Connecting to the web-based manager

Connecting to the web-based manager
14
3 Connect the power cables to power outlets.
Connect each power cable to a different power source, if possible. If one power
source fails, the other source might still be operative.
After a few seconds, SYSTEM STARTING appears
on the LCD.
MAIN MENU appears on the LCD when the system
is running.
Table 1: FortiGate-1000 LED indicators
LED
Power
1 to 4/HA
Internal
External
To power off the FortiGate unit
Always shut down the FortiGate operating system properly before turning off the
power switch.
1 From the web-based manager, go to System > Maintenance > ShutDown, select
Shut Down and select Apply, or from the CLI, enter:
execute shutdown
2 Turn off the power switch.
3 Disconnect the power cable from the power supply.
Use the following procedure to connect to the web-based manager for the first time.
Configuration changes made with the web-based manager are effective immediately
without resetting the firewall or interrupting service.
State Description
Green The FortiGate unit is powered on.
Off The FortiGate unit is powered off.
Amber The correct cable is in use, and the connected equipment has
power.
Flashing Network activity at this interface.
amber
Green The interface is connected at 100 Mbps.
Off No link established.
Amber The correct cable is in use, and the connected equipment has
power.
Flashing Network activity at this interface.
amber
Green The interface is connected at 1000 Mbps.
Off No link established.
01-28004-0025-20040830
Getting started
