- Page 1 English 755/7 60 Operator’s Manual 2016-...
-
Page 2: Table Of Contents
Table of contents 755/760i TABLE OF CONTENTS Table of contents............2 Starting the engine..........21 Introduction..............3 Stopping the engine..........21 Safety instructions............4 Drive control............22 Warranty..............6 Steering of the machine.........23 Description of the loader..........7 Loader control............23 Engine identification..........8 Using the auxiliary hydraulics........23 Loader identification..........8 Requirements for attachments......24... -
Page 3: Introduction
Keep this Operators Manual with the machine at all times. If this Manual gets lost, ask for a new copy from your Avant dealer. Remember also to give this Manual to the new owner when the machine changes ownership. -
Page 4: Safety Instructions
Do not transport or lift persons in the bucket or in any well as the safety instructions. other attachment. Lifting of persons is only allowed with the attachment designed for this purpose: Avant Understand the limitations of speed, braking, steering and Leguan 50, following the instructions in the Operators stability as well as loading capacity of the machine before Manual of Leguan 50. - Page 5 755/760i Safety instructions Handling of heavy loads and load sensor Safety frame (ROPS) and safety canopy (FOPS) The loader is equipped with a load sensor system. It Safety frame (ROPS) protects the operator gives an audible warning signal and at the same time an in case the machine tips over.
-
Page 6: Warranty
755/760i Avant 755/760i warranty This warranty specifically applies to the AVANT 755/760i loader only and not to any attachments used with this product. Any repairs or modifications performed without the prior authorisation of Avant Tecno Oy will cancel this warranty. -
Page 7: Description Of The Loader
755/760i Description of the loader Description of the loader Identification of the loader Write down the identification information of your loader in the following fields, it facilitates ordering of spare parts etc. 1. Loader model_____________________________________________ 2. Loader serial no.___________________________________________ 3. Engine serial no.___________________________________________ Serial number of the loader is printed on the type plate (see page 9), which also indicates the loader model. -
Page 8: Main Parts Of The Loader
Description of the loader 755/760i Main parts of the loader Following picture shows the main parts of the loader: Hydraulic connectors Multi connector Pressure 2 Pressure 1 Tank line Attachment control switch pack socket (option) Attachment coupling plate Front frame Attachments are mounted on the attachment coupling On the front frame are mounted: driver’s seat,... -
Page 9: Signs And Decals
Signs and decals Make sure that the following signs and decals clean, undamaged and readable. If any of these decals is missing or is unreadable it should be replaced without delay. Ask for new decals from your local Avant dealer. -
Page 10: Technical Specification
Description of the loader 755/760i Technical specification Model AVANT 755/760i Engine make and type Kohler KDI 1903 TCR Model AVANT 755 AVANT 760i Function 4-stroke, OHV, four valves/cylinder, Tur- Length 3080 mm bocharged, Common rail direct injection Width see table on page 11 Coolant Water/50% antifreeze, Freezing point -37C, total 11.6l... -
Page 11: Fuel Requirements
Consult your dealer for further information. Emission control information l/min Avant 755 and 760i with Kohler KDI engine meets the most stringent European 97/68/EC Stage 3B and US EPA and CARB Tier 4 Final emissions standards for compression ignited engines in 37-56 kW power category. -
Page 12: Load Diagram
Description of the loader 755/760i Load diagram The lifting capacity of the loader is limited by the possibility of tipping around the front axle. The diagram below shows the tipping loads and max. allowed loads in different loading situations on an even level surface with the loader chassis in maximum articulation. -
Page 13: Operating Instructions
755/760i Operating instructions Operating instructions... -
Page 14: Operating Controls
Operating instructions 755/760i Operating controls Following picture shows the location of operating controls. The location and function of controls may be slightly different in different models, see following pages. Cab DLX: Some of the switches are on the panel in the cab. -
Page 15: Control Of Loader Boom, Auxiliary Hydraulics And Other Functions
755/760i Operating instructions Control of loader boom, auxiliary hydraulics and other functions Most of the functions of the loader are controlled at the control panel on the right side of the operator: Boom and bucket movements, auxiliary hydraulics (attachments), engine revs etc. , depending on loader model. Following pictures show the... -
Page 16: Dashboard
Operating instructions 755/760i Dashboard Indicator lights Ref. Symbol Indicator Colour Remarks On the dashoard on the right side of the driver’s Road traffic light kit, optional seat are mounted gauges, indicators and switches Head- Green lights which help the operator to control the loader. -
Page 17: Gauges And Switches On The Dashboard
755/760i Operating instructions Gauges and switches on the dashboard Suspension seat The suspension seat is equipped with a seat belt and has the following adjustments: Charge indicator 1. Suspension adjustment Drive release valve switch • by turning the knob counterclockwise suspension... -
Page 18: Drive Speed Range Selection Switch
Operating instructions 755/760i Drive speed range selection switch Seat heater Avant 760i is equipped with two-speed hydraulic drive The suspension seat is equipped motors. Drive speed range can be selected with the switch with an electric seat heater. Seat on the control panel right (see page 14). In addition to... -
Page 19: Boom Self Levelling
Requirements vary in different countries, please consult The loader can be equipped, as an option, with an engine your local AVANT distributor. block heater. Engine block heater outlet (220V-240V )is on the right side in the rear of the machine. -
Page 20: Tilt Adapter
Operating instructions 755/760i Tilt adapter (option) Extra auxiliary hydraulics outlets, front and rear (option) The hydraulic tilt adapter mounts between the attachment and the In addition to the standard auxiliary hydraulics outlet, attachment coupling plate. It allows the loader can be equipped with a double acting extra the driver to tilt the attachment outlet. -
Page 21: Starting The Engine
755/760i Operating instructions Starting the engine Before starting the engine do the daily checks, see page 27. Adjust the seat and mirrors (if fitted) so that you have a good working position and unrestricted field of vision from the driver’s seat. Check that all controls function correctly. See to it that the operating area is safe. -
Page 22: Drive Control
Principle of operation AVANT 700 series is equipped with a hydrostatic drive system, a variable displacement hydraulic pump in the drive circuit is proportianally controlled with the two drive pedals. Driving of the machine is controlled with the drive pedals and hand throttle. -
Page 23: Steering Of The Machine
755/760i Operating instructions Steering of the machine Loader control Steering of the machine happens with the steering wheel. The loader boom and bucket are controlled with the The steering wheel is hydraulically powered. A practical multi-function lever sideways (tilt) and back & forward way of steering is to steer with your left hand on the knob (boom up &... -
Page 24: Requirements For Attachments
• Read Operators Manual of the attachment before starting operation. Make sure that the attachment is compatible with the loader. Contact your Avant dealer if necessary • Check max. allowed hydraulic oil flow for the attachment. Adjust engine revs so that they are suitable for the work and the attachment. -
Page 25: Coupling The Hydraulic Hoses Of The Attachment
755/760i Operating instructions Coupling the hydraulic hoses of the attachment Hydraulic hoses of the attachment are equipped with the multi connector system, which connects all hoses at the same time. Coupling the multi connector Align the pins of the attachment connector with correspondig holes of the loader connector. -
Page 26: Cabs
Cabs Air conditioning (option for cab DLX) On CAB DLX some the AVANT 700 series can be equipped, as an option, with cab switches shown in detail on L, LX or DLX. All cabs are ROPS and FOPS certified. page 14 are located on the control panel up to the right. - Page 27 755/760i Operating instructions Heater Air conditioning (option for cab DLX) Cab DLX can be equipped, as an option, with air (cab LX) conditioning. A/C switch is located on the panel up to the Temperature right. The A/C condenser is mounted at the factory either...
-
Page 28: Service And Maintenance Instructions
Service and maintenance instructions 755/760i Service and maintenance instructions Service parts are available through your Avant dealer or authorized service. If you are not sure about how to do any service operation, ask for additional information before starting servicing. Contact Avant service. -
Page 29: Daily Inspections
755/760i Service and maintenance instructions Daily inspections • Tyre pressure • Locking of attachment and locking pins on attachment • Boom movements coupling plate, function of attachment, position of • Drive control and steering attachment hoses • Eventual need for lubrication •... -
Page 30: Cleaning Of The Machine
Service and maintenance instructions 755/760i 2. Cleaning of the machine 6. Check coolant level Cleanliness of the loader is not only a question of outer Coolant level should be above the appearance. All surfaces, painted and others, will stay minimum marker on the reservoir, in better condition when they are cleaned regularly. -
Page 31: Check And Tightening Of Bolts, Nuts Etc
There are two pressure relief cartridges which have fixed 370 bar pressure setting. It is recommended that pressures should only be checked by a competent and experienced technician. Call your AVANT dealer if you need assistance. -
Page 32: Adjust And Change Of Slide Pads On Telescopic Boom
The load sensor must be calibrated in case one adds or removes more than two AVANT rear weights (+/- 65 kg) Slide pads 1 to 4 can be adjusted on the machine. Calibrating happens as follows:... -
Page 33: 18. Water Separator And Fuel Filter
Cab LX and DLX 19.-26. Service, engine AVANT 760i is equipped with a Kohler KDI diesel engine. Service and maintenance instructions for the engine can be found in the Kohler Operator’s Manual supplied with the loader. -
Page 34: Hydraulic Oil Cooler Fan Fuse
The red indicator no. 2 on the dashboard indicates blown thoroughly and clean the fuel tank after every 2 years. hydraulic oil cooler fan fuse. If the indicator is lit, check the 25A fuse of the oil cooler fan. Contact Avant service Storage of the machine if necessary. -
Page 35: Greasing Points
755/760i Service and maintenance instructions Greasing points Following pictures show the location of greasing points. Greasing points pcs. Greasing points pcs. Lift cylinder, both ends Articulation joint Steering cylinder, both ends Tilting mechanism Tilt cylinder, both ends Leveling cylinder, both ends... -
Page 36: Filters
Service and maintenance instructions 755/760i Filters Following pictures and tables show the location and part numbers for the filters. Avant 755/760i filters Part number Air filter 66060 Fuel filter 66062 Fuel filter, pre filter 64657 Engine oil filter 66063 Hydraulic oil filter, return... -
Page 37: Troubleshooting
755/760i Troubleshooting Troubleshooting Problem Possible cause Remedy Main switch off Turn on the main switch Battery discharged, battery voltage Check and charge too low Engine does not crank Check fuses. If fuse blows again, find out the cause. Blown fuse... -
Page 38: Service History
Services made 755/760i Services made 1. Customer_____________________________________________________ 2. Loader model_______________Serial no____________________________ 3. Date of delivery________________________________________________ Date of service Operating Serviced by: Remarks dd / mm / yyyy hours Stamp/signature ___/___/______ ______ / 50 h ___/___/______ ______ / 450 h ___/___/______... -
Page 39: Ec Declaration Of Conformity
EC Declaration of conformity 500 Series EC Declaration of conformity EC DECLARATION OF CONFORMITY 1. Manufacturer: Avant Tecno Oy Ylötie 1 FI-33470 YLÖJÄRVI FINLAND 2. We hereby declare that the machines listed below conform to EC Directives, as they are amended: 2006/42/EC (Machinery), 2004/108/EC (EMC) and 2000/14/EC (Noise Emission). - Page 40 FIN-33470 YLÖJÄRVI, FINLAND Tel. +358 3 347 8800 Fax +358 3 348 5511 e-mail: sales@avanttecno.com AVANT has a policy of continuing improvement, and retains the right to change specifications without notice. © 2016 AVANT Tecno Oy. Kaikki oikeudet pidätetään. www.avanttecno.com...
