- Page 1 www.wester mo.com Lynx DSS L-106-S2 EX / L-206-S2 EX Industrial Ethernet 6-port Device Server Switch WeOS...
- Page 2 6643-22901...
-
Page 3: General Information
Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Before Installation
Do not use or store the unit in dusty, dirty areas, connectors as well as other mechanical part may be damaged. If the unit is not working properly, contact the place of purchase, nearest Westermo distributor office or Westermo Tech support. -
Page 5: Maintenance
Maintenance No maintenance is required, as long as the unit is used as intended within the specified conditions. Product disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it. It needs to be handed over to an applicable collection point for recycling electrical and electronic equipment. -
Page 6: Atex Certification
ATEX certification ATEX certification number Baseefa12ATEX0119X Standards EN 60079-0:2012, EN 60079-15:2010. Certification code Ex nA IIC T3 Gc (–40°C ≤ Ta ≤ +70°C) ATEX code II 3G Specific Conditions of Use The equipment must be installed in an area of not more than pollution degree 2 in accordance with IEC/EN 60664-1, and in an enclosure that provides a minimum degree of protection of at least IP54 and complies with the relevant requirements of EN 60079-0 and EN 60079-15. - Page 7 ATEX-Zertifizierung ATEX-Zulassungsnummer Baseefa12ATEX0119X Standards EN 60079-0:2012, EN 60079-15:2010 Zertifizierungscode Ex nA [op ist T4] IIC T3 Gc (–40 °C ≤ Ta ≤ +70 °C) ATEX-Code II 3G Spezifische Einsatzbedingungen Die Geräte müssen in einem Bereich welcher einem maximalen Verschmutzungsgrad der Stufe 2 gemäß...
- Page 8 Certification ATEX Numéro de certification ATEX Baseefa12ATEX0119X Normes EN 60079-0:2012, EN 60079-15:2010 Code de certification Ex nA [op is T4] IIC T3 Gc (–40°C ≤ Ta ≤ +70°C) Code ATEX II 3G Conditions spéciales d'utilisation L'équipement doit être installé dans une zone où le degré de pollution ne dépasse pas le degré...
-
Page 9: Agency Approvals And Standards Compliance
Agency approvals and standards compliance Type Approval / Compliance EN 61000-6-1, Immunity residential environments EN 61000-6-2, Immunity industrial environments EN 61000-6-3, Emission residential environments EN 61000-6-4, Emission industrial environments EN 50121-4, Railway signalling and telecommunications apparatus IEC 62236-4, Railway signalling and telecommunications apparatus Safety UL/IEC/EN 60950-1, IT equipment Marine... -
Page 10: Declaration Of Conformity
Declaration of Conformity Westermo Teleindustri AB Declaration of Conformity The manufacturer Westermo Teleindustri AB SE-640 40 Stora Sundby, Sweden Herewith declares that the product(s) Type of product Model Industrial Ethernet 6-port Device Server Switch Lynx DSS Lx06-S2-y is in conformity with the following EU directive(s). -
Page 11: Type Tests And Environmental Conditions
Type tests and environmental conditions Environmental phenomena Basic standard Description Test levels Electrostatic discharge EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ±2 kV Ethernet Status out/Digital in Serial ports Enclosure L-L: ±0.5 kV, 2 Ω, 18 μF Surge EN 61000-4-5 Power port... - Page 12 Dielectric strength EN 60950-1 Power port to all 1.5 kVrms, 50 Hz, 1 min other ports Ethernet ports to all other ports RS-232 port to all other ports RS-422/485 port to all other ports Environmental Temperatures EN 60068-2-1 Operating –40 to +70°C (–40 to +158°F)* EN 60068-2-2 Storage and transport –50 to +85°C (–58 to +185°F)
- Page 13 Description L10-S2 EX / L206-S2 EX is an Industrial switch and device server made for harsh environments. WeOS is the operating system of L106-S2/L206-S2 enabling the unit to operate in two functional levels. The switch can be used in either 10 or 100 Mbit networks.
-
Page 14: Interface Specifications
Interface specifications Power Operating voltage Rated: 24 to 48 VDC Operating: 19 to 60 VDC Rated current 150 mA (300 mA) @ 24 VDC (with 500 mA USB load) 80 mA (150 mA) @ 48 VDC (with 500 mA USB load) Rated frequency Inrush current, I 22.7·10... - Page 15 RS-232 Electrical specification EIA RS-232 Data rate 50 bit/s – 115.2 kbit/s Data format 7 or 8 data bits, Odd, even or none parity, 1 or 2 stop bits Protocol Transparent, optimised by packing algorithm Circuit type SELV Transmission range 15 m / 49 ft Isolation to All other...
- Page 16 Connection USB receptacle connector type A Console Electrical specification LVTTL/LVCMOS-level Data rate 115.2 kbit/s Data format 8 data bits, no parity, 1 stop bit, no flow control Circuit type SELV Connection 2.5 mm jack, use only Westermo cable 1211-2027 6643-22901...
-
Page 17: Safety Control Drawing
Safety control drawing Location of interface ports and LED’s LED Indicators (for details see page 16) Power connection (for details see page 9) Position Direction* / description Output values Out / VBUS In/out / D– = 5 VDC max In/out / D+ = 500 mA max Shield RS-232, RS-422/485 (for details see page 9, 10 and 13) - Page 18 RS-422/485 (for more details see below) Signal Position Direction Description Input/Output values RS-422 RS-485 (4-wire) (2-wire) No. 1 T+/R+ Out/In RS-422: Transmit RS-485: Transmit/Receive No. 2 T– T–/R– Out/In RS-422: Transmit RS-485: Transmit/Receive U = 5 V max No. 3 R–...
-
Page 19: Connection To Console Port
The following steps needs to be taken 1. Connect the serial diagnostic cable to the console port (use only Westermo cable 1211-2027). 2. Connect cable to your computer (USB port, if drivers are needed they can be downloaded from our Web page). -
Page 20: Power Connection
Safety control drawing Power connection Product 4-position Direction Description Input values marking No. 1 +DC1 Input Supply voltage input DC1 = (19 – 60) VDC No. 2 +DC2 Input Supply voltage input DC2 = 300 mA @ 24 VDC No. 3 -COM Input Common... -
Page 21: Led Indicators
LED indicators Status Description Unit has no power. GREEN All OK, no alarm condition. Alarm condition, or until unit has started up. (Alarm conditions are configurable, see ''WeOS Management Guide''). BLINK Location indicator ("Here I am!"). Activated when connected to IPConfig Tool, or upon request from Web or CLI. - Page 22 Mounting This unit should be mounted on 35 mm DIN-rail, which is horizontally mounted inside an apparatus cabinet or similar. It is recommended that the DIN-rail is connected to ground. Snap on mounting, see figure. Mounting Lynx with integrated DIN-clip: Removal Removing Lynx with integrated DIN-clip: Press down the support at the back of the unit using a screwdriver.
-
Page 23: Getting Started
• IPConfig tool This is a custom Westermo tool used for discovery of attached Westermo units. Note! Version of IP Config tool must be 10.4.0 or higher. • Web Configuration of the unit using the web browser. -
Page 24: Referring Documents
Referring documents Type Description Document number Management Guide Westermo OS management guide 6101-3201 Factory default on L106-S2 EX / L206-S2 EX It is possible to set the unit to factory default settings by using two straight standard Ethernet RJ-45 cables. - Page 25 Dimensions Measurements are stated in millimeters. 96 ±1 52 ±1 92 ±1 6643-22901...
- Page 28 Westermo • SE-635 35 Stora Sundby, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com REV. G 6643-22901 2019-08 Westermo Network Technologies AB, Sweden...
