BDI vertica Assembly Instructions

vertica
8559
home theater
Component List
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents,
trade dress, and/or copyright laws.
BDI are trademarks of Becker Designed, Inc.
All Rights reserved. ©2014, BDI
Made in China. 8559REV012315v2
Vertica is engineered for easy assembly. Carefully
follow this procedure to prevent any damage.
A - Phillips Screwdriver
x 1
Placement and Maintenance
Vertica is designed for indoor use on level floors.
B1 - Hex Wrench
Clean wood veneer with a moist cloth.
x 1
B2 - Leveler Wrench Step 1
x 1 Unpack and Identify
Unpack and identify the components at left. Note
that some components are shipped inside the
cabinet. The assembly workspace should be a non-
C - Cabinet x 1
marring surface such as carpet. For missing hardware pieces, please
contact BDI Customer Service at customerservice@bdiusa.com. For all
other concerns, please contact your BDI Retailer.
D - Cam Bolt x 2
E - Cam Fitting x 2
F - Wood Dowel x 2
Step 2
G - Side Legs x 2
Install and tighten Cam Bolts (D) into Side Legs (G) using Phillips
Screwdriver (A). Insert Wood Dowels (F) into corresponding holes of
Side Legs (G).
H - Base Stretcher
x 1
I - Center Leg x 1
J - 1/4-20 x 60 mm
Machine Screw
x 3
K - 1/4-20 x 100 mm
Machine Screw
x 6
L - Adjustable Shelf
x 2
M - Large Adjustable
Shelf x 1
N - Back Panel
x 2
a s s e m b l y i n s t r u c t i o n s
bdiusa.com
D
G
F
1
customerservice@bdiusa.com
TWO PERSON ASSEMBLY
D
F
G
D
F
J
G
