- Page 1 AIR SERIES User Manual Systems: AIR-62 AIR-62-IP AIR-S12 AIR-S12-IP AIR-82 AIR-82-IP AIR-S15 AIR-S15-IP AIR-122 AIR-122-IP AIR-S18 AIR-S18-IP AIR-152 AIR-152-IP AIR-210 AIR-210-IP AIR Series User Manual rev 1.1...
-
Page 2: Table Of Contents
5.8. Securing speakers using SCA safety cables .....................15 5.9. Passive speakers ................................16 5.9.1. Passive connections ...............................16 6. Standard contents ................................. 17 7. Accessories ....................................17 8. Warranty and assistance ..............................18 8.1. Product warranty ................................18 8.2. Assistance ..................................18 AIR Series User Manual rev 1.1... - Page 3 AIR Series User Manual rev 1.1...
-
Page 4: Panel A. Dimensions
112mm 185mm 147mm 99mm [4.42"] [7.28"] [18.50"] [5.78"] [3.89"] 40mm 70mm [1.57"] [2.75"] 100mm [3.94"] AIR-210 AIR-210 IP Any free point can be used as safety 750mm 110mm [29.53"] [4.33"] 51mm 155mm [2.02"] [6.09"] AIR Series User Manual rev 1.1... - Page 5 AIR-S12 AIR-S15 AIR-S12-IP AIR-S15-IP 2x Safety 2x Safety point point AIR-S18 AIR-S18-IP 2x Safety point AIR Series User Manual rev 1.1...
- Page 6 AIR Series User Manual rev 1.1...
-
Page 7: Safety Instructions
INSTALLING OF THIS UNIT MUST BE PERFORMED ONLY BY QUALIFIED TRAINED PERSONNEL FOLLOWING APPLICABLE SAFETY RULES. DO NOT ALLOW INSTALLATION OF THIS UNIT IF INSTALLATION HARDWARE IS BROKEN, BENT, PARTS ARE MISSING OR IS OTHERWISE DAMAGED. - for powered speakers only AIR Series User Manual rev 1.1... -
Page 8: Regulatory Information
EN 55103-2:2009 /IS:2012 EN 61000-4-2:2009 EN 61000-4-3:2006 /A1:2008 /IS1:2009 /A2:2010 EN 61000-4-4:2012 EN 61000-4-5:2006 EN 61000-4-6:2014 EN 61000-4-11:2004 EN 60065:2002 /A1:2006 /A11:2008 /A2:2010 /A12:2011 Bila Tserkva, 22 January 2019 Alexey Asanov For compliance questions: info@mag-audio.com AIR Series User Manual rev 1.1... -
Page 9: Air Series
3. AIR series 3.1. Introduction 3.2. AIR series speaker models AIR series includes following speaker models: AIR series has been created as the series of installation-dedicated speakers, backed-up with AIR-62-8-BK part number 00-0004538 various mounting hardware options for ease AIR-62-8-WH part number 00-0021201 AIR-62-16-BK part number 00-0005612 and versatility of set-up. -
Page 10: Specifications
IP 54 (AIR-210 IP) Enclosure material Plywood; wear-resistant paint Grill Steel grill, acoustically transparent backing - peak value, calculated according to AES 2 - 2012 - based on transducer power measured according to AES 2 - 2012 AIR Series User Manual rev 1.1... - Page 11 IP 54 (AIR-S18-IP) Enclosure material Plywood; wear-resistant paint Grill Steel grill, acoustically transparent backing - peak value, calculated according to AES 2 - 2012 - based on transducer power measured according to AES 2 - 2012 AIR Series User Manual rev 1.1...
-
Page 12: System Operation
5. System operation 5.1. Rigging AIR series systems are equipped with M10 mounting point adapters for versatile applications. Rigging must be performed only by trained personnel following the established safety rules. MAXIMUM WEIGHT RESTRICTIONS MUST BE FOLLOWED AT ALL TIMES! -
Page 13: Wall Or Ceiling Mounting Using Mounting Adapter
LAIR-82 - for AIR-82 LAIR-122 - for AIR-122 LAIR-152 - for AIR-152 AIR series speakers can be placed with pan and tilt capability using the rotation pattern of the LAIR bracket. 1-2. Mount the bracket onto the threaded pole or other support structure using rotation pattern. -
Page 14: Wall Mounting Of Air-S12, Air-S15 And Air-S18
1. Attach the CL ceiling adapter to the ceiling with provided mounting holes. 2. Release four M10 bolts on sides of cabinet the make space for the adapter’s fittings. 3. Insert the cabinet into the adapter fittings. 4. Tightly secure four M10 bolts. AIR Series User Manual rev 1.1... -
Page 15: Securing Speakers Using Sca Safety Cables
CORRECT CABLE DIRECTLY TO THE SUPPORT STRUCTURE INDEPEDENTLY OF ITS MOUNTING BRACKET. CONNECTING SPEAKER SAFETY CABLE TO ITS MOUNTING BRACKET, OR CONNECTING JUST THE BRACKET TO THE SUPPORT STRUCTURE DOES NOT PROVIDE ENOUGH SAFETY! AIR Series User Manual rev 1.1... -
Page 16: Passive Speakers
5.9.1. Passive connections AIR series system AIR series system Use power amplifier with DSP or power amplifiers with external speaker processor with AIR series systems. MAKE SURE TO USE HIGH PASS FILTER FOR ALL AIR SERIES SYSTEMS TO PREVENT EXCESSIVE... -
Page 17: Standard Contents
6. Standard contents Check the complement of your AIR series system upon receiving the package. Standard contents of AIR series systems: - AIR series passive speaker system - 1 pcs; - AIR series User Manual - 1 pcs; - Polyethylene bag - 1 pcs;... -
Page 18: Warranty And Assistance
8. Warranty and assistance 8.1. Product warranty 8.2. Assistance 1. By this warranty MAG Audio grants that all There are no user-serviceable parts in your equipment manufactured under the MAG Audio device. Refer servicing to qualified technical trademark is free from defects in material, personnel. - Page 19 AIR Series User Manual rev 1.1...
