2.1 Attaching the arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Remove the input/output port cover (Figure 1).
3. Attach the base into the arm, making sure the tab on the arm fits into the
groove on the base (Figure 2).
(Figure 1)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2 Detaching the arm/base (for VESA
wall mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the input/output port cover (Figure 1).
3. Press the release button, and then detach the arm/base from the monitor
(Figure 2).
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
ASUS PA32U Series LCD Monitor
(Figure 1)
2
1
(Figure 2)
2
1
(Figure 2)
2-1
