HX-1
HX-2
Control panel shown. Also includes 1RU electronics chassis.
Applications
Broadcast
News Production
outside Broadcast
Rental
Small Studio
Sports
Other
Education
Event production
Government
House of Worship
HX-1 and HX-2
Rugged, portable, and designed to excel in today's most demanding high-definition
production environments, the brand-new HX line of HD video switchers from Focus
Enhancements not only meets the highest broadcast standards, but also provides an
array of simple-to-operate features. Whether you're conducting a live outside broadcast
or shooting inside a production studio, the Focus HX-1 Portable HD Video Switcher and
Focus HX-2 HD/SD Video Switcher enable you to switch seamlessly between video
sources and blend high-quality digital content on the fly.
HX HD Video Switchers
Designed from the inside out to excel in today's demanding high-definition production envi-
ronment, HX HD video switchers are easy to set up and operate, feature full 10-bit internal
processing, generate superior-quality video effects, and meet the highest broadcast standards.
Models
Focus HX HD video switchers are available in two models—the Focus HX-1 Portable HD
Video Switcher and the Focus HX-2 HD/SD Video Switcher.
Key Features
MoDEl
Inputs
HD-SDI only (each with its own active loop-through output)
HD-SDI or SD-SDI
External SD/HD-SDI Key Inputs (DSK and Fill)
outputs
HD-SDI only
(2 x line/Program, 2 x Preview, 2 x Video Effects)
HD-SDI or SD-SDI
(2 x line/Program, 1 x Preview, 1 x Video Effects,
1 x Utility 1, 1 x Utility 2, 1 x Key Channel)
Robust Functionality
2D DVE (see page 2 for a complete list)
Mixing and Wipes (eight wipe patterns)
Video Delay
External Reference Signal Integration (active loop-through)
Frame Synchronizer (all inputs)
Rugged Construction
Professional, rugged metal enclosure with high-quality
back-lit channel buttons, lCD display, and machined
aluminum fader bar with extremely smooth operation
Easy to Set Up, learn, and Use
Simple to integrate into a variety of equipment configurations
Intutive layout for easy operation
HX-1 AND HX-2
HX-1
4
—
—
6
—
—
•
1H
•
•
•
•
•
www.focusinfo.com 800.338.3348
HX-2
—
8
2
—
7
•
•
1H
•
—
•
•
•
Page 1 of 4
