- Page 1 For Model No. User's manual MPWIN810CL...
- Page 2 1:Buttons 1. Power button: Press briefly to sleep/wake. Press and hold to turn on/off. 2. Volume + 3. Volume – 4. USB connection 5. Earphone connection 6. TF card slot...
- Page 3 Cautions ● Do not press the surface of touch screen using sharp object. Touch screen can be stabbed or pressed, may not work or cause malfunction. ● Be careful of using, touch screen and display can be damaged if it undergo external shocks or pressure.
- Page 4 Turn on PC 1. Press Power button to turn on PC Turn off PC 1. Touch Power icon on the bottom left corner of the screen 2. Touch “Shut down” to turn off PC...
-
Page 5: Understanding The Screen
Understanding the Screen Desktop mode Tablet mode How to change Desktop mode to Tablet mode 1. Slide to the left from the right side of screen. - Page 6 2. Touch “Tablet mode” to change between Desktop and Tablet mode. Charm menu on Tablet mode 1. Slide to the left from the right side of screen.
- Page 7 2. “Tablet mode”, “Rotation lock”, “Setting”, “Wi-Fi” and other functions comes up. All Applications menu on Tablet mode 1. Touch Application icon on the bottom left corner of screen.
-
Page 8: Micro Sd Card Slot
2. All applications comes up on the screen. Micro SD card slot Micro SD is the removable drive anc can move various data easily and expand capacity of PC Using Card 1. Insert the Micro SD card into Micro SD card slot 2. -
Page 9: Setting Volume
Setting Volume Volume setting is available by button and the volume icon on the bottom right corner of screen. Setting Volume by button Press the volume key on top of PC and set volume Setting Volume by volume icon Touch the volume icon on the bottom right corner of screen. Setting LCD brightness ※... -
Page 10: Wireless Network (Wi-Fi)
2. Set the screen brightness by touching Brightness icon. Wireless Network (Wi-Fi) Can simply connect to wireless network if there are Wi-Fi nearby. Connecting wireless LAN 1. Touch Wi-Fi icon on the bottom right corner of screen. - Page 11 2. All available Wi-Fi list will be shown up. And touch desired Wi-Fi on the list. 3. Touch Connect. ※ Network security key need to be checked by network manager...
- Page 12 Battery If use PC with battery, not adopter, please refer to this description Charge the battery Please plug charger in PC charger port Check battery remains Can check battery remains 1. Check on the taskbar After separate charger port from PC, Touch battery icon on the bottom right corner of screen.
- Page 13 KEYBOARD USER MANUAL Packing Contents: 1. Cordless keyboard 2. User manual 3. power cable 1. Bluetooth Keyboard General Features 1) Built-in Nuoda Bluetooth module 3.0 2) Suitable for 8inch tablet pc 3.) MICRO interface, easy to charge 4.) Built-in rechargeable lithium battery 5.) Light weight, quiet keystrokes, water-proof, dust-proof 6.) Energy saving keyboard in sleep mode Bluetooth Keyboard Specification and Pairing Instruction:...
- Page 14 11) Lithium battery capacity：110mA 12) Sustainable working time：44 hours 13) Lithium battery life：3years 14) Lithium battery dimension：3.0*25*25mm 15) Key strength：80±10g 16) Key Life：5 million strokes 17) Working temperature：-10 - +55 ℃ 3. Bluetooth Keyboard Pairing Step 1: Turn on the power toggle switch. The state indicator light will be on for 5 seconds, and then the light will go off.
- Page 15 7. Energy Saving Sleep mode The keyboard will kick into sleep mode when it is inactive for 15 minutes and the keyboard [power] indicator or light will go off. To wake up from sleep mode, just press any key and wait 3seconds, the keyboard will come back on.
- Page 16 15. Special Note The keyboard on charging state instructions: Please use original power line to charge if there is low battery when you are using it. You also can use other data line with MICR interface, but it cannot be used immediately unless you take data line out.
- Page 17 Attention: If there are some bluetooth keyboards cannot be used under the Windows 10 system. It can be resolved through the following ways: 1. Power On the bluetooth keyboardàOpen BluetoothàSearch the Bluetooth KeyboardàThe bluetooth keyboard matched 2. After Connected the Bluetooth keyboard, Click Printers&scannersàClick “Device and Printers”...
