CONTROLSKY
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CONTROLSKY and is the answer not in the manual?

Questions and answers

Related Manuals for Exalux CONTROLSKY

Summary of Contents for Exalux CONTROLSKY

  • Page 1 CONTROLSKY USER MANUAL...
  • Page 2 EXALUX™ CONTROL SKY is a 5-in-1 wireless DMX controller ® especially designed to control up to 20 SkyPanels with sense CONTROLSKY and simplicity. CONTROL SKY works perfectly with all CRMX by LumenRadio™ Getting started... receivers. CRMX LINK/UNLINK CRMX Hold 3s to unlink all CRMX devices...
  • Page 3 HOME PLAYER APP allows you to RECORDER RECORDER APP allows to PLAYER Choose app using the touch screen play the DMX memories that record 512 DMX channels in or the knobs have been recorded with real time. the FADER, RECORDER and 8 memories | 80s recording SKY apps.
  • Page 4 SKY APP allows to control up to 20 SkyPanels® in DMX P30 mode. Operation modes are : CCT+GM, HSI, RGBW, [X,Y], Effects, Source Matching and Filters. ADJUST CHANNEL LEVEL ADJUST INTENSITY LEVEL CHANNEL SELECTION CHANNEL SELECTION SKYPANEL SELECTION CHOOSE THE CONTROL Up to 20 MODE NAVIGATE BETWEEN...

  • Page 5: Fixture Setup

    FIXTURE SETUP Selection of the fixture to control ENABLE / DISABLE COLOUR 1 / COLOUR 2 THE FIXTURE SELECTION TABS The SkyPanel must be set in The P30 consists of two individual colour modes, crossfaded with a DMX mode Ultimate 8 bits dedicated slider.
  • Page 6 FADER FADER APP works the exact same way than your hardware DMX console you used for years. Every fader is linked to a DMX address. SET CHANNEL LEVEL SET MASTER LEVEL PREVIOUS FADER PREVIOUS FADER <1’’ <1’’ FADER SCROLLING FADER SCROLLING >1’’...
  • Page 7 RECORDER RECORDER APP allows to record all DMX frames received on the DMX input. Record sequences up to 80 seconds at 44 Hz on each of the 8 memories. SELECT A MEMORY Recording stops automatically when memory full TO RECORD DMX IN seconds @ 44Hz) EMPTY MEMORY The recorded sequences can...
  • Page 8 PLAYER PLAYER APP allows you to play the DMX memories that have been recorded with the FADER, RECORDER and SKY apps. CHOOSE THE SELECT SOURCE MEMORY TO USE EMPTY MEMORY FILLED MEMORY SET MASTER LEVEL SET CROSSFADE CHANGE THE DURATION MEMORY NAME BACK TO HOME...

  • Page 9: Back To Home

    TX APP turns the CONTROL SKY into a CRMX transmitter. The DMX received on the DMX input is wirelessly transmitted by the integrated CRMX transmitter. The CRMX transmitter is automatically switched on when the TX app is running. DMX INPUT STATUS GREEN: DMX OK WIRELESS OUTPUT STATUS RED: NO DMX...

  • Page 10: System App

    SYSTEM SYSTEM APP allows you to reset the memories, adjust the display brightness and set a pin code. SCREEN BRIGHTNESS ADJUSTMENT RESET MEMORIES RESET MEMORIES 3’’ 3’’ OF SKY APP OF RECORDER APP RESET MEMORIES 3’’ 3’’ RESET CONTROL SKY OF FADER APP BACK TO HOME PIN CODE SETUP...
  • Page 11 CONTROLSKY ECO-SYSTEM RX100S RECEIVER EXORAA iOS/Android DEVICES CONTROL SKY LEDMASTER NEO DIMMER RX200N RECEIVER CONNECT ONE DMX CONSOLE...

  • Page 12: Technical Specifications

    Lock / unlock function 5VDC (USB) | 10-24VDC (XLR4) Input / 4W max SPECIFICATIONS Runs up to 11h with 10Ah/36Wh PowerBank XLR5 DMX input (M) & output (F) 180x154x50 mm | 700g Fully compatible with EXALUX™ CONNECT * depending on the receiver...
  • Page 13 Do not modify the power cord nor the plug. In case of EXALUX reserves the right to modify and upgrade its non-compliance, there is a risk of electric shock and range of products, with no obligation to integrate fire hazard and death.
  • Page 14 DESIGNED MADE NANTES FRANCE DIMMING LIGHT CONNECT CONTROL EXALUX, 1 rue de la Noë 44322 Nantes Cedex 3 France | +33 9 72 45 70 43 | contact@exalux.eu...
