Summary of Contents for Eguana Technologies Evolve 0513
- Page 1 Eguana Evolve™ Evolve Owner’s Manual Model Evolve 0513 DO 68025...
- Page 2 Operating the product in a way that it was not intended can also result in permanent damage to the product. This manual applies to the following products: Evolve 0513 Energy Storage System Warranty The Eguana Evolve includes a 10 year standard warranty with performance pro-rating for the battery modules. Please review the warranty statement included with your product.
-
Page 3: Table Of Contents
Table of Contents Contents 1 SAFETY ......................................1 1.1 I ............................1 N CASE OF EMERGENCY 1.3 E ..........................2 NVIRONMENTAL ROTECTION 2 INTRODUCTION ....................................3 2.1 O ................................3 VERVIEW – A 2.2 S ......................4 YSTEM ONITORING CCOUNT ETUP 3 OPERATION ..................................... -
Page 4: Safety
1 Safety Throughout this manual, the following symbols will be used to highlight important information and procedures: Symbol Definition WARNING! A dangerous voltage or other condition exists. Use extreme caution when performing these tasks. CAUTION! This information is critical to the safe installation and or operation of the system. Follow these instructions closely. -
Page 5: Environmental Protection
1.2 General safety precautions Important! Never operate the system in a manner not described by this manual. Only qualified personnel should service this product. Risks of Fire Do not expose the system to temperatures exceeding 45 degrees Celsius. Avoid installation in direct sunlight. Do not store objects on top of the cabinet. -
Page 6: Introduction
2 INTRODUCTION 2.1 Overview This manual contains instructions for the operation of the Eguana Evolve™ home energy storage system. This product, when installed, is permanently wired to the home electrical panel. There are two main components as shown below, including the energy storage system (1), and the energy meters installed in the main electrical panel (2). -
Page 7: System Monitoring - Account Setup
2.2 System Monitoring – Account Setup The system can be viewed online via desktop or mobile by signing into your account at: https://app.switchdin.com/accounts/sign-in?profile=eguana You will receive an automated invitation email to setup your account after the installer has completed the system installation. 3 Operation The Evolve home energy storage system is fully automated. -
Page 8: Service Button
3.2 Service Button The service button can be used to wake the LED display, and either put the system into or out of service mode, as well as cycle through various operating modes. IMPORTANT! In the event that the system has gone out of service, please consult your installer for guidance. Depending on the nature of the service fault, your installer may advise you to reset the system on your own, or schedule a service visit. -
Page 9: Troubleshooting
6 Troubleshooting System faults are reported and logged in the monitoring system. All fault logs are also accessible remotely by your installer. IMPORTANT! Contact your system installer as recommended below if any of the following conditions are present on the front display of the inverter panel.
