Vizion PMA Autopilot C180, C182-C182D, C185
Make
Textron Aviation, Inc. 5A6
Textron Aviation, Inc. 3A13 182, 182A, 182B, 182C, 182D
Textron Aviation, Inc. 3A24 185, 185A, 185B, 185C, 185D, 185E, A185E, A185F
NOTE:
The installation of the Vizion autopilot is NOT compatible with the
Robertson STOL system. If the subject aircraft has a Robertson STOL
system installed, please contact TruTrak Flight Systems and do not
proceed with the installation of the Vizion autopilot.
RESTRICTION ON USE, DUPLICATION, OR DISCLOSURE OF
THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF
TRUTRAK FLIGHT SYSTEMS, INC. AND MAY NOT BE REPRODUCED, COPIED,
DISCLOSED OR UTILIZED IN ANY WAY, IN WHOLE OR IN PART, WITHOUT THE
PRIOR WRITTEN CONSENT OF TRUTRAK FLIGHT SYSTEMS, INC.
Prepared by
Prepared by
Checked by
Approved by
Rev: B
TruTrak Doc: 255
Appendix E
Installation
TCDS Models
180, 180A, 180B, 180C, 180D, 180E, 180F, 180G,
180H, 180J, 180K
PROPRIETARY INFORMATION
Prepared by
TruTrak Flight Systems, Inc.
Function/Title
Engineering
President
GM
President
1
Vizion Install Appendix E C180, C182-
C182D, C185
Name
Zach Williamson
Andrew Barker
Moss Foster
Andrew Barker
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TruTrak Vizion PMA C180
Summary of Contents for TruTrak Vizion PMA C180
- Page 1 The installation of the Vizion autopilot is NOT compatible with the Robertson STOL system. If the subject aircraft has a Robertson STOL system installed, please contact TruTrak Flight Systems and do not proceed with the installation of the Vizion autopilot.
-
Page 2: Table Of Contents
Pitch Servo Materials List ........................19 3.4. Cessna C180, C182-C182D, C185 Pitch Servo Mounting Instructions ......20 3.5. Cessna C180, C182-C182D, C185 Vizion Roll IPC ..............27 3.6. Cessna C180, C182-C182D, C185 Vizion Pitch IPC ..............28 Cessna C180, C182-C182D, C185 Autopilot Settings ..........29 4.1. Lateral Autopilot Settings ........................29 4.2. Vertical Autopilot Settings ........................30 Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 3: Document Revision History
1. Document Revision History Rev Description Pages Date Initial Release 8-16-18 Added BK part numbers, made changes for PV.40 5-15-19 software Added note on front page regarding Robertson 8-9-19 STOL incompatibility. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 4: Cessna C180, C182-C182D, C185 Controller / Wiring Harness Installation
Vizion Flat Pack Controller 8000-175 or 8000-185 100 MS3367-1-0 Cable Tie Connector D-sub Female 9 Pin Crimp 2100-044 Female Socket Crimp Connector D-sub 2100-045 Connector Backshell 9 Pin 2100-010 Vizion Emergency Level Button Kit 8100-113 Vizion Limitations Placard 8300-092 5A AP circuit breaker (not supplied) Control Wheel Steering Switch (not supplied, but MUST be RED in color) AP Master Switch (not supplied) 6-32 X 3/8” Instrument mounting screw (not supplied) N/A Various terminals and pins for connection of power and GPS N/A 1/8”-27 NPT male fittings and tees for connecting the A/P pitot and static to the aircraft systems Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 5: Wiring Harness / Controller Mounting Instructions
2.2. Ensure that mounting location does not require autopilot servo lines to run near com antenna coax. 2.3. Ensure that there is sufficient space near the autopilot controller to install the Vizion Limitations Placard (Trutrak P/N 8300-092) 3. Remove the instrument panel and panel overlays as necessary. 4. Remove the seats. 5. Remove the left A-pillar and kick panel trim. 6. Remove carpeting. 7. Wiring harness routing. 7.1. Route the pitch (white) and roll (black) servo harnesses from the controller to the left side of the panel. 7.2. Route the roll (black) servo harness up the left A pillar and out the leading edge of the left wing as shown in Figure 2-1, Figure 2-2, and Figure 2-3. Extend the excess harness out the inspection hole just forward of the Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... - Page 6 Figure 2-1 Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 7 Figure 2-2 Figure 2-3 7.3. Route the pitch (white) servo harness down the left kick panel and under the floor. Continue running the harness to the pitch servo mounting location as shown in Figure 2-4 and Figure 2-5. Use self-adhesive cable tie anchors to Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 8 Figure 2-4 Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 9 Figure 2-5 8. Select appropriate mounting locations for the AP Master, AP Circuit Breaker, Emergency Level and control wheel steering switches. Connect these items per the Vizion wiring diagram in the Vizion PMA Installation Guide (TruTrak Doc. 166). 8.1. All items in this step are required to be installed. The AP Master Switch, AP Circuit Breaker, and Control Wheel Steering switches must be labeled. The Control Wheel Steering Switch must be RED.
- Page 10 Potential location of Limitations Placard 13. Reinstall the instrument panel and panel overlays. 14. Once autopilot settings are confirmed, perform autopilot system test per the Vizion PMA Installation Guide (TruTrak Doc. 166). Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
-
Page 11: Cessna C180, C182-C182D, C185 Servo Installation
2500-122 MS21051-08 8-32 Anchor Nut 2500-094 AN3-17A 2500-081 MS35333-39 Internal Lock Washer 2500-076 AN960-10 2500-075 AN3-3A 2500-069 8-32 X 5/8 Screw AN526C832R10 2500-068 AN3-7A 2500-055 AN345-10 2500-047 AN970-3 Washer 2500-042 MS20364-1032 1450-128 18X Lower Roll Bracket 1450-127 18X Upper Roll Bracket 1 1420-216 Servo Bolt Pattern Plate Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 12: Cessna C180, C182-C182D, C185 Roll Servo Mounting Instructions
3.2. Cessna C180, C182-C182D, C185 Roll Servo Mounting Instructions NOTE: Apply torque seal to all bolts after final torquing is achieved. 1. The roll servo will be mounted in the left wing just forward of the inboard end of the aileron. 1.1. Begin by removing the inspection cover on the lower wing skin located forward of the inboard end of the aileron. 1.2. Figure 3-1shows the roll servo mounting location from below the left wing. Figure 3-1 2. The Cessna 18X Upper Roll Bracket (P/N 1450-127) will be mounted to the flange of the rear wing spar using 3 ea. AN526C-832R8 screws. 2.1. Locate the inboard screw hole as shown in Figure 3-2 on the upper wing skin. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... - Page 13 Figure 3-2 2.2. Drill the inboard hole only at this time with a #19 drill. 2.3. Invert the Cessna 18X Upper Roll Bracket (P/N 1450-127) on the upper wing skin and cleco the inner hole on the bracket to the hole drilled in the previous step. Rotate the bracket so that the middle and outer bracket mounting holes are aligned with the row of rivets in the rear wing spar as shown in Figure 3-3. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 14 Figure 3-3 2.4. Match drill 2 holes as shown in Figure 3-3. 2.5. Remove the Cessna 18X Upper Roll Bracket (P/N 1450-127) from the wing and deburr the mounting holes that were drilled. 2.6. Temporarily attach the Cessna 18X Upper Roll Bracket (P/N 1450-127) to the Servo Bolt Pattern Plate (P/N 1420-216) using 2 ea. AN3-3A as shown in Figure 3-4. Figure 3-4 2.7. Place the assembly shown in Figure 3-4 in the wing and cleco in place as shown in Figure 3-5. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 15 Figure 3-5 2.8. Temporarily attach the Cessna 18X Lower Roll Bracket (1450-128) to the Servo Bolt Pattern Plate (P/N 1420-216) using 2 ea. AN3-3A as shown in Figure 3-6. Figure 3-6 Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 16 (P/N 8100-064 for 12 volt or P/N 8100-065 for 24 volt) using the provided 8-32 x 3/8” flat head screws. Use blue threadlocker (Loctite 242 or equivalent) and torque the screws to 18-20 in-lb. 2.12. Allow a sufficient service loop and trim the roll servo wiring harness to length. 2.13. Terminate the roll servo wiring harness per the Vizion wiring diagram in the Vizion PMA Installation Guide (TruTrak Doc. 166) and install the 9 Pin Connector Backshell (2100-010). 2.14. Place the Cessna 18X Upper Roll Bracket (P/N 1450-127) and Cessna 18X Lower Roll Bracket (1450-128) in the wing in approximately the final mounting position but do not secure them to the wing.
- Page 17 2.29. Ensure that the aileron cable is not wrapped around the 41” push rod (2510- 062) then partially thread the MM3-300 rod end attached to the aileron bellcrank in the outboard end of the push rod. 2.30. Have an assistant hold the yoke in the full right position and rotate the servo arm against the outboard stop on the roll servo bracket. 2.31. Thread the MM-3-300 rod end bearing into the servo end of the pushrod until the pushrod is the correct length to align with the drive point on the servo arm. 2.32. Verify that the control cable is not twisted around the pushrod. 2.33. Attach the pushrod assembly to the Cessna 172 Roll Servo Arm (P/N 7200- 091) as shown in Figure 3-8 and torque to 20-25 in-lb. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 18 2.36. Ensure that aircraft stops are contacted prior to servo stops. Adjust length of pushrod as needed until servo stops are not contacted when controls are moved to both ends of travel. 2.37. Verify that the servo and pushrod motion are unobstructed throughout the full control travel. Once wiring harness is installed, ensure that the wiring harness is properly secured to prevent interference. 2.38. Apply torque seal to all bolts after final torqueing is achieved. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
-
Page 19: Pitch Servo Materials List
4 2500-081 MS35333-39 Internal Lock Washer 2 2500-076 AN960-10 4 2500-075 AN3-3A 9 2500-069 8-32 X 5/8 Screw AN526C832R10 1 2500-068 AN3-7A 1 2500-055 AN345-10 1 2500-054 AN315-4 1 2500-047 AN970-3 Washer 1 1450-129 Early 18X Pitch Bracket Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 20: Cessna C180, C182-C182D, C185 Pitch Servo Mounting Instructions
3.4. Cessna C180, C182-C182D, C185 Pitch Servo Mounting Instructions 1. The pitch servo will be mounted in the aft fuselage as shown in Figure 3-9. Figure 3-9 2. Remove the baggage compartment bulkhead to access the rear fuselage. 3. Remove the rear inspection cover on the bottom of the fuselage. 4. Rotate the Early 18X Pitch Bracket (1450-129) so that the long flange of the bracket is toward the left of the aircraft. Place the forward edge of the Early 18X Pitch Bracket (1450-129) 4.25” aft of station 172.00” and 2.25” left of the centerline on the lower skin inside the aft fuselage. The elevator cables provide a good reference of the centerline of the aircraft. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... - Page 21 Early 18X Pitch Bracket (1450-129). After drilling each hole secure the bracket to the fuselage using a cleco. 6. Remove the bracket from the aircraft and deburr the mounting holes. 7. Attach the 2.75” PMA Servo Arm Assembly (P/N 7200-106) to the 60 inch/lb PMA servo (P/N 8100-064 for 12 volt or P/N 8100-065 for 24 volt) using the provided 8-32 x 3/8” flat head screws. Use blue threadlocker (Loctite 242 or equivalent) and torque the screws to 18-20 in-lb. 8. Remove the 2 jack screws from a 60 in/lb PMA servo (P/N 8100-064 for 12 volt or P/N 8100-065 for 24 volt) and install 2 of the hex head slide lock jack screws included in the wiring harness kit. Use blue threadlocker (Loctite 242 or equivalent) and torque the screws to 2-3 in-lb. Figure 3-11 Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 22 (Loctite242 or equivalent). Torque to 20-25 in-lb. Ensure that the 2.75” PMA Servo Arm Assembly (P/N 7200-106) is orientated upward between the servo stops. Figure 3-14 10. Attach the Early 18X Pitch Bracket (1450-129) to the lower fuselage skin using 9 ea. AN526C-832R8 screws and 9 ea. MS20365-832 nuts. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 23 12. Partially thread the link sensor end of the Early Model 182 Pitch Push Rod (7200-112) in the MM-4 rod end attached to the elevator bellcrank. 13. Fully thread an AN345-10 nut on a MM3-300 rod end then partially thread the MM3-300 rod end into the forward end of the Early Model 182 Pitch Push Rod (7200-112)). 14. Have an assistant hold the yoke in the full aft position and rotate the servo arm against the aft stop on the pitch servo bracket. 15. Thread the MM-3-300 rod end bearing into the servo end of the pushrod until the pushrod is the correct length to align with the drive point on the servo arm. 16. Attach the pushrod to the pitch servo arm with hardware as shown in Figure 3-16 and torque to 20-25 in-lb. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 24 20. Complete routing of the pitch servo wiring harness and trim to length. 21. Terminate the pitch servo wiring harness per the Vizion wiring diagram USING OPTION B in the Vizion PMA Installation Guide (TruTrak Doc. 166) using a Right Angle D-sub 9 Pin Backshell Kit (P/N 8210-011). 22. The pitch servo connector backshell and slidelock should be assembled as shown in Figure 3-17.
- Page 25 23. Insert and tighten the cable retention clamp on the servo connector backshell as seen in Figure 3-18. Figure 3-18 24. Connect the pitch servo connector. 25. Connect the Sheathed Microfit Cable Assembly 1M (P/N 6000-064) to the PMA link sensor (P/N 8000-177) and pitch servo (P/N 8100-064 for 12 volt or P/N 8100-065 for 24 volt). 26. Secure the Sheathed Microfit Cable Assembly 1M (P/N 6000-064) so that routing is as shown in Figure 3-19 and Figure 3-20. The cable will be secured to the pitch push rod using a cable tie. Ensure that cable is free to move as the link sensor moves through full control deflection without excess pressure on the connector. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 26 Figure 3-19 Figure 3-20 27. Verify that the servo and pushrod motion are unobstructed throughout the full control travel. 28. Replace all inspection covers, carpet, seats, and interior previously removed during the installation. 29. Reconnect the aircraft battery. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
-
Page 27: Cessna C180, C182-C182D, C185 Vizion Roll Ipc
3.5. Cessna C180, C182-C182D, C185 Vizion Roll IPC Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 28: Cessna C180, C182-C182D, C185 Vizion Pitch Ipc
3.6. Cessna C180, C182-C182D, C185 Vizion Pitch IPC Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 29: Cessna C180, C182-C182D, C185 Autopilot Settings
14) PRESS ALT button to advance to next setup screen. 15) ROTATE KNOB to select a MICROACTIVITY of 10. 16) PRESS ALT button to advance to next setup screen. 17) ROTATE KNOB to select a GPSS GAIN of 16. 18) PRESS ALT button to advance to next setup screen. 19) ROTATE KNOB to set ROLL REV to Y. 20) PRESS KNOB exit lateral setup and return to the home screen. 21) PRESS and HOLD ALT button until VRT ACTIVITY is shown. 22) WHILE CONTINUING TO HOLD ALT, PRESS MODE. 23) RELEASE MODE and ALT. 24) PRESS MODE until MAC is displayed. 25) ROTATE KNOB to set MAC to 2. 26) PRESS KNOB to exit menu and return to home screen. 27) Do not remove power from autopilot. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... -
Page 30: Vertical Autopilot Settings
23) RELEASE MODE and ALT. 24) PRESS MODE until MAC is displayed. 25) ROTATE KNOB to set MAC to 2. 26) Repeatedly PRESS ALT button until EFIS TYPE is displayed 27) ROTATE KNOB to set EFIS TYPE to: 1 – if the autopilot is connected to an ASPEN, 2 – if the autopilot is connected to a G5, 0 – if the autopilot is connected to any other GPS 28) PRESS KNOB to exit menu and return to home screen. 29) Do not remove power from autopilot. 4.2. Vertical Autopilot Settings For Vizion software version PV.30 follow the steps below: 1) PRESS and HOLD ALT button until VRT ACTIVITY is shown. 2) ROTATE KNOB to select a VRT ACTIVITY of 16. 3) PRESS ALT button to advance to next setup screen. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255... - Page 31 8) ROTATE KNOB to select a PITCH REV of N. 9) PRESS ALT button to advance to next setup screen. 10) ROTATE KNOB to select a STATIC LAG of 1. 11) PRESS ALT button to advance to next setup screen. 12) ROTATE KNOB to select a MICROACTIVITY of 5. 13) PRESS ALT button to advance to next setup screen. 14) ROTATE KNOB to select desired DEFAULT VS (this is the vertical speed setting that the autopilot will use as the value to determine whether or not to synchronize to current vertical speed or synchronize to zero vertical speed, as well as the default vertical speed for altitude pre-select). For example, if the DEFAULT VS is set to 300 fpm, if the aircraft is climbing at 200 fpm, the autopilot select zero VS upon engagement. If the aircraft is climbing at 400 fpm, the autopilot will select 400 fpm upon engagement. We suggest using 300-500 feet per minute. CAUTION! Do not select a DEFAULT VS that is too high, or autopilot performance may be adversely affected. 15) PRESS KNOB to exit vertical setup and return to the home screen. 16) Cycle power on the autopilot. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
- Page 32 TruTrak Flight Systems, Inc. Rev: B Vizion Install Appendix E C180, C182- C182D, C185 TruTrak Doc: 255...
