LED Backlit Mirror
Sizes: 48" W x 36"H (horizontal or vertical)
60" W x 35"H (horizontal or vertical)
70" W x 38"H (horizontal or vertical)
Model: Catella M09AT, Catela-Plus M10AT, Royal M12AT,
Edison M13AT, Swan M14AT, Egret M16AT
For easy installation of your Dyconn Mirror please do the following:
Thoroughly read all instructions before installing the enclosed product.
Read and take note of all safety, care, and maintenance information.
PLEASE KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE FOR PRODUCT
OPERATION AND MAINTENANCE.
Product Features:
Frameless backlit Mirror
Extra thick frosted LED light
Can be hung vertical or horiztonal
Touch switch on & o
Anti-fog pad
www.dyconnfaucet.com
E491008
Advertisement
Related Manuals for Dyconn Catella M09AT
Summary of Contents for Dyconn Catella M09AT
- Page 1 Model: Catella M09AT, Catela-Plus M10AT, Royal M12AT, Edison M13AT, Swan M14AT, Egret M16AT For easy installation of your Dyconn Mirror please do the following: Thoroughly read all instructions before installing the enclosed product. Read and take note of all safety, care, and maintenance information.
- Page 3 Warning: Please read!! electrician. 2. During installation please make sure the circuit breaker or the with a live line on. 3. It is recommended to have at least two people available to install the mirror. Remember to wear proper protective gear during instal- lation.
- Page 4 Product Description & Information Product Features: Package Content: • Frameless backlit Mirror • LED backlit Mirror • Extra thick frosted LED light • Screws • Can be hung vertical or horizontal • Studs • Touch switch on & o • Touch switch dim function •...
- Page 5 Warning: Al installation and maintenance. Do not switch on the electrical supply at the mains until the end of the installation. Tools you will need: Phillips Screwdriver Electronic Driller E491008...
-
Page 6: Installation Steps
Installation Steps First, decide whether you want to hang your mirror vertically or horizontally. It is advisable to have one more person help you install the mirror. Horizontal Mounting 1.Have one person hold the side of the mirror while another person holds the back frame. -
Page 7: Vertical Mounting
Vertical Mounting 1.Have one person hold the side of the mirror while another person holds the back frame. Pull the bottom of the glass out from the back frame and lift up to separate these two parts. Vertical Mount Horizontal Mount Lock catch Handles (Only when... - Page 8 LED Mirror Power Source FAQ Internal Power Flow Diagram Scenario 1 Input Output (Direct Wired) 110VAC -12VDC Anti-fog 110VAC This is the most common way to driver Power Source: connect the mirror. The LED light Constant 110AC Output & anti fog pad are both power controlled by the built-in touch Dimmer Switch...
-
Page 9: Model Chart
Introducing Tri-Color Mirrors and Additional Features In the near future, Dyconn Faucet will be upgrading our mirror products to include tri-color options and additional features. Full feature list is listed below: • Tri-color temperature options: 3000K, 4000K and 6400K • Dimming Capability (except 72 Inch models) •... - Page 10 3. Why is my mirror making humming/buzzing noise? Answer: Hearing a low buzzing/humming noise is normal as the touch sensor defective. 1) The relay for the anti-fog pad 2) the touch sensor or 3) Power supply. Please contact Dyconn Faucet customer service at 855-239-2666 or info@dyconnfaucet.com.
- Page 11 Wall Switch Bypass Instructions Numbers will correspond to Use the following steps to wire mirror to an electrical wall switch following tags attached to the wires and bypass the touch sensor: 1. Disconnect all connections from the touch sensor (#1-3). 2.
-
Page 12: Manufacturer Limited Warranty
Dyconn Faucet as defective will be repaired or replaced (with a product of equal value) at the company's discretion. If Dyconn Faucet is not able to replace or repair the product, Dyconn Faucet may elect to refund the original purchase price to the original purchaser in exchange for the product's return.
