of dirt, sand, etc. -
Page 9: Trouble Shooting Guide
Trouble shooting guide… Problem Cause Solution – The image seen through a) The binoculars are not a) Hinge the binoculars more the binoculars is not properly adjusted to your or less at their centerline, concentric. personal eyebase. as necessary, until the left and right image merges. -
Page 10: Technical Data
Technical data LEICA ULTRAVID LEICA ULTRAVID LEICA ULTRAVID LEICA ULTRAVID 8x 32BR 10x 32BR 7x 42BR 8x 42BR/BL Magnification Lens diameter 32 mm 32 mm 42 mm 42 mm Exit pupil 4 mm 3.2 mm 6 mm 5.25 mm Twilight factor 17.9... - Page 11 Technical data LEICA ULTRAVID LEICA ULTRAVID LEICA ULTRAVID LEICA ULTRAVID 10x 42BR/BL 8 x50 BR 10 x 50BR 12x 50BR Magnification Lens diameter 42 mm 50 mm 50 mm 50 mm Exit pupil 4.2 mm 6.25 mm 5 mm 4.2 mm Twilight factor 20.5...
-
Page 12: Leica In The Internet And Leica Academy
Leica in the Internet and Leica Academy Leica Customer Service Up to date information about products, novel- For service of your Leica equipment and in ties, special events, Leica Academy seminars, case of neccessary repairs please contact the and the Leica company is available on our...
