Duratuf KIWI MK4B Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Quality – Built In
ASSEMBLY INSTRUCTIONS
MK4B
BASE SIZE 4210mm x 3380mm

Advertisement

loading
Need help?

Need help?

Do you have a question about the MK4B and is the answer not in the manual?

Questions and answers

Related Manuals for Duratuf KIWI MK4B

Summary of Contents for Duratuf KIWI MK4B

  • Page 1 Quality – Built In ASSEMBLY INSTRUCTIONS MK4B BASE SIZE 4210mm x 3380mm...
  • Page 2 ASSEMBLY INSTRUCTIONS • Tools Required: Drill • Drill Bit 3.5mm • Drill Bit 6mm (for clear roof panel only) • Hex Drive 5/16 • Riveter (free Duratuf riveter supplied in kit) • Hammer • Nail Punch • Tape Measure • Ladder or Saw stool •...
  • Page 3 KIWI MK4B PARTS LIST 2.280m Gable End Wall Sheets 1.890m Wall Sheets 1.890m MK4 1/2 Wall Sheets Door - Standard Security Instruction Booklet 0.260m Jack Studs - 140 x 45mm 0.200m Jack Studs - 60 x 45mm Hardware Pack Touch-up Paint & Brush...
  • Page 5 MK4B TIMBER FRAME JACK STUDS Note: For sheds with the Raised Floor Modification option the studs will be 1.780m long to allow the Wall Sheets to pro- trude 20mm below the Bottom Plate. Refer to Raised Floor Modification section (Page 15).
  • Page 6 MK4B TIMBER FRAME Step 4: Stand up Back Wall frame and one End frame and nail together, using two 75mm nails per join, top and bottom. Stand remaining Frames up and nail together. Nail in remaining .764m Nogs in End Walls.
  • Page 7 MK4B WALL CLADDING TO AVIOD CORROSION: • Where at all possible try not to trap metal filings between two sheets. Remove all metal filings before riveting. • Carbon in pencils reacts with the Zinc/Aluminium coating on steel. Use ink to mark steel.
  • Page 8 MK4B WALL CLADDING Step 1: Front Wall: Start at the left hand side. Position the Wall Sheet with the LIP on the left hand side. Ensuring the LIP is flush with side of the Stud and the top of the Top Plate, tack in place.
  • Page 9 MK4B LOUVRE WINDOW (Optional) 588mm Step 1: Lay out the two window studs (883mm) and Step 2: On the inside of the shed, position studs Nog (634mm) on a flat surface. Position and Nog centrally on window opening. Nog and nail in place using 2x 75mm nails Make sure the studs are parallel and nail at each end.
  • Page 10 Window Frame to hold glass in place. Pre-drilling Glazing Beads is recommended. MK4B DOOR JAMB & CORNER FLASHINGS Step 1: Fit Door Jamb Flashing (A104) in between Top and Bottom Plates and hard against Stud. Attach...
  • Page 11 MK4B DOORS Step 1: Position Right-hand Door Track (107) on the front wall with the top of the track 7mm below the top of the timber frame. The left- hand end should be 20mm to the right of centre of shed. (Ie Door...
  • Page 12 MK4B ROOF Note: Condensation can form on the under side of shed roof. If building paper is required, fit now. Building paper will need to be sup- ported by netting or roofing twine. Step 1: Position first Roof Sheet centrally over Ridge Beam on the right hand end of shed with the LIP on the left hand side.
  • Page 13 MK4B CLEAR ROOF PANEL (Optional) Step 1: Leave a gap where the Clear Panel is to be fitted. Position the next Roof Sheet. Ensure it overlaps correctly, then rivet togeth- er, one rivet in the centre and one approximately 600 mm down from the centre on both sides. Fit remaining Roof Sheets, overlapping and riveting as you go.
  • Page 14 MK4B BARGE & SPOUTING Step 1: Attach left hand and right hand barges (C102 & Step 2: Centralise Barge Flashing on gable end D102) together with three rivets at top overlap. Posi- and rivet in place, one rivet into every tion Barge Flashings on gable ends.
  • Page 15 MK4B HASP & STAPLE Using seven rivets, attach hasp to Left Hand Door and the staple to the Right Hand Door as shown. RAISED FLOOR MODIFICATION For sheds being placed on a purpose built floor, (concrete, cobbles, ply etc.), the Wall Sheets will pro- trude 20mm below the Base Plate.

  • Page 16: Maintenance

    DURATUF PREMIUM SHED WARRANTY GUARANTEE TO CUSTOMER Congratulations on purchasing a Duratuf Storage Shed. With proper care and attention, this product will last many years. For your benefit PLEASE READ THE FOLLOWING INFORMATION CAREFULLY. WARRANTY ON METAL CLADDING Riverlea Group Ltd guarantee that the metal roofing and wall cladding on Kiwi and Fortress Garden Sheds may be used in moderate and inland corrosion zones or areas where the first year mild steel corrosion rate is less than 200g/m2, and that in these conditions, they will not perforate due to corrosion within 30 years of date of manufacture.
