2016 Elite Bubble & Jet Spa Service manual
After-sale Service Manual
Version: Elite Jet & Bubble Spa
Oriental Recreational Products (Shanghai) Co., Ltd.
MSpa website: www.the-mspa.com
-
-
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the elite jet and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for mspa elite jet

Summary of Contents for mspa elite jet

  • Page 1 2016 Elite Bubble & Jet Spa Service manual After-sale Service Manual Version: Elite Jet & Bubble Spa Oriental Recreational Products (Shanghai) Co., Ltd. MSpa website: www.the-mspa.com...

  • Page 2: Table Of Contents

    Chapter 6. Trouble Shooting Guide ........................29 6.1 The following Check Flow is as attached....................29 Premium Elite Jet & Bubble Spa check flow: No display on the control panel ..........29 Premium Elite Jet & Bubble Spa check flow: No bubbles ................29 Premium Elite Jet &...
  • Page 3 2016 Elite Bubble & Jet Spa Service manual 8.1 Attachment 1: Check flow ........................39 Premium Elite Jet & Bubble Spa check flow: No display on the control panel ..........39 Premium Elite Jet & Bubble Spa check flow: Error code E0 ................. 39 Premium Elite Jet &...

  • Page 4: Chapter 1 After-Sale Service Center Operation And Warranty Policy

    1.1.3 Provide a proper sized warehouse to store MSpa spare parts and returned defective parts from customers. 1.1.4 Have a workshop to test and repair defective spas that defect problem cannot be solved by telephone service.

  • Page 5: Mspa After-Sales Service Policy

    1.3.1 Warranty Period to MSpa Distributors Warranty Starting Date: MSpa distributor/importer warranty starts from the arrival date at destination port. For MSpa® Premium Inflatable Spa (including JB-301 and JB-304) Fifteen(15) months ( including three(3) months of storage period ) for the spa pool...
  • Page 6 Apart from key electric components, one piece of control box is to be provided as a "rolling service control box". For urgent case, MSpa distributor can send this control box to end-user to replace the defective control box. After repair the returned control box, distributor can keep it in stock for future service.

  • Page 7: Chapter 2 Important Information And Tips For Using Spa Products

    Heat Preservation Mat is helpful to avoid heat loss from bottom and it provides better heat insulation results with the inflatable bladder in use. It is recommended to have the MSpa heat preservation mats in between the spa and ground.

  • Page 8: Ensure Well Connection Of The Signal Cable Between Control Panel And Control Box

    ORPC/MSpa warranty. It is important to advise customers to watch the MSpa DVD or follow the instruction manual carefully to check and test the air pressure every single time before inflating or using the spa.

  • Page 9: Using Spa In The Cold Weather

    B0301965 Winter electric heat preservation mat is available from 2014 season. It offers great effect to retain constant temperature for Mspa use in the chilly time, fitting to all Mspa models.It is round shape, made of laminated PVC material. 220-240V, 400W, Dia.1.2m (47”) Winter sauna cover B0301687N suitable for max, 3 adults to use and fits all Mspa 4-person round products.

  • Page 10: Temperature Issue

    Water treatment Read through the “Water Quality & Filter” sections in the user manual. Always shower before entering the MSpa! To ensure a healthy spa, test your spa water chemistry and balance the pH, chlorine and alkalinity levels by using the test strip every time before using it.

  • Page 11: Where To Find The Mspa Serial Number

    2.12 Where to find the Mspa serial number? For Mspa produced before year 2014, please find Mspa serial number on the spa pool, as the left picture shows, the serial number is marked by red rectangle. Start by letters “2G BUB, 2G BUB or 2GBUB”.

  • Page 12: Chapter 3 Mspa Assembly, Wire Diagram & Major Electric Parts

    2016 Elite Bubble & Jet Spa Service manual For Mspa produced in year 2014 or after, please find the Mspa serial number on the back of control panel, as the left picture shows, the serial number is marked by red rectangle, and start by number “4”, “5” or “6”.
  • Page 13 2016 Elite Bubble & Jet Spa Service manual MSpa website: www.the-mspa.com...

  • Page 14: Mspa Major Electric Parts

    2016 Elite Bubble & Jet Spa Service manual 3.2 MSpa Major Electric Parts Transformer Ozone generator Control panel Power board Filter pump Heater element JET system Bubble generator 3.3 Wiring Diagram MSpa website: www.the-mspa.com...

  • Page 15: Chapter 4. How To Replace Mspa Electrical Parts

    2016 Elite Bubble & Jet Spa Service manual Chapter 4. How to Replace Mspa Electrical Parts 4.1 Power Board Assembly and Wire Terminal Connection 4.2 How to Replace the Filter Pump 1. Disconnect the signal cable and remove the air pipe.

  • Page 16: How To Replace The Heater Element

    4.3 How to Replace the Heater Element 1. Take off water inlet and outlet caps. 2. Remove the air pipe. The upper square valve is for inflation The button round valve is for deflation 3. Deflate spa pool. 4. Unscrew the check valve plastic nut. MSpa website: www.the-mspa.com...
  • Page 17 12. Unplug heater elements cables on the power board. lid. 13. Unscrew four screws that place heater elements 14. Take out the original heater elements from the onto the control box. And Unplug the cable connection control box and assemble the new heater elements in MSpa website: www.the-mspa.com...

  • Page 18: How To Replace The Power Board

    3. Deflate spa pool 4. Unscrew the check valve plastic nut 5. Cut off the tie of ozone pipe. 6. Unplug Ozone generator pipe. 7. Take out control box from spa pool. 8. Loosen four screws on the top lid. MSpa website: www.the-mspa.com...

  • Page 19: How To Replace The Bubble Generator

    9. Disconnect all electrical cables from the original power board and connect all cables to the new power board correctly and assemble the power board into the control box in reverse order. 4.5 How to Replace the Bubble Generator MSpa website: www.the-mspa.com...
  • Page 20 5. Cut off the tie of ozone pipe. 6. Unplug Ozone generator pipe. 7. Take out control box from spa pool. 8. Remove the foam. 9. Loosen four screws on the top lid. 10.Disassemble the mid part of the control box MSpa website: www.the-mspa.com...

  • Page 21: How To Replace The Check Valve

    15. Take out the original bubble generator from the control box and assemble the new one in reverse order 4.6 How to Replace the Check Valve 1. Remove the air pipe 2. Turn the control box inside the spa pool upside down MSpa website: www.the-mspa.com...

  • Page 22: How To Replace The Transformer

    5. Assemble the new check valve by screws. 6.screw the nut of spa pool 4.7 How to Replace the Transformer 1. Take off water inlet and outlet caps. 2. Remove the air pipe. The upper square valve is for inflation The button round valve is for deflation 3. Deflate spa pool. 4. Unscrew the check valve plastic nut. MSpa website: www.the-mspa.com...
  • Page 23 11. Loosen four screws on the power board case top 12. Cut off the ties on the board. lid. 14. Unscrew the screws that fix the transformer onto the 13. Unplug transformer cables on the power board. control box. MSpa website: www.the-mspa.com...

  • Page 24: How To Replace The Ozone Generator

    1. Take off water inlet and outlet caps. 2. Remove the air pipe. The upper square valve is for inflation The button round valve is for deflation 3. Turn the spa pool upside down and deflate spa pool. 4. Unscrew the check valve plastic nut. 5. Cut off the tie of ozone pipe. 6. Unplug Ozone generator pipe. MSpa website: www.the-mspa.com...
  • Page 25 11. Loosen four screws on the power board case top lid. on the power board. 13. Unscrew the screws that fix the outlet pipes. 14. Unscrew the filter pump plastic nut 15. Unscrew the screws that fix the Ozone generators. 16. Take out the Ozone generator from control box MSpa website: www.the-mspa.com...

  • Page 26: How To Replace The Jet System

    4. Use wrench to screw these 3 outlet/inlet The upper square valve is for inflation The button round valve is for deflation 5. Turn the spa pool upside down and deflate spa pool. 6. Take out JET system box from spa pool. 7. Unscrew the screws of base. 8. Unscrew the screws of base. MSpa website: www.the-mspa.com...

  • Page 27: Chapter 5. How To Replace Spa Pool

    2. Unscrew air vale to deflate spa pool. 3. Use wrench to screw these 3 pieces of Jet spray 4. Take off water inlet, outlet and ozone caps. 5. Unscrew the screws of air valve. 6. Unscrew the nut of air valve. MSpa website: www.the-mspa.com...
  • Page 28 11. Pull out wires from the end of Jet system 12. Cut off the tie of ozone pipe. 13. Unplug Ozone generator pipe. 14. Take out control box from spa pool. 15. Change a new spa pool and fix all spare parts inverted. MSpa website: www.the-mspa.com...

  • Page 29: Chapter 6. Trouble Shooting Guide

    Chapter 6. Trouble Shooting Guide 6.1 The following Check Flow is as attached. Premium Elite Jet & Bubble Spa check flow: No display on the control panel Premium Elite Jet & Bubble Spa check flow: No bubbles Premium Elite Jet & Bubble Spa check flow: Heating problem Premium Elite Jet &...
  • Page 30 Screw up the pipe tightly or pipes and filter pump is re-glue the connecting pipes loose 3. Water leaks from the control box Replace the broken 3.2 Connecting pipes connecting pipes or filter and filter pump is pump. broken. MSpa website: www.the-mspa.com...

  • Page 31: Air Leakage And Inflation Failure Checking Flow Chart

    3-person spa weighs about 2500 pounds filled with water. On the plus side, you will have privacy and convenience. Your unit and cover will also be fully protected from the weather. 1.2. What is needed to prepare a site for Mspa? Question: MSpa website: www.the-mspa.com...
  • Page 32 If a site does in fact have hardy types of grass it is recommended to remove these grasses before initial set up. Do not set up Mspa in a place where it can be flooded with water.
  • Page 33 Before entering the spa tub, users should measure the water temperature with an accurate thermometer since the tolerance of water temperature regulating devices may vary as much as +/- 2 ℃ ( 5 ℉ ). 3.6. If turned off at night time, how much will the temperature drop? Question: MSpa website: www.the-mspa.com...
  • Page 34 Question: Answer MSpa can leave outside in light rain as it is of IPX5, protection against harmful ingress of water. But we do not suggest people use it with bubbling open because the water may cause air pump damped and rusted which could result the air pump works improperly and will void your warranty.
  • Page 35 The hole(s) on the surface of filter cartridge is a security to make sure there is always minimum water flow to avoid damage to heater and pump when filter cartridge would be blocked. MSpa doesn’t have cover or bag for the filter cartridge anymore Part Seven: Safety Issue 7.1.
  • Page 36 2016 Elite Bubble & Jet Spa Service manual Part Eight. Maintance on the Mspa Pool 8.1. Does the spa pool require any special care to ensure durability? Question: Answer: Keep sharp objects out of the spa pool or from underneath of the spa pool. Maintain proper PH level of water and keep the spa sanitary and clean.
  • Page 37 Answer: If looked after, your MSpa should last for years. The blower of bubble has a lifetime. MSpa blower is Quieter & more durable than like product for > 200 Hours – equal to 600 times of use. For your health concern, MSpa has the auto break design, sets the bubble function for every 20 minutes and auto stop for 10 minutes break.
  • Page 38 10.7. How much does it cost to run? Question: Answer: With a full function and half an hour use, the MSpa will cost approximately ￡5 or €3.2 per day. Each function on the pump/uses the following: Massage: 0.5-0.72kW/hr Filter: 0.035-0.06kW/hr Heater: 6.75-1.5kW/hr...

  • Page 39: Chapter 8. Attachment

    Chapter 8. Attachment 8.1 Attachment 1: Check flow Premium Elite Jet & Bubble Spa check flow: No display on the control panel Premium Elite Jet & Bubble Spa check flow: Error code E0 Premium Elite Jet & Bubble Spa check flow: Error code E1 Premium Elite Jet &...
