1.3 Monitor introduction
1.3.1. Front.view
1. Menu (5-way) button:
• Press this button to enter the OSD menu.
• Enacts the selected OSD menu items.
• Increases/Decreases values or moves your selection up/down/left/right.
2. Close button:
• Exits the OSD menu.
• Toggles the Key Lock function between on and off with a long press for
5 seconds.
3. Input select button:
• Selects an available input source.
Press
HDMI-4, Thunderbolt, DisplayPort signals after you connect HDMI/DisplayPort/
Thunderbolt cable with the monitor.
4. QuickFit button:
• This is a hotkey to activate the QuickFit function designed for alignment.
• The QuickFit function contains 5 types of alignment patterns. (Please refer
to 1.3.3 QuickFit Function).
Shortcut
5.
• Default: Brightness hotkey
1-2
Menu
Close
Input Select
QuickFit
Brightness
Blue Light Filter
button (Input Select button) to display HDMI-1, HDMI-2, HDMI-3,
1
2
3
4
5
6
7
Chapter 1: Product introduction
