- Page 1 Z01 - SLIDING GATE HOME AUTOMATION zero Z01 - SLIDING GATE MOTOR HOME AUTOMATION SUPPLY 230-24V IT | EN | FR Z01.REV01.2018 USER MANUAL AND CONFIGURATION...
- Page 2 Z01 - SLIDING GATE HOME AUTOMATION zero HOME AUTOMATION...
- Page 3 •ZERO SRLS. is not responsible for the improper use of the product, or other use than that for which it was designed.
- Page 4 Z01 - SLIDING GATE HOME AUTOMATION 02. OPERATOR TECHNICAL SPECIFIATIONS Z01 specifications are as follow: Z01.01 Z01.01.24 Z01.02 Z01.02.24 Power Supply 230Vac 50/60Hz 24Vdc 230Vac 50/60Hz 24Vdc Power 250W 400W Current 1,4 A 1-3 A 1-3 A 1400 2000...
-
Page 5: Installation Dimensions
Z01 - SLIDING GATE HOME AUTOMATION 03. INSTALLATION INSTALLATION DIMENSIONS During installation you will need to open the motor cover, to access various components on the inside. For this, loosen the screw until the cover is free to be removed. - Page 6 Z01 - SLIDING GATE HOME AUTOMATION It is very important that these dimensions are respected! Only this way can be assured the correct functioning and durability of the operators! During the course of the gate, all elements of the rack must mesh properly with the pinion! All rack supports must be weld at the gate.
-
Page 7: Maintenance
Z01 - SLIDING GATE HOME AUTOMATION 04. MAINTENANCE Check that the distance between rack and motor remains unchanged and this engages the teeth of the pinion of the engine correctly (over time can happen some distortion). Lubricate all systems/axis of movement of the gate. Lightly lubricate with spray the rack and pinion. -
Page 8: Troubleshooting
Problem Procedure Behavior Procedure II Make sure you have 230V Door doesn’t power supply connected Consult a qualified ZERO work Still not working. to control board and if it technician. is working properly. Consult an experienced Encountered problems? gate expert. - Page 9 All ZERO control boards have LEDs that indicate the functioning of connections to allow easy diagnosis of faults. All safety devices LEDs (DS) in normal situations remain On. All “START” circuits LEDs in normal situations remain Off.
- Page 10 Z01 - SLIDING GATE HOME AUTOMATION NOTE: _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ _____________________________________________________________________ PG10...
- Page 11 Z01 - SLIDING GATE HOME AUTOMATION zero HOME AUTOMATION PG11...
-
Page 12: Home Automation
Z01 - SLIDING GATE HOME AUTOMATION zero HOME AUTOMATION ZERO SRLS Via ROMA 25/A ALTAVILLA VIC. ITALIA info@miozero.it - www.miozero.it PG12...
