THERMOSALD UPSCR Series Operator's Manual

Temperature controller for impulse sealing
Hide thumbs Also See for UPSCR Series:

Advertisement

Quick Links

TEMPERATURE CONTROLLER FOR IMPULSE SEALING
MANUAL BALANCING at first start up
AUTOMATIC BALANCING at sealing band change
BURN IN of sealing band
AUTOMATIC POWER FREQUENCY SWITCHING
ENERGY CONTROL ON SEALING BAND
485 SERIAL INTERFACE to exchange data to supervisor
3E S.r.l.
Via del Maccabreccia 37/a - 40012 LIPPO DI CALDERARA ( BOLOGNA )
-
Tel. ++39 051 6466225
Fax ++39 051 6426252
THERMOSALD
UPSCR
AUTOMATIC CALIBRATION
OPERATOR MANUAL
Mod. UPSCR_N_V5 (M_V4)
e-Mail : mail@3e3e3e.com
Indirizzo internet : www
.3e3e3e.com
