System config
FortiGate-100 Administration Guide
The cluster units use the ethernet interfaces configured with HA heartbeat priorities for
HA heartbeat communication. The HA heartbeat communicates cluster session
information, synchronizes the cluster configuration, synchronizes the cluster routing
table, and reports individual cluster member status. The HA heartbeat constantly
communicates HA status information to make sure that the cluster is operating
properly.
You can enable heartbeat communications for physical interfaces, but not for VLAN
subinterfaces.
Enabling the HA heartbeat for more interfaces increases reliability. If an interface fails,
the HA heartbeat can be diverted to another interface.
HA heartbeat traffic can use a considerable amount of network bandwidth. If possible,
enable HA heartbeat traffic on interfaces only used for HA heartbeat traffic or on
interfaces connected to less busy networks.
Table 5: Default heartbeat device configuration
FortiGate model
FortiGate-100
Change the heartbeat device priorities as required to control the interface that is used
for heartbeat traffic and the interface to which heartbeat traffic reverts if the interface
with the highest heartbeat priority fails or is disconnected.
Setting the heartbeat priority for more interfaces increases the reliability of the cluster.
To optimize bandwidth use, you can route most heartbeat traffic to interfaces that
handle less network traffic. You can also create a failover path by setting heartbeat
priorities so that you can control the order in which interfaces are used for heartbeat
traffic.
The heartbeat priority must be set for at least one cluster interface. If heartbeat
communication is interrupted the cluster stops processing traffic.
Heartbeat device IP addresses
You do not need to assign IP addresses to the heartbeat device interfaces for them to
be able to process heartbeat packets. In HA mode the cluster assigns virtual IP
addresses to the heartbeat device interfaces. The primary cluster unit heartbeat
device interface is assigned the IP address 10.0.0.1 and the subordinate unit is
assigned the IP address 10.0.0.2. A third cluster unit would be assigned the IP
address 10.0.0.3 and so on.
For best results, isolate each heartbeat device on its own network. Heartbeat packets
contain sensitive information about the cluster configuration. Also, heartbeat packets
may use a considerable amount of network bandwidth and it is preferable to isolate
this traffic from your user networks. The extra bandwidth used by heartbeat packets
could also reduce the capacity of the interface to process network traffic.
01-28006-0003-20041105
Default heartbeat device
External
DMZ
HA configuration
Default priority
50
100
