Printed: 23.05.17 File: BA_P2L-002_V2.1_EN EU Declaration of Conformity InSystems Automation GmbH, Rudower Chaussee 29, 12489 Berlin for the devices: Pick-to-Light Sensor P2L-Sensor D002 Digital Pick-to-Light Sensor P2L-Sensor D002 Digital ESD Pick-to-Light Sensor P2L-Sensor C002 CAN Bus Pick-to-Light Sensor P2L-Sensor C002 CAN Bus ESD We herewith confirm the conformity of the above-mentioned products with European laws and standards: EU Guideline 2004/108/EG –... -
Page 3: Preliminary Remarks
– Prior to installation and use of the sensors, every user must have read these instructions. – The sensors should only be installed and adjusted (teach-in procedure) from qualified staff members. – InSystems Automation GmbH will not be responsible for damages due to improper use and settings of the sensors. -
Page 4: Table Of Contents
Improper Use Improper Use Addition, Changes and Modifications Product Description P2L Sensor Available Models General remarks Operation Launch P2L D002 Digital P2L C002 CAN Bus Available on Request Settings 6.4.1 LEDs Brightness 6.4.2 Pick time P2L Sensor Assembly and Coverage Area... - Page 5 Start and Process Error Teach-in of P2L Sensors P2L Sensor Control 11.1 Operation Modes 11.2 Consequences by Errors during Picking Operations 11.3 Signal Processing P2L D002 Digital 11.4 Signal Processing P2L C002 CAN Bus 11.4.1 CAN – Data Telegram 11.4.2 Message Protocol 11.4.3 Communication with the sensor and functions 11.4.4...
- Page 6 Picture 32: Mobile P2L station with open fronted container (LF 211 ZW PP) by SSI Schäfer Picture 33: Measurements P2L D002 Picture 34: Overview P2L digital Picture 35: Measurements P2L CAN bus Picture 36: Overview P2L CAN bus Copyright © 2016, InSystems Automation GmbH InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10...
-
Page 7: Product Overview
You can read more details about the sensors in the relevant chapter. Service InSystems Automation GmbH allows a free sensor test: We provide test sensors for a functional test to your conditions. Please contact our customer service (See chapter 15.2) 3.1 Acronyms / Definitions... -
Page 8: Information To This Guide
This symbol identifies an operating step. An operating instruction contains one or more consecutive operating steps. This symbol underlines useful tips and extra information. This symbol identifies the end of an operating instruction. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 8-37 12489 Berlin, Germany... -
Page 9: Safety Remarks
4.5 Improper Use Another use as described in chapter Intended Use is considered improper. During improper use, unpredictable risks might occur. For damages after improper use, InSystems Automation GmbH declines any liability. Examples for improper use are: – Untypical use –... -
Page 10: Product Description P2L Sensor
LED. The green LED lights up on the container, from where the piece should have been taken out. Picture 1: Supply shelf InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 10-37 12489 Berlin, Germany... -
Page 11: Available Models
P2L C002 ESD Technical Data see chapter 0 5.2 General remarks Der P2L-Sensor is designed to fulfill the requirements of the protection class IP53. Picture 2: Protection class IP53 InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 11-37... - Page 12 – Do not open the casing of a P2L sensor. The device contains high-precision electronic components, which might be damaged. For damages resulting from non-compliance with the present instructions, we do not grant any warranty. InSystems Automation GmbH Rudower Chaussee 29 Tel.:...
-
Page 13: Operation Launch
Printed: 23.05.17 File: BA_P2L-002_V2.1_EN 6 Operation Launch 6.1 P2L D002 Digital With following steps the P2L D002 will be installed and launched: Assembly the sensor in the racking levels where the material is stored see chapter 7. Connect the sensors to the PLC see chapter 8.1. -
Page 14: P2L Sensor Assembly And Coverage Area
7.3 Assembly and Sensor Alignment A downward-facing alignment is recommended. The sensor can also be aligned upward or side-facing, but it might be become susceptible to failures because of dirt (case-by-case assessment). InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... - Page 15 Possible, but more susceptible for contamination: by dirt deposit on the sensor by ambient light Picture 6: Sensor field facing sideways InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 15-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de...
-
Page 16: Sensor Position On The Box
The sensor range is too far from the box and can supervise only a part of it. The procedure might not be recognized or the next box might be supervised instead. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... -
Page 17: Assembly Of Esd Sensors
Demo of a C002 P2L sensor, which is mounted over Bosch grip plates with an angled bracket. The sensor is fastened to the bracket with two M4 screws. Picture 10: Assembly with customer specific bracket InSystems Automation GmbH Rudower Chaussee 29 Tel.:... -
Page 18: Connection
23.05.17 File: BA_P2L-002_V2.1_EN 8 Connection 8.1 P2L D002 Digital Each digital P2L sensor is connected by a separate cable with the PLC. P2L sensors are supplied with power by the PLC. Picture 11: Pick-to-light system scheme with P2L digital 1. Digital P2L-Sensors 2. -
Page 19: Dip Switch For Brightness And Picking Time
Status 6500 ms Status 8000 ms The other DIP switches are not used. Upon delivery of the P2L sensors all DIP switches are set to OFF. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 19-37 12489 Berlin, Germany... -
Page 20: P2L C002 Can Bus
1. P2L sensors with CAN bus in a row 2. PLC with CAN Bus 3. MFR for - Control of assembly sequence - Control of the containers, - Visualizing etc. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 20-37 12489 Berlin, Germany... -
Page 21: Connector Plug
On the last P2L sensor in a row, the switchgear of the DIP switch must be turned on, so that the termination resistance is leaded to the bus. Picture 18: Bottom of P2L C002 with DIP switch Picture 17: Schema of DIP switch InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... -
Page 22: Use In Plc Systems
Picture 20: LED signals by error during startup sequence – Check the wiring and turn the system on. Measures for Error Message – Watch if all LEDs light one second after start InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 22-37... -
Page 23: Teach-In Of P2L Sensors
Reach in the box, when both lighting LEDs confirm a successful teach-in. Pay attention to the position and the distance of the sensors see chapter 7.4 Sensor Position on the Box InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... - Page 24 After a successful teach-in at system start, the operations can start. All the following operations will be executed automatically, so that the operator can work without interruptions, even when the containers get refilled. InSystems Automation GmbH Rudower Chaussee 29 Tel.:...
-
Page 25: P2L Sensor Control
(set by the operator, must be programmed in PLC ) Picture 24: Example for picking error 4. End of the assembly procedure InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... -
Page 26: Consequences By Errors During Picking Operations
– an outfeed of the unit with the purpose of extra work or quality control The measures should be chosen and programmed by the customer. 11.3 Signal Processing P2L D002 Digital For LED signals see 11.1 Picture 27: PLC signals by correct picking operation... -
Page 27: Signal Processing P2L C002 Can Bus
Picture 29: CAN data telegram 11.4.2 Message Protocol Sensor transmission rate is 125 kBit/s. Data block uses only one Byte of data, that means 8 of 64 bits is used. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... -
Page 28: Communication With The Sensor And Functions
When a picking message is delivered, the corresponding command will be executed and the green LED lights When no picking time command is sent, picking time is set to 0 ms. When no brightness command is sent, LED brightness is set to 100%. InSystems Automation GmbH Rudower Chaussee 29 Tel.:... -
Page 29: Sensor Answers
Signal answer of the sensor while it’s reachable Brightness LEDs light modus 1 Picking time LEDs light modus 2 Picture 30: LED while setting brightness Picture 31: LED while setting picking time InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 29-37... -
Page 30: Led Error Codes And Troubleshooting
– Solution: Turn the power on and off. If the LED is still blinking, the sensor may be broken. In this case, please contact the customer service. InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10... -
Page 31: Special Issues
D002 with DIP switch see chapter 8.1.2 procedure. C002 with CAN bus see chapter 11.4.3 InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 31-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de... -
Page 32: P2L Mobile Supply Unit With Pick-To-Light Sensor
Operating voltage 24 V (PLC) Power draw 0,5 W Coiled cable Extended≈ 1200 mm Closed ≈ 300 mm Stecker Harting InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 32-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de Email:... -
Page 33: Service
16 Maintenance The delivered P2L sensor is maintenance-free. If a device does not work properly, do not open the casing and let it repair only by the manufacturer. Please contact InSystems Automation GmbH customer service and plan appropriate steps. 16.1 Cleaning The sensor and the LEDs on the casing must be cleaned if necessary, depending on the amount of dirt and environmental conditions. -
Page 34: Technical Data P2L Sensors
2 x M4 screws Environmental Conditions Operating Temperature Range -10° C to +50 °C Sunlight / Ambient Light No influence in recommended position, other positions require case-by-case assesment InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 34-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de... -
Page 35: Measurements And Elements Of P2L Sensors
23.05.17 Printed: 23.05.17 File: BA_P2L-002_V2.1_EN 18.1 Measurements and Elements of P2L sensors 18.1.1 P2L D002 Digital Measurements apply to standard and ESD model. Picture 33: Measurements P2L D002 Picture 34: Overview P2L digital InSystems Automation GmbH Rudower Chaussee 29 Tel.:... -
Page 36: P2L D002 Can Bus
23.05.17 Printed: 23.05.17 File: BA_P2L-002_V2.1_EN 18.1.2 P2L D002 CAN Bus Picture 35: Measurements P2L CAN bus Picture 36: Overview P2L CAN bus InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 36-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de... - Page 37 Documentation Created: 23.05.17 Printed: 23.05.17 File: BA_P2L-002_V2.1_EN InSystems Automation GmbH Rudower Chaussee 29 Tel.: +49-30-639 225 10 37-37 12489 Berlin, Germany Fax: +49-30-639 225 16 www.insystems.de Email: info@insystems.de...
