Frigidaire FAH08EM1T1 Factory Parts Catalog

Room air conditioner
Hide thumbs

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FAH08EM1T1
FAH08EM1T
MARKET
BTU-COOLING
Frigidaire
8000 BTU
WIRING DIAGRAM - # 309104104
OWNER'S GUIDE - # 309000823
ENERGY GUIDE - # 309369941
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG

ROOM AIR CONDITIONER

SERIES
VOLTS
Intermediate
115
Publication No.
5995385167
030131
-EN/SERVICE /KC
345
©2003 Electrolux Home Products, Inc.
All rights reserved
ROOM AIR CONDITIONER
Model No.
FAH08EM1T

Advertisement

loading

  Related Manuals for Frigidaire FAH08EM1T1

  Summary of Contents for Frigidaire FAH08EM1T1

  • Page 1: Room Air Conditioner

    PRODUCT NO. BASE MODEL NO. FAH08EM1T1 FAH08EM1T MARKET BTU-COOLING Frigidaire 8000 BTU WIRING DIAGRAM - # 309104104 OWNER’S GUIDE - # 309000823 ENERGY GUIDE - # 309369941 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER...
  • Page 2: Cabinet Front And Wrapper

    Publication No. FAH08EM1T1 5995385167 CABINET FRONT AND WRAPPER 02/03...
  • Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAH08EM1T1 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309627504 Cabinet,wrapper 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs 309636101 Screen,safety ,wire mesh ,cabinet rear 5304408740 Panel,plastic mesh ,cabinet rear 309629304 Louver Assy,grey ,Includes 7,8,9...
  • Page 4 Publication No. FAH08EM1T1 5995385167 CONTROLS 02/03...
  • Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAH08EM1T1 CONTROLS PART NO DESCRIPTION 309628502 Control Box 5304418395 Wiring Harness,control box ,14 AWG 309329304 Switch,heat ,0.75" shaft ,3 speed 5304409496 Control,temperature 309329801 Clip,sensor retainer ,3/8 inch...
  • Page 6: Air Handling Parts

    Publication No. FAH08EM1T1 5995385167 AIR HANDLING PARTS 02/03...
  • Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAH08EM1T1 AIR HANDLING PARTS PART NO DESCRIPTION 309629102 Fan Blade 3202975 Screw,10-16AB x 0.72 ,square drive 309628901 Shroud,fan 3015312 Screw,8-18AB x 0.500 309647503 Motor,fan ,3 speed 309627401 Bulkhead...
  • Page 8: Compressor Parts

    Publication No. FAH08EM1T1 5995385167 COMPRESSOR PARTS 02/03...
  • Page 9 POS. NO 11 # 12 # 16 # 17 # 28 # 29 # 30 # # = Fast-moving Parts * = Non-Illustrated Parts FAH08EM1T1 COMPRESSOR PARTS PART NO DESCRIPTION 309616919 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3)
  • Page 10 Publication No. FAH08EM1T1 5995385167 WINDOW MOUNTING PARTS 02/03...
  • Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAH08EM1T1 WINDOW MOUNTING PARTS PART NO DESCRIPTION 309628603 Trim,frame ,side 309628604 Trim,frame ,top & bottom 5304409304 Block,tapered 5303301038 Seal,stuffer ,wrapper 5304409305 Seal,cond. end brkt ,rear panel 5304409306 Seal,condenser ,26.5 x 1.5 x1.5 ,rear panel 5304409307 Seal,condenser ,14 x 1.5 x 1.5 ,rear panel/side...
  • Page 12: Wiring Diagram

    Publication No. FAH08EM1T1 5995385167 WIRING DIAGRAM 02/03...
