MICROWAVE OVEN
Installation & User Instructions
IMPORTANT
• WARNING: if the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person;
• WARNING: it is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy;
• WARNING: liquids and other food must not be heated in a sealed
container since they are liable to explode;
• WARNING: only allow children to use the oven without supervision when
adequate instruction have been given so that the child is able to use the
oven in a safe way and understands the hazards of improper use.
• WARNING: accessible parts may become hot during use. Young children
should be kept away.
CAREFULLY RETAIN THESE INSTRUCTIONS
–
Please keep for future reference
295/5081
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Morphy Richards MM820CXN-PM0F
Summary of Contents for Morphy Richards MM820CXN-PM0F
- Page 1 MICROWAVE OVEN Installation & User Instructions 295/5081 – Please keep for future reference IMPORTANT • WARNING: if the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person; • WARNING: it is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy;...
-
Page 2: Table Of Contents
Contents Safety Information Materials you can use in microwave oven Materials to avoid using in the microwave oven tensils Setting Up your Oven Oven components and accessories Turntable installation Microwave cooking principle Microwave Food Packaging Symbols Accessories included Installation 10-11 Please Note Electrical connection Earthing installation Operating your microwave oven... -
Page 3: Safety Information
Safety Information Important – Please read these instructions fully before installation IMPORTANT SAFETY INSTRUTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE 1. The temperature of accessible surfaces may get hot when the appliance is operating especially the metal top area and the warming rack if any. 2. - Page 4 Safety Information Important – Please read these instructions fully before installation 6. The appliance is not intended to be operated by means of an external timer or separate remote- control system. 7. The appliance is intended to be used in household and similar applications such as : - staff kitchen areas in shops, offices and other working environment;...
- Page 5 Safety Information Important – Please read these instructions fully before installation 12. Only use utensils that are suitable for use in microwave ovens. 13. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
- Page 6 Safety Information Important – Please read these instructions fully before installation 20. Failure to maintain the oven in a clean condition could lead to deterioration of the surface which could adversely affect the life of the appliance and possibly result in a hazardous situation.
- Page 7 Safety Information Im p ortant – Please read these instructions full y before installation 29. If the supply cord or plug is damaged, or if the oven is The oven must be placed on a level surface. not working properly or has been dropped it must be The turntable and turntable ring assembly must always replaced or repaired by the manufacturer or its service be used in the oven during cooking.
-
Page 8: Materials You Can Use In Microwave Oven
MATERIALS YOU CAN USE IN MICROWAVE OVEN Utensils Remarks Shielding only. Small smooth pieces can be used to cover thin parts of meat or poultry Aluminium foil to prevent overcooking. The foil should be a least 1 inch Arcing can occur if foil is (2.5cm) away from oven walls. -
Page 9: Setting Up Your Oven
Setting Up Your Oven OVEN COMPONENTS AND ACCESSORIES fig.1 Remove the oven and all materials from the carton. TURNTABLE INSTALLATION fig. 2 Warning : Do not remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron. -
Page 10: Microwave Cooking Principle
Setting Up Your Oven Microwave cooking principles 1. The microwaves generated by the magnetron are evenly distributed through the food as the glass turntable revolves. This ensures that the food is cooked uniformly . 2. The microwaves are absorbed by the food up to a depth of approximately 1 inch (2.5cm). Cooking continues as the heat is dissipated through the food. -
Page 11: Installation
Installation Please Note Electrical connection The oven is fitted with a plug and must be only connected to a properly installed earthed socket. In accordance with the appropriate regulations, the socket must only be installed and the connecting cable must only be replaced by a If the plug is qualified electrician. -
Page 12: Earthing Installation
Installation EARTHING INSTALLATION DANGER Check that the voltage marked on the product corresponds with your supply voltage. Electric Shock Hazard This product is fitted with a 13 A plug complying with BS1363. Touching some of the internal components lf this plug is unsuitable or needs to be replaced, please note can cause serious personal injury or death. -
Page 13: Operating Your Microwave Oven
OPERATING YOUR MICROWAVE OVEN CONTROL PANEL AND FEATURES 1. Set the cooking power by turning the power selection knob to desired level. 2. Set the time of cooking by turning the timer knob to desired time per your food cooking Power guide. - Page 14 OPERATING YOUR MICROWAVE OVEN Microwave cooking Turn power selection dial Set microwave cooking time by to Microwave cooking turning timer dial. To set a time position. less than 1 min turn the control past the required setting, and then move the control back. 1.
-
Page 15: Cleaning Your Microwave Oven
CLEANING YOUR MICROWAVE OVEN Attention Your microwave oven should be cleaned regularly to prevent grease and food particles from building up on the inside surface. The accumulated grease / food particles may cause a fire hazard. It is important to clean the interior of your microwave oven after each use. To clean the oven interior, use a mild detergent solution, such as washing-up liquid, with warm water on a soft cloth. -
Page 16: Troubleshooting And Maintenance
Troubleshooting and maintenance NORMAL CONDITION Microwave oven interfering with TV reception. Radio and TV reception may be interfered with when microwave oven is in operation. It is similar to the interference of small electrical appliances such as food mixers, vacuum cleaners and electric fans. This is normal. Oven light dim. -
Page 17: Questions And Answers
Questions And Answers Q: When the oven is plugged into a wall outlet for the first time, it does not work properly. What's wrong? A: The microcomputer used in the oven control may temporarily become scrambled and fail to function as programmed. Unplug the oven from the wall outlet and then plug it back in. -
Page 18: Technical Specifications
Technical Specifications MM820CXN-PM0F Model Power Source: 230-240 V~50Hz Microwave Power Consumption: 1200-1270 Watt Maximum Output: 750-800 Watt Oven Capacity: 20 litres Turntable Diameter: Ø 255 mm External Dimensions (L x W x H): 440mm x 324mm x 258mm Net Weight: Approx. -
Page 19: Guarantee
Guarantee PRODUCT GUARANTEE This product is guaranteed against manufacturing defects for a period of Year This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible during this period by the dealer from whom you purchased the unit.
