EVID Compact Sound Speaker System
EVID-C44, EVID-C2.1, EVID-40C, EVID-S44, EVID-S44W, EVID-2.1, EVID-2.1W, EVID-40S, and
EVID-40SW
en | Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVID-C44 and is the answer not in the manual?

Questions and answers

Summary of Contents for Electro-Voice EVID-C44

  • Page 1 EVID Compact Sound Speaker System EVID-C44, EVID-C2.1, EVID-40C, EVID-S44, EVID-S44W, EVID-2.1, EVID-2.1W, EVID-40S, and EVID-40SW en | Installation Manual...
  • Page 3: Table Of Contents

    Surface mount speakers 5.2.1 Wattage tap 5.2.2 70v/100v/4 ohm Mono 5.2.3 8 ohm Stereo Surface Mount Subwoofer Only Troubleshooting Technical data Ceiling mount speakers 7.1.1 Frequency response Surface Mount Speakers 7.2.1 Frequency response Notes Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 4: Safety

    Suspending any object is potentially dangerous and should only be attempted by individuals who have a thorough knowledge of the techniques and regulations of suspending objects overhead. Electro-Voice strongly recommends all loudspeakers be suspended taking into account all current national, federal, state, and local laws and regulations. It is the responsibility of the installer to ensure all loudspeakers are safely installed in accordance with all such requirements.
  • Page 5 (in accordance with the European Waste Electrical and Electronic Equipment Directive). To dispose of old electrical or electronic devices, you should use the return and collection systems put in place in the country concerned. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 6: Introduction

    Attractive subwoofer design with full-face grille—install it anywhere, no need to hide! ▪ Supports stereo operation with 8-ohm audio connections. ▪ Quick-mount slide-on wall bracket included. ▪ Available in black or white finishes. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 7: System Overview

    The major components included in one (1) box for the EVID C2.1 ceiling mount satellite speaker. Item Quantity Description EVID C2.1 ceiling mount satellite speakers Grilles C-ring supports Cutout template Engineering data sheet Paint shields Table 3.1: Ceiling Mount Satellite Speaker Figure 3.1: Components in kit Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 8 The major components included in the box for the EVID 40C ceiling mount subwoofer: Item Quantity Description EVID 40C ceiling mount subwoofer Tile rails C-ring support Grille Installation manual screws Cutout template Paint shield Table 3.2: Ceiling Mount Subwoofer Figure 3.2: Components in kit 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 9 Wall brackets Speaker brackets Engineering Data Sheet M6 hex drive pan-head screws M5 pan-head screws Screw sockets Hex wrench Table 3.3: Surface Mount Satellite Speaker (1 box) Figure 3.3: Components in kit Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 10 Description EVID 40S surface mount subwoofer Wall bracket, assembled in box Installation Manual M6 hex drive pan-head screw Rubber feet Hex wrench Table 3.4: Surface Mount Subwoofer Figure 3.4: Components in kit 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 11: Product Information

    Product information Ceiling mount speakers Figure 3.5: EVID C2.1 Product Information Figure 3.6: EVID 40C Product Information Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 12 EVID Compact Sound Speaker System Surface mount speakers Figure 3.7: EVID 2.1 Product Information Figure 3.8: EVID 40S Product Information 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 13: Dimensions

    Dimensions Ceiling mount speakers Figure 3.9: Dimensions EVID C2.1 Figure 3.10: Dimensions EVID 40C Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 14 Surface mount speakers Figure 3.11: Dimensions EVID 2.1 and mounting bracket Figure 3.12: Dimensions EVID 40S and mounting bracket Notice! The mounting bracket dimension drawings are not to scale. Drawing sizes increased for readability. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 15: Installation

    Consult an expert if you are unsure. Installing a ceiling mount satellite speaker To install a ceiling mount satellite speaker, do the following: Trace the cutout template. Cut the hole. Attach the C-Ring. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 16 Install wires into the Phoenix connector. Tighten the two (2) screws to secure the conduit clamp. Attach the safety cable. The safety cable should be installed with a minimum of a 3-inch (76.2 mm) slack. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 17 Push the speaker up into the ceiling. Tighten the mounting tabs. 10. Attach the grille. 11. Installation complete. For more information, see Safety. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 18: Ceiling Mount Subwoofer Installation

    Consult an expert if you are unsure. Installing a ceiling mount subwoofer To install a ceiling mount subwoofer, do the following: Trace the cutout template. Cut the hole. Secure rails to the C-Ring. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 19 Attach the safety cable to the auxiliary support tab. Route wires through the ceiling to the conduit clamp. Connect the wires to the Phoenix connectors. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 20 EVID Compact Sound Speaker System Plug the phoenix connector into the socket. Tighten the two (2) screws to secure the conduit clamp. Push the speaker up into the ceiling. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 21 12. Attach the auxiliary support line to the structure. The safety cable should be installed with a minimum of a 3-inch (76.2 mm) slack. 13. Installation complete. For more information, see Safety. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 22: Surface Mount Speakers

    Place the speaker bracket onto the wall bracket. Using the hex wrench (supplied), tighten the M6 hex drive pan-head screw to secure the speaker bracket to the wall bracket. For more information, see Safety, page 4. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 23: Wall Bracket Range Of Motion

    Only mount the wall bracket in the vertical V-shape position. Do not mount the V-bracket or wall bracket side ways or upside down. Figure 4.2: Wall bracket correct and incorrect mounting positions Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 24 Using a Phillips head screwdriver (not supplied), tighten six (6) M5 pan-head screws (not supplied) to attach the wall bracket to a secure mounting surface. Using the hex wrench (supplied), tighten the three (3) M6 hex drive pan head screws to attach the V-bracket. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 25: Removing Subwoofer From The Wall

    4.2.4 Removing subwoofer from the wall To remove the subwoofer from the wall, do the following: Pull the subwoofer slightly out from the wall. Lift the subwoofer up. The locking detents disengage. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 26: Wiring

    50 W, 25 W, and 12.5 W at 70V or 100 W, 50 W, and 25 W 100V. The power selector switch is located on the baffle behind the grille. Figure 5.1: EVID 40C Wattage Tap 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 27: 70V/100V/4 Ohm Mono

    Any combination of four satellites (surface mount, ceiling or pendant speakers) is allowed. The system is designed for operation with only four (4) satellite speakers. Operation with less than four (4) satellite speakers is not recommended. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 28: Surface Mount Speakers

    100V, as well as a 4 ohm transformer bypass setting. A guide on the input panel shows which switch positions to use for the power settings at 70V and 100V. Figure 5.2: EVID 40S wattage tap 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 29: 70V/100V/4 Ohm Mono

    Any combination of four satellites (surface mount, ceiling or pendant speakers) is allowed. The system is designed for operation with only four (4) satellite speakers. Operation with less than four (4) satellite speakers is not recommended. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 30: Ohm Stereo Surface Mount Subwoofer Only

    (4) satellite speakers is not recommended. Notice! A standard low impedance (4/8 ohm) amplifier source is required when operating the unit in STEREO mode. 100/70v operation is not supported in STEREO mode. 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 31: Troubleshooting

    Poor System Check and correct the system grounding, as required. Grounding or Ground Loop If these suggestions do not solve your problem, contact your nearest Electro-Voice dealer or Electro-Voice distributor. Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 32: Technical Data

    Long Term Program Rating, 3 dB greater than continuous noise pink noise rating. Average 1 kHz – 4 kHz. Average 1 kHz – 8 kHz. 7.1.1 Frequency response EVID C2.1 Half Space EVID 40C Half Space 1000 10000 20000 Frequency (Hz) 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 33: Surface Mount Speakers

    Half space (wall mounting). Long Term Program Rating, 3 dB greater than continuous noise pink noise rating. Average 1 kHz – 4 kHz. Average 1 kHz – 8 kHz. 7.2.1 Frequency response Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
  • Page 34: Notes

    EVID Compact Sound Speaker System Notes 2015.12 | 07 | F.01U.310.295 Installation Manual Electro-Voice...
  • Page 35 Electro-Voice Installation Manual 2015.12 | 07 | F.01U.310.295...
