- Page 1 XL C11H 1U Rack Mount 17” 1-Port LCD Console USER’S MANUAL P/N: KDW-01HB1 Rev. 1.0...
- Page 2 XL C11H User’s Manual Copyright and Trademark Information Freedom9 makes no warranty or representation, expressed or implied, with respect to the contents or use of this documentation. Freedom9 reserves the right to modify this documentation at any time without obligation to notify any individual or entity of such modifications.
-
Page 3: Table Of Contents
GENERAL INFORMATION ...1 1.1 O ...1 VERVIEW 1.2 S AFETY NSTRUCTIONS 1.3 P ACKAGE ONTENTS 1.4 P RODUCT PECIFICATIONS 1.5 R OUNTING NSTRUCTIONS INSTALLATION...4 2.1 I NSTALLING THE IDEO 2.2 C ONFIGURING THE 2.3 C ONNECTING TO A 2.4 T URNING N THE 2.5 T... -
Page 4: General Information
Overview The freeView XL C11H is an ideal solution for managing one or more servers in a rack. Its ability to connect directly to a server or to a KVM to increase the number of connections allows it to grow along with the number of servers in the rack. -
Page 5: Rack Mounting Instructions
Operation Temperature Storage Temperature Humidity Rack Mounting Instructions To mount the freeView XL C11H in your rack, follow these three steps. 1. Attach the left and right brackets included with the unit to your rack (Figure 1). PS/2 PS/2 1280x1024... - Page 6 XL C11H User’s Manual 2. Slide the unit into the brackets in the rack (Figure 2). Figure 2: Sliding in the Unit 3. Insert the screws into the front and sides of the unit to secure it in place (Figure 3).
-
Page 7: Installation
Installing the Video Card and Video Driver Before connecting the freeView XL C11H to the computer, make sure the computer has a video card installed for the monitor. After you connect the drawer (see Section 2.3 for details), install the video card driver supplied by the manufacturer of the video card. -
Page 8: Testing The Unit
Note: If the unit does not power up when the panel is pulled up, try pushing the soft power on/off button on the left side of the monitor panel to power up the unit. Note: You can adjust the horizontal and vertical position, contrast, and brightness to better suit your video card and your personal preference. -
Page 9: Controls
3 Controls Panel Controls Controls Description Power Powers on or off the device (device must be plugged in in order for the unit to turn on) Auto Automatically adjust the screen to synchronize with display settings Up/Left (-): Move the cursor up in the menu or increase a setting Down/Right (+): Move the cursor down in the menu or decrease a setting Menu... -
Page 10: Touchpad
XL C11H User’s Manual The structure of the main menu is as follows: Touchpad The table below illustrates the different ways the touchpad can be used. Normal Movement: Moving your finger in the middle of the touchpad is the equivalent of moving the mouse normally. - Page 11 Vertical Scrolling: Moving your finger up and down along the right side of the touchpad is the equivalent of using the vertical scroll wheel on your mouse. Horizontal Scrolling: Moving your finger left and right along the bottom of the touchpad will scroll the screen left and right, similar to the vertical scroll wheel except horizontally.
-
Page 12: Troubleshooting
XL C11H User’s Manual 4 Troubleshooting Symptom Keyboard not responding Mouse not responding Possible Cause Action Improper keyboard reset Unplug the keyboard connector from the Console Keyboard Port, then plug it back in. You may have to restart the computer. -
Page 13: Certifications
5 Certifications This equipment has been tested and found to comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received. Including interference that may cause undesired operation.
