Timer plus
Contents
1
INTRODUCTION ....................................................................................... 3
2
CONNECTIONS ........................................................................................ 3
...........................................................................................................3
3
THE TIMER LAYOUT ................................................................................ 4
4
QUICK START .......................................................................................... 5
5
LCD DISPLAY AND ICONS ...................................................................... 6
6
MEASUREMENTS .................................................................................... 7
................................................................................................................7
6.2.1
6.2.2
...........................................................................................................8
6.3.1
6.3.2
6.3.3
6.4.1
Timer plus
User Guide
.........................................................................................3
............................................................................3
One gate..................................................................................................7
Two gates................................................................................................7
One gate..................................................................................................8
Two gates................................................................................................8
Smart pulley ............................................................................................8
..................................................................................................8
Two gates................................................................................................8
..........................................................................................................9
........................................................................7
1
Advertisement
Table of Contents
Summary of Contents for Fourier Timer plus
-
Page 1: Table Of Contents
6.2 T ...7 6.2.1 One gate...7 6.2.2 Two gates...7 6.3 V ...8 ELOCITY 6.3.1 One gate...8 6.3.2 Two gates...8 6.3.3 Smart pulley ...8 6.4 A ...8 CCELERATION 6.4.1 Two gates...8 6.5 D ...9 ISTANCE Timer plus User Guide ...3 ...7... - Page 2 6.5.1 Distance sensor ...9 6.5.2 Smart pulley ...9 FRONT PANEL BUTTONS ... 10 7.1 S ...10 ENSOR BUTTONS 7.2 M EASUREMENT UTTON 7.3 R ...11 ANGE UTTON 7.4 O ...11 PERATING UTTONS SPECIFICATIONS... 12 ...10...
-
Page 3: Introduction
Timer plus 1 Introduction The Fourier microprocessor based Timer plus is a versatile stand-alone timer that will meet all of your needs for time and motion measurements in kinematics: time, velocity, acceleration and position. The timer is very easy to use. When you plug in a sensor, the timer automatically recognizes it. -
Page 4: The Timer Layout
3 The Timer layout Sensor inputs Photo gate PC connection Socket Power input (Use AC adaptor) On / Off Button Smart Photo gate Pulley Distance Display Sensors Buttons Start / Stop Button Measurement Button Precision Button... -
Page 5: Quick Start
4 Quick start Make sure that the Timer is connected to the power (use the AC adaptor, connect it to the power input on the left side of the Timer), and follow the next five easy steps: 2. Plug in the... -
Page 6: Lcd Display And Icons
5 LCD display and icons The Timer has large 6 digits display. Above the data display there is an icon bar that indicates the active sensor. The units (and the measurement type) are shown in the right side of the display. -
Page 7: Measurements
6 Measurements 6.1 Working with the Photogate For best results the object that blocks the gate should be matte black. The object should pass through the gate as near as possible to the IR receiver, which is located on the arm that is connected to the mounting rod (the fixed arm in the adjustable Photogate). -
Page 8: Velocity
From: 6.3.2 Two gates Measures the velocity in both photogates and Timer displays the velocities alternately. Use this mode for collision experiments with one or two carts. The calculation is done assuming that the moving object width is 3cm. Use the 3cm motion card. -
Page 9: Distance
Measures the position of a string tangent to the pulley. The photogate head attached to the pulley counts the number of slits that passes through it and the timer calculates the distance the string traveled. (A) pulley – ∆t (B) pulley – ∆t and then calculates the ∆... -
Page 10: Front Panel Buttons
7 Front panel buttons 7.1 Sensor buttons Measures time or velocity with one Photogate Measures time or acceleration between two Photogates. A → B Measures velocities in each of the photogates and displays it alternately. Smart Pulley. Measures velocity or distance of a Pulley string tangent to the pulley Sonic ranger, measures distance to a moving object... -
Page 11: Range Button
7.3 Range Button Precision Select precision from 1 digit after the decimal point to four digits after the decimal point. 7.4 Operating Buttons On/Off Turning the Timer On and Off Start/Stop Start or stop recording... -
Page 12: Specifications
0 to 100m/s Acceleration Range 0 to 100m/s Resolution Timer Display: 100µs PC Software (Optional): 2µs Timer Display: 100 µS Accuracy PC Software (Optional): 2µs Photogate Detector rise time: 180ns Detector fall time: 180ns Infrared source: Peak at 800 nm...
