Quick Set-up Instructions
Instructions de Montage Rapide
Instrucciones para la Instalación Rápida
Tubes de montage
Tubos de montaje
Figure 1 - Handle Assembly
Figure 1 - Montage de pied en caoutchouc
Figura 1 - Ensamble del mango
Lock washer
Contre-écrou
Nut
Contratuerca
Écrou
Tuerca
Figure 2 - Wheel Assembly
Figure 2 - Assemblage de la roue
Figura 2 - Ensamble de la rueda
© 2009 Campbell Hausfeld/Scott Fetzer
Mounting tubes
Washer
Rondelle
Arandela
For parts, product & service information
visit www.chpower.com
Screw
Vis
Tornillo
HL551600
Axle bolt
Boulon d'essieu
Perno del eje
Wheel
Roue
Rueda
IN631900AV 9/09
