Page 1
Linux, Mac OS X, or Microsoft Windows 7/8/10 Java Runtime Environment 1.6 (1.8 or newer recommended) Web Browser: Google Chrome (Other browsers may have limited functionality.) UniFi Controller software v5.11.x (or newer), available at: ui.com/download/unifi IMPORTANT: We strongly recommend using UPS backup and power regulation to prevent equipment damage due to stability issues with local AC power.
Page 2
Factory defaults, waiting for adoption. Successfully adopted by a network and working Steady Blue properly. This indicates that you clicked Locate in the UniFi Location Animation Controller software. The software will also display the location of the device on the map.
We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial-grade, shielded Ethernet cable from Ubiquiti. For more details, visit: ui.com/toughcable Note: Although the cabling can be located outdoors, the UniFi Switch itself should be housed inside a protective enclosure. Hardware Installation...
Page 4
IMPORTANT: Fanless switches must not be stacked. Do not place this USW-16-POE Quick Start Guide UniFi Switch on top of another switch. Do not place anything on top of this UniFi Switch.
“Adopting the UniFi Switch”. After you have installed the software and run the UniFi Installation Wizard, a login screen will appear for the UniFi Controller management interface. Enter the admin name and password that you created and click Sign In.
2. On the Devices screen, locate the UniFi Switch in the list of devices under the Model column. To adopt the UniFi Switch, click Adopt. 3. The System LED on the UniFi Switch will turn blue to confirm that it has been successfully adopted.
USW-16-POE USW-16-POE Quick Start Guide Dimensions 442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72") Weight 2.80 kg (6.17 lb) With Rackmount Brackets 2.89 kg (6.37 lb) Interfaces Networking (16) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports...
WARNING: To reduce the risk of fire or electric shock, do not expose this product to USW-16-POE Quick Start Guide rain or moisture. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm. There may be a remote risk of electric shock from lightning.
2. This device must accept any interference received, including interference that may cause USW-16-POE Quick Start Guide undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
