ProxSys Media Server
Applications
Broadcast
Digital Media Archiving
Education and Distance Learning
Healthcare
Research and Development
Video Production
PROXSYS MEDIA SERVER
With an intuitive browser-based interface, robust features, and scalable configuration op-
tions, the ProxSys
Media Server from Focus Enhancements makes media asset manage-
®
ment simple and cost-effective. By combining the functionality, flexibility, and scalability
of a custom system with the implementation time and ownership cost of an "out of the
box" solution, ProxSys gives you the performance you want for a price you can afford.
ProxSys Media Server
A fully integrated solution, the ProxSys Media Server combines ProxSys Media Asset Man-
agement software with professional-grade server hardware to provide a turnkey media asset
management system that can easily grow as your needs evolve. Media stored on ProxSys
is accessed through an intuitive browser-based interface—no proprietary client software is
required.
Media Asset Management
Designed for fast performance, the ProxSys Media Server uses rich metadata to make it easy
to find and retrieve media assets quickly. Low-resolution MPEG-4 proxy video clips of your
HD, HDV, DV, and MPEG footage allow for quick preview, protect high-resolution media
assets, and save network bandwidth.
The browser-based interface provides immediate access to audio, video, images, and
text-based data from any location. Additional features include online and offline usage,
picture-to-clip extract, multi-client support, access rights management, and NLE format
compatibility via the FireStore DV Conversion Suite.
1
2
1
Access assets through an intuitive browser-based interface with user-friendly navigation.
2
Manage multiple projects with unique and secure access rights.
3
View proxy files in the integrated player, complete with mark-in and mark-out tools.
4
Search easily using timecode-based metadata.
PROXSYS MEDIA SERVER
www.focusinfo.com 800.338.3348
3
4
Page 1 of 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Proxsys and is the answer not in the manual?

Questions and answers

Related Manuals for Focus Proxsys

Summary of Contents for Focus Proxsys

  • Page 1 By combining the functionality, flexibility, and scalability of a custom system with the implementation time and ownership cost of an “out of the box” solution, ProxSys gives you the performance you want for a price you can afford. ProxSys Media Server...
  • Page 2 find clips—with amazing speed. Projects ProxSys uses projects to organize and store media and related files. When you import me- dia, you can either create a new project or assign it to an existing project. Projects can also have subfolders, allowing you to organize files within a project.

  • Page 3: Exporting Media

    ProxSys features a number of export modules (each sold separately) that simplify the distri- bution process. For example, you can upload video from ProxSys to a web server or an FTP server. When you make video available for download, you can incorporate an order form to collect information before download can begin, ensuring that you capture information about those who use your footage.
  • Page 4 German Air Force ProxSys Media Server Editions Available in two editions, the ProxSys Media Server features flexible configurations to suit almost any organization. The Workgroup Edition is ideal for organizations with up to 24 us- ers. If your organization has 25 or more users, the Enterprise Edition is recommended and is available in four configurations.

  • Page 5: Supported Media Formats

    The ProxSys Media Server supports both high- and standard-definition video and generates MPEG-4 proxy files that make it fast and easy to preview footage. In addition to your media assets, ProxSys can also store other information that pertains to your media-based projects, such as proposals, storyboards, supporting documentation, and more.

  • Page 6: Online Storage

    32TB to 332TB. ProxSys Storage The ProxSys Media Server supports a wide range of storage options, including disk, optical, and tape-based systems. By taking a number of factors into consideration, Focus Enhance- ments can help you determine how much storage capacity you need and which storage option or combination of options will best serve your organization.
  • Page 7 A copy of the data can be accessed and edited, or discs can be removed from the system and shelved. Either way, ProxSys keeps track of your footage so you can easily locate and retrive it at any time.

  • Page 8: Technical Specifications

    ProxSys Media Server Enterprise Edition 5.0 Operating System SUSE Linux 2.6 Database SQL Server Utilities ProxSys Media Import, ProxSys Multimedia Tools; Direct File Server; FTP Server; Web Configuration and Service Tool Client Software Browser (user supplied) Windows: Internet Explorer; Macintosh OS: Safari Export Modules ProxSys Export Modules (optional) Public;...
