MODEL 5495
Distributed Power Module
Document 151161
Rev P
P
151161:
ECN 17-0298
Installation and
Operations Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5495 and is the answer not in the manual?

Questions and answers

Shawn Brown
February 7, 2025

The 5495 fa panel has power but will not turn on

0
1 comments:
Mr. Anderson
February 10, 2025

The SILENT KNIGHT 5495 may not turn on despite having power due to several possible reasons:

1. Trouble Relay Activation: If the trouble relay detects a fault, it may deactivate, preventing operation.
2. Incorrect DIP Switch Settings: Incorrect configuration of DIP switches, such as Switch 5 for auxiliary power, may cause issues. The unit only checks these settings during power-up, so power must be completely removed and restored after changes.
3. Wiring Issues: Improper wiring, especially with the control panel or notification appliances, can prevent the unit from functioning. Consulting the installation manual is necessary for correct wiring.
4. Loss of AC Power: If the unit is set to delay reporting AC loss (default 6 hours), the issue may not be immediately apparent. Testing mode (Switch 4 ON) can confirm AC power status.

Checking these factors can help diagnose why the panel is not turning on.

This answer is automatically generated

0

Related Manuals for SILENT KNIGHT 5495

Summary of Contents for SILENT KNIGHT 5495

  • Page 1 MODEL 5495 Distributed Power Module Document 151161 Rev P 151161: ECN 17-0298 Installation and Operations Manual...

  • Page 3: Table Of Contents

    Contents Section 1 Introduction ..............................1 Section 2 UL Requirements ..........................1 Section 3 System Overview ..........................2 Terminal Descriptions and Electrical Ratings ................2 Signal Input Terminals ......................... 2 Notification Appliance Circuit Terminals ..................3 Section 4 Installation ..............................5 Mounting ............................5 4.1.1 Preventing Water Damage ....................5 Wire Routing ..........................
  • Page 4 Model 5495 Distributed Power Module Installation Manual 4.8.4 Setting the Auxiliary Output ....................17 Section 5 Sample Applications ........................18 Notification Power Applications ....................18 Non-Resettable Power Application ....................20 Door Holder Application ......................21 Section 6 Troubleshooting ..........................21 LEDs ............................21 Trouble Conditions ........................22 Earth Fault Resistance ......................23 Removing and Replacing the Control Panel ................23...

  • Page 5: Introduction

    Section 1 Introduction The 5495 is a notification appliance circuit and auxiliary power expander that provides up to 6 amps of filtered, 24 volt power for powering notification appliances and auxiliary devices. The 5495 provides its own AC power connection, battery charging circuit, and battery connections. Used with security and fire alarm control panels, the 5495 enables you to connect and distribute power to many more devices than your panel may normally allow.

  • Page 6: System Overview

    151161 Section 3 System Overview CAUTION Each output circuit is rated at 3 amps. DO NOT OVERLOAD. Overloading a circuit will cause it to shut down (power limit). The circuit will automatically reset once you remove the overload condition. Terminal Descriptions and Electrical Ratings Terminal # Description Ratings...

  • Page 7: Notification Appliance Circuit Terminals

    Terminals 3 through 10 are the notification appliance circuit output terminals. Each of the four circuits are rated at 3 amps, although you can only draw a total of 6 amps from the 5495. The 5495 outputs are short-circuit protected (power limited) according to UL 864 standards. Overcurrent indicators are yellow LEDs. The output voltage can vary depending on the load and input voltage.
  • Page 8 151161 For Option: These Inputs: Control These Outputs: Input 1 or Outputs 1, 2, 3, and 4 Class B ANSI temporal- Input 2 coded circuits Input 1 Outputs 1 and 2 Class B circuits Input 2 Outputs 3 and 4 Class B circuits Input 1 Output 1...

  • Page 9: Installation

    Section 4 Installation Before installing the 5495, the AC input must first be wired into the building’s main electrical power through the TB1 terminals (see Figure 4-2). Shut off the electrical power to the 5495, and then complete the general installation of the 5495 using the information in this section.

  • Page 10: Current Requirements (Standby And Alarm)

    Batteries used with the 5495 must not exceed 35AH. (33AH max. for FM (Factory Mutual) Installations). Batteries larger than 7 AH will not fit into the 5495 cabinet and must be housed in the RBB Remote Battery Box. See Section 4.7 for battery installation.
  • Page 11 The above numbers were calculated assuming the use of 7 AH batteries at 100% of rated capacity. The total current of the 5495, plus all items powered from it, must not exceed 6 A when the panel is in alarm. Use Table 4-2 to ensure that the current does not exceed 6 A and, that the desired amount of standby is possible for the battery intended for use with the 5495.
  • Page 12 Current per Device Devices Current Current For each device use this formula: This column X This column Current per number of devices. 5495 Distributed Power Module Standby: 75 mA 75 mA Alarm: 205 mA 205 mA (Current draw from battery)

  • Page 13: Connecting The 5499 To A Control Panel

    Common Trouble Relay The 5495 has a Form C trouble relay built into Terminals 11-13. The relay provides a normally open and a normally closed contact, both of which are rated at 2.5A. The trouble relay will deactivate under any trouble condition.

  • Page 14: Notification Appliance Wiring

    5495 board. Pay close attention to the polarities when wiring a panel to the 5495 and follow these requirements: • When wiring to Terminal 18 on the 5495, you must use two separate wires. Do not loop a single wire or twist 4-10...

  • Page 15: Class B Supervised Wiring

    Class B Supervised Wiring Figure 4-5 shows how to wire for Class B input and output supervision. Use in/out wiring methods for proper supervision (Refer to the Appendix for notification appliances approved for use with the 5495.) Class B Output Notification Circuits Figure 4-5 shows four, 1.5 A devices wired as Class B.

  • Page 16: Class B Supervised Input Circuits

    Use an EOL resistor as shown to enable notification appliance circuit input supervision. Some panels use EOLs that have a different value from the 4.7k ohm EOL resistor used by the 5495. In this case, the EOL must be UL listed for the fire alarm control panel (not the 5495).

  • Page 17: Dip Switch Settings

    The position of Switches 4 and 5 does not affect the relationship of inputs to outputs. Note: The 5495 checks switches 1, 2, 3, and 6 only when powering up the 5495. If you change these switch settings, you must 4-13...

  • Page 18: Input/Output Configurations That Select Ansi Temporal-Coded Outputs

    151161 remove both the AC power and the battery to make the 5495 recognize the new settings. Figure 4-7 Setting DIP Switches 1-3 Figure 4-8 Setting DIP Switches 1-3 (Continued) Note: For 100 mS input signal debounce with no synchronization DIP switches 6 and 7 must be turned On.

  • Page 19: Selecting Synchronized Output Configurations

    The 5495 can also produce temporal patterns if the inputs are non-ANSI temporal configurations. 4.8.2 Selecting Synchronized Output Configurations The following sections describe how to configure the 5495 as a synchronization power expander for Amseco, Faraday, Gentex, System Sensor, or Wheelock synchronized horn/strobe appliances. Note: In order for the synchronization feature to operate properly, make sure you have set the DIP switches for the proper manufacturer.

  • Page 20: Selecting Synchronized Gentex Configurations

    151161 4.8.2.2 Selecting Synchronized Gentex Configurations To select the input/outputs for Gentex synchronized appliances, set the DIP switches as shown in Figure 4-10. Figure 4-10 Gentex Synchronized Configurations 4.8.2.3 Selecting Synchronized System Sensor Configurations To select the input/outputs for System Sensor synchronized appliances, set the DIP switches as shown in Figure 4-11.

  • Page 21: Selecting Synchronized Amseco Configurations

    Switch 5 on the DIP switch determines how the auxiliary power operates on the 5495. The 5495 checks Switch 5 only when powering up the 5495. If you change this switch, you must remove both the AC power and the battery to force the 5495 to recognize the new switch setting.

  • Page 22: Sample Applications

    151161 Section 5 Sample Applications The drawings in this section show various 5495 configurations, including “daisy-chaining”. Notification Power Applications 5495 Local Fire Alarm Control Panel Figure 5-1 Input 1 Activates All Four Outputs 5495 Local Fire Alarm Control Panel Figure 5-2 Input 1 Activates NACs 1 and 2; Input 2 Activates NACs 3 and 4...
  • Page 23 Model 5495 Distributed Power Module Installation Manual Note: When multiple power supplies are used with one control unit they will not sync with each other 5495 Local Fire Alarm Control Panel 5495 Figure 5-3 One Control Activating Two 5495s 5495...

  • Page 24: Non-Resettable Power Application

    Non-Resettable Power Application The 5495 provides a dedicated 3 A auxiliary power output that you can select as non-resettable (output is always on). See Section 4.8.4 for setting the auxiliary power. If you need more than 3 A, wire the inputs as shown in Figure 5-6.

  • Page 25: Door Holder Application

    Model 5495 Distributed Power Module Installation Manual Door Holder Application In a typical door holder application, the door holder power must be interrupted to close all fire doors under the following conditions: • Any active alarm condition. • AC power failure (to conserve battery power).

  • Page 26: Trouble Conditions

    151161 Color Description BATT Yellow When ON, a low battery condition exists. Green When OFF, there is no AC power to the unit. Under normal conditions, this LED is ON to indicate the presence of AC power. See Figure 4-2 for locations of LEDs. Trouble Conditions Trouble Condition What Happens...

  • Page 27: Earth Fault Resistance

    Model 5495 Distributed Power Module Installation Manual Earth Fault Resistance Table 6-1 lists the earth fault resistance detection for each applicable terminal on the FACP. Table 6-1: Earth Fault Resistance Values by Terminal Terminal Value Function Terminal Label Number (in kohms)

  • Page 28: Replacing The Control Panel

    151161 Remove the two heat sink screws. The heat sink screws are located on the top of the cabinet. See Figure 6-1. Figure 6-1 Mounting Screw Locations Remove the four chassis mounting screws. See Figure 6-1 for chassis screw locations. Carefully remove the control panel.
  • Page 29 Synchronization is UL listed for multi-circuit operation. Notification Appliances Table A-1 below lists notification appliances compatible with the 5495. Appliances which can be synchronized indicate the type of sync available in the columns marked Audio and/or Visual.

  • Page 30: Ul Listed Notification Appliances

    Model 5495 Distributed Power Module Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Vibrating Bell Vibrating Bell Single Stroke Bell 2700 -M. -R, -T, -Y, -Z Strobe 2701 Series Strobe 2705 Series Strobe 2820 Snyc Temporal Horn/Strobe...
  • Page 31 151161 UL Listed Notification Appliances Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type 5378 8-Tone Horn/Strobe 5383 8-Tone Horn/Strobe with Sync Strobe 5386 8-Tone Horn/Strobe with Sync Strobe 5387 8-Tone Horn/Strobe with Sync Strobe 5388 8-Tone Horn/Strobe with Sync Strobe 5508 Single Gang Sync Strobe 5509...
  • Page 32 Model 5495 Distributed Power Module Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type S2415-FC Strobe S241575-FC Strobe S2430-FC Strobe 130-3117C Mini Horn 130-3147C Mini Horn BLV-6 Vibrating Bell BLV-10 Vibrating Bell BLVCH Vibrating Chime H12/24-FC Horn...
  • Page 33 151161 UL Listed Notification Appliances Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type GEC-24-15 Horn/Strobe GEC-24-30 Horn/Strobe GEC-24-60 Horn/Strobe GEC-24-75 Horn/Strobe GEC-24-177 Horn/Strobe Gentex GEC-24-110 Horn/Strobe GEC-24-15/75 Horn/Strobe GX91 MiniHorn Steady Tone GX93 MiniHorn Temporal Tone HG124 Horn HS24-15 Horn/Strobe HS24-30...
  • Page 34 Model 5495 Distributed Power Module Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type Chime Chime CHSR 2-Wire Chime/Strobe CHSW 2-Wire Chime/Strobe Horn Horn Horn Horn WHT Wall 4x4 Horn Red Wall 4x4 HGRL Horn Red Wall 2x4...
  • Page 35 151161 UL Listed Notification Appliances Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type 4-Wire Horn/Strobe PC4W 4-Wire Horn/Strobe P4WH 4-Wire Horn/Strobe High Candela PC4WH 4-Wire Horn/Strobe High Candela P4RK 4-Wire Horn/Strobe PC4RK 4-Wire Horn/Strobe P4RHK 4-Wire Horn/Strobe High Candela PC4RHK 4-Wire Horn/Strobe High Candela PC4RH...
  • Page 36 Model 5495 Distributed Power Module Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type SCRHK Strobe High Candela SRL, SRL-P, SRL-SP* Strobe Red Wall 4x4 SWL, SWL-P, SWL-ALERT Strobe White Wall 4x4 SWL-CLR-ALERT* SCRL Strobe Red Ceil 4x4...
  • Page 37 151161 UL Listed Notification Appliances Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type HS-24 Horn HS4-241575W Horn/Strobe HS4-24MCW Horn/Strobe HS4-24MCWH Horn/Strobe HS4-24MCC Horn/Strobe MIZ-24S Mini Horn Strobe MT-121575W MultitoneHorn Strobe MT-241575W Multitone Horn Strobe MT-24MCW Multitone Horn Strobe MTWP-2475W Multitone Horn Strobe MTWP-2475C...
  • Page 38 Model 5495 Distributed Power Module Installation Manual Table A-1: Compatible Notification Appliances Manufacturer Model Audio Visual Type RSSR-2475W Strobe RSSR-2475C Strobe RSSR-24110C Strobe RSSA-24110W Strobe RSSB-24110W Strobe RSSG-24110W Strobe RSSR-24110W Strobe RSSA-24MCC Multi-Cd Strobe RSSB-24MCC Multi-Cd Strobe RSSG-24MCC Multi-Cd Strobe...
  • Page 39 UPS ground. • Return the Honeywell Silent Knight product circuit board only. Products that are returned in cabinets will be charged an additional $50 to cover the extra shipping and handling costs over board only returns. Do not return batteries.

  • Page 40: Manufacturer Warranties And Limitation Of Liability

    • Repairs and returns should be sent to: Honeywell Fire Systems Attn: Repair Department / RA Number_______________________ 12 Clintonville Road Northford, CT 06472 USA Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
  • Page 42 Silent Knight 12 Clintonville Road Northford, CT 06472-1610 203-484-7161 Fax: 203-484-7118 www.silentknight.com...
