freeView XL
1U Rackmount Console
with 17" LCD
freeView XL C11H > 1U Rackmount Console
with 17" LCD
The freeView XL C11H is designed to offer high availability
from your console drawer. With detachable display and
keyboard modules, the freeView XL C11H offers customer
replaceable parts which can reduce downtime and lower
service costs. The 17-inch TFT display offers 1,280 x 1,024
resolution and the industrial grade keyboard features an
integrated touchpad. Connecting the freeView XL C11H to
your server is done via a single cable, which reduces clutter
compared to similar products on the market. Fitted in an
industry standard 1U 19-inch rack mount, the freeView XL
C11H's metal chassis offers solid build quality and longevity.
Connect it to a KVM for a space saving solution in your rack
that offers full controll over your servers.
Specifications
PC Connectors
Cable Type
Keyboard/Mouse
Video
LCD Panel
KVM Cable
Rackmount Kit
Mouse Control
VGA Resolution
Bandwith
Power Adapter
Housing
Operating Temperature
Weight
Dimensions (H x W x D)
Model Numbers
Model Name
Description
Part Number
Revision 2.1 Specifications are subject to change without notice. Copyright 2007 Freedom9 Inc.
C11H
1
1-to-3 (High Density)
PS/2
VGA
17" TFT
1 x 6 ft (1.8 m)
1
Touchpad
1280x1024
200 Mhz
12V, 4.16A
Metal
32°F - 122°F (0°C - 50°C)
29.5 lb (13.4 kg)
1.7 x 17.4 x 22.4 in (43 x 443 x 57 mm)
freeView XL C11H
1U Rackmount Console with 17" LCD
KDW-01HB1
Features:
• Modular design
• 1,280 x 1,024 resolution TFT display
• Single cable connection to server
• Supports standard PS/2 connectors
• 1U rackmount design
• KVM daisy chain capable
• Industrial grade keyboard
• Supplied with sliding rackmount rails
• Supports operation in a braod range of
environmental temperatures
www.freedom9.com
1-888-998-9189
