Freedom9 freeConnect S210 Specifications

freeConnect Mod
SFP Transceiver
Module
freeConnect Mod S210 > SFP transceiver module
SFP/mini-GBIC LX Single-Mode fiber transceiver
The freeConnect Mod S210 is a high performance
1310nm single-mode SFP/mini-GBIC transceiver
supporting full-duplex, gigabit speeds on multi-
mode and single-mode fiber for distances of up to
10km on 9µ single-mode fiber. This hot pluggable
unit has a metal housing to reduce EMI and to
increase durability.
The freeConnect Mod S210, interface fully complies
with the IEEE 802.3z 1000BASE-LX standard. How-
ever, the higher optical quality allow them to reach
10km over single-mode fiber (SMF) versus the 5km
specified in the standard.
Specifications
Standards
Interface
Transmission Range
Data Rate Gigabit
Data Rate Fiber Channel
Optical Receiver Sensitivity
Supply Voltage
Maximum Voltage
Maximum Current
Temperature
Humidity
Dimensions (h x w x d)
Certification
Model Numbers
Model Name
Description
Part Number
Revision 1.1 Specifications are subject to change without notice.
S210
IEEE 802.3z
LC Type Connector
Up to 10km on 9/125µ
1.250Gbps (Bi-directional)
1.062Gbps (Bi-directional)
-20dBm (max.)
3.1 - 3.5V
6.0V
300mA
Operating: 32° to 158° F (0° to 70° C)
Storage: -40° to 185° F (-40° to 85° C)
10% to 85%
0.5 x 1.2 x 2.2 in (12 x 30 x 57 mm)
FDA 21 1040.10 & 1040.11 / Class 1 Laser - EN 60825-1
freeConnect Mod S210
SFP/mini-GBIC LX Single-Mode Fiber Transceiver
STS-L100
Features
• 1310nm single-mode transceiver
• Duplex LC connector
• Metal enclosure reduces EMI
• 3.3V power supply
• Hot pluggable
• Multi-vendor device support
• Up to 10km on 9/125µ single-mode
• Up to 1.25Gbps bi-directional (Gigabit)
• Up to 1.0625Gbps bi-directional (Fiber
Channel)
