062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg
PRODUCT MANUAL
DE Produkthandbuch
FR
Manuel de produit
NL Producthandleiding
SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands
T +31 (0)88 70 60 100 • E info@smartmetals.nl • W www.smartmetals.nl
CONTENTS
CONTENTS
Product manual
Important safety information
Mounting regulations
Mounting regulations
Guarantee terms and conditions
Guarantee terms and conditions
Declaration of conformity
Declaration of conformity
Anti-collision explained
Mounting instructions
Mounting instructions
User manual
User manual
Instructions reset controlbox
Specification sheet
Instructions reset controlbox
Specification sheet
Contact details
Wiring diagram
Contact details
original language English
1
2
6
2
7
3
8
4
9
5
11
11
15
14
15
17
18
16
19
20

Advertisement

loading
Need help?

Need help?

Do you have a question about the 062.7205B and is the answer not in the manual?

Questions and answers

Related Manuals for Smart Metals 062.7205B

Summary of Contents for Smart Metals 062.7205B

  • Page 1 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg PRODUCT MANUAL original language English DE Produkthandbuch CONTENTS CONTENTS Manuel de produit Product manual Important safety information NL Producthandleiding Mounting regulations Mounting regulations Guarantee terms and conditions Guarantee terms and conditions...
  • Page 2 IMPORTANT SAFETY INFORMATION - GB Page 2 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Important safety information for both installer and user Installer: Before starting the installation read the safety instructions, the mounting regulations and rest of this product manual carefully.
  • Page 3 WICHTIGE SICHERHEITSHINWEISE - DE Page 3 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Wichtige Sicherheitsinformationen für Installateur und Benutzer Installateur: Lesen Sie vor Beginn der Installation die Sicherheitshinweise, die Montagevorschriften und den Rest dieses Produkthandbuchs sorgfältig durch. Wenn Sie nicht alle Anweisungen lesen, verstehen und nicht befolgen, kann dies zu schweren Verletzungen, Geräteschäden oder zum Erlöschen der Werksgarantie führen! Es liegt in der...
  • Page 4 INFORMATIONS DE SÉCURITÉ IMPORTANTES - FR Page 4 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Informations de sécurité importantes pour l’installateur et l’utilisateur l’Installateur: Avant de commencer l’installation, lisez attentivement les consignes de sécurité, les réglementations de montage et le reste de ce manuel du produit.
  • Page 5 BELANGRIJKE VEILIGHEIDSINFORMATIE - NL Page 5 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Belangrijke veiligheidsinformatie voor zowel installateur als gebruiker Installateur: Lees de veiligheidsinstructies, de montagevoorschriften en de rest van deze producthandleiding zorgvuldig door voordat u met de installatie begint. Als u niet alle instructies leest, volledig begrijpt en niet opvolgt, kan...
  • Page 6 MOUNTING REGULATIONS Page 6 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Mounting regulations Montagevorschriften WARNING WARNUNG A correct mounting is extremely important and this is not the responsibility of Eine korrekte Montage ist von größter Bedeutung, und SmartMetals Mounting SmartMetals Mounting Solutions.
  • Page 7 GUARANTEE TERMS AND CONDITIONS Page 7 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Guarantee terms and conditions Garantiebedingungen 1. SmartMetals Mounting Solutions guarantees that a product that SmartMetals 1. SmartMetals Mounting Solutions garantiert, dass ein Produkt, bei dem...
  • Page 8 DECLARATION OF CONFORMITY Page 8 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg GB Declaration of conformity DE Konformitätserklärung Manufacturer: Hersteller: SmartMetals Mounting Solutions BV SmartMetals Mounting Solutions BV Vlietskade 8016 Vlietskade 8016 4241 WS ARKEL...
  • Page 9 ANTI-COLLISION EXPLAINED Page 9 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Anti-collision Antikollision IMPORTANT WICHTIG For optimised safety this lift system has been fitted with an integrated sensor, Aus Sicherheitsgründen wurde dieses Liftsystem mit einem integrierten Sensor alias called PIEZO™.
  • Page 10 ANTI-COLLISION EXPLAINED Page 10 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Anti-collision Antikollision FUNCTIONALITY FUNKTIONALITÄT PIEZO™ is a built-in electronic sensor in the lift column, which reacts on load changes. PIEZO ™ ist ein in die Liftsäule integrierter elektronischer Sensor, der auf Lastwechsel If the lift system drives into an obstacle the load will change.
  • Page 11 MOUNTING INSTRUCTIONS Page 11 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg 052.7288 MON.0075 MON.0120 6a | M6 | 16x 7a | M8x45 |4x 7d | M6x25 | 4x 7g | 200x3.6 | 2x 6b | M6x20 | 16x...
  • Page 12 MOUNTING INSTRUCTIONS Page 12 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg SmartMetals Mounting Solutions B.V. • Vlietskade 8016 • 4241 WS ARKEL• The Netherlands T +31 (0)88 70 60 100 • E info@smartmetals.nl • W www.smartmetals.nl...
  • Page 13 MOUNTING INSTRUCTIONS Page 13 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg Max. 120 kg (265 lbs) optional     7a    4x optional      7f      4x for VESA > 600x400 see page 14 min. 4mm...
  • Page 14 MOUNTING INSTRUCTIONS FOR VESA > 600x400 Page 14 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg MON.0255 C1 | M8 | 8x C2 | M8 | 8x20x1,5 | 8x C3 | M8x16 | 8x VESA Fixate to...
  • Page 15 USER MANUAL Page 15 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg 6c 1x DOWN 230V - FIRST MOVE THE SCREEN ALL THE WAY DOWN BEFORE MOVING THE PRODUCT AROUND - ALWAYS PUSH AGAINST THE MOBILE STAND, NOT AGAINST THE DISPLAY - PLEASE TAKE EXTRA CARE WHEN MOVING DOWN SLOPES, SEE THE WARNING BELOW MAX 10˚...
  • Page 16 USER MANUAL Page 16 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg DE Achtung! Risiko des Zerquetschens DK Forsigtig! Fare for knusning ES ¡Precaución! Peligro de aplastamiento FI Varoitus! Puristumisvaara FR Attention! Risque d'écrasement GB Caution! Risk of crushing Max.
  • Page 17 INSTRUCTIONS RESET CONTROLBOX Page 17 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg - Check the connection from the remote - Check the connection from to the controlbox the power plug to the controlbox - Überprüfen Sie die Verbindung von der - Überprüfen Sie die Verbindung vom...
  • Page 18 SPECIFICATION SHEET Page 18 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg 062.7205B/W Net weight 41 kg Gross weight 48 kg Max. load 120 kg max. free space Included 052.7288 Expansion set for lift bracket up to max. VESA 800x600 1062 max.
  • Page 19 WIRING DIAGRAM Page 19 062.7205B/W Floor lift on wheels incl. anti-collision, max. 86 inch, 120 kg RJ45 8 PINS CONTROL CABLE Grey Orange White Blue Green Yellow Violet Cable wire color Function RJ45 8 Pin plug no. Blue + Green...
  • Page 20 CONTACT SMARTSELECTOR Find your solution fast and easy with the mobile SmartSelector. Scan the QR code and find your solutions whithin 3 steps with the mobile SmartSelector TRY NOW! SmartMetals Mounting Solutions B.V. Vlietskade 8016 4241 WS ARKEL The Netherlands +31 (0)88 70 60 100 E info@smartmetals.nl W www.smartmetals.nl...
