Fender Standard Jazz Bass V Assembly

Control assembly

Hide thumbs Also See for Standard Jazz Bass V:

Download this manual

BLACK WIRE FROM

NECK P.U. GOES TO

BACK OF POT

WHITE(YELLOW)

WIRE FROM NECK

P.U. GOES TO MIDDLE

TERMINAL

BLACK WIRE

FROM BRIDGE P.U.

GOES TO BACK OF POT

WHITE(YELLOW) WIRE

FROM BRIDGE P.U.

GOES TO MIDDLE TERMINAL

GROUND WIRE FROM

BRIDGE

STD. JAZZ BASS V 0136600

CONTROL ASSEMBLY

BRIDGE ASSEMBLY

.05 MFD

Pg. 2 of 4

11-11-99
