Euroscreen Diplomat TabTension User Manual

Hide thumbs Also See for Diplomat TabTension:

Advertisement

Quick Links

Download this manual
4 maj 2015, 16:31
Diplomat TabTension
Made in Sweden
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Diplomat TabTension and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euroscreen Diplomat TabTension

Summary of Contents for Euroscreen Diplomat TabTension

  • Page 1 4 maj 2015, 16:31 Diplomat TabTension Made in Sweden...
  • Page 3 Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation. Vi ® hoppas den kan ge er många timmar av underhållning och/eller utbild- ning, beroende på...
  • Page 4 SE För att garantin skall gälla för motoriserade dukar från Draper Europe AB måste de vara inkopplade på ett korrekt sätt. Detta uppnås förslagsvis genom att använda Draper Europe’s ”Euroscreen Control Box” (Art. 210730). Används reläboxar/reläer av andra fabrikat är det upp till kunden att funktionskraven nedan uppnås, samt att kunna bevisa korrekt funktion och inkoppling vid en eventuell tvist i ett eventuellt reklamationsärende.
  • Page 5 Assembly / Montering 150mm 150mm fig 2 It shall be approximately 150mm from the edges to the brackets (fig 2). If there are three brackets included (only larger screens) the third bracket shall be placed in the middle. fig 3 Mount the brackets on the wall (fig 3) or in the ceiling (fig 4).
  • Page 6 fig 6 fig 7 fig 9 fig 8...
  • Page 7 Adjusting the wiring / Justering av kablaget: EN: Loosen the locking nut (fig 10). Turn the connector clockwise to a maximum of 180 degrees (fig 11)! Hold the connector in place while tightening the locking nut (fig 12). SE: Lossa muttern (fig 10). Vrid kontakten medsols, max 180 grader (fig 11)! Håll kontakten i önskat läge medan du spänner muttern igen (fig 12).
  • Page 8 Usage / Användning Screen limits / Gränslägen: The screen is set at its outer limits when delivered. The upper limit shall never be set higher and the down limit never be set lower. Warning! Incorrect adjustment of the screen limits may damage the product.
  • Page 9 Lower limit / Nedre gränsläget: EN: Lower limit is set by the screw underneath the white field (fig 13). Counterclockwise increase the screen length and clockwise reduces the screen length (fig 14). SE: Nedre gränsläget ställs med skruven under det vita fältet (fig 13), där moturs ökar duklängden och medurs minskar duklängden (fig 14).
  • Page 10 Adjust tensioning / Trådjustering: EN: To keep the surface flat you may need to adjust the tensioning as the surface will change with time and temperature. This is done with the tensioning screw marked in fig 17. It is adjustable with 1/6 turn increments. Only adjust it in a single increment at a time! 1.
  • Page 11 Draper Europe AB is a member of REPA. Declaration of Conformity Draper Europe confirms that Euroscreen® Electric meets Machinery Directive 2006/95/EG & EMC Directive 2004/108/EC. This is an EN61140 Class I product with internal separation instead of protective conductor (EN61140 7.2.2 Note 2).
  • Page 12 Draper Europe AB • Västervallvägen 6 SE-302 50 Halmstad Sweden Tel: +46 35-14 42 90 • Fax: +46 35-14 42 91 info@drapereurope.se • www.drapersolskydd.se...
