Fender Stevie Ray Vaughan Parts List

STEVIE RAY VAUGHAN STRATOCASTER 0109200
P/N
REF.#
1 0038922000 Neck, Stevie Ray Vaughan Stratocaster, R/W
2 0027702000 Tuning Key, (1) Set
0018823000
0027703000
3 0083675000 Bone Nut
4 0018803000 String Retainer
0018823000
5 0012252000 Truss Rod Adjustment Nut
6 0038918xxx Body, Stevie Ray Vaughan Strat, Sunburst
7 0038957000 Neck Mounting Plate
0018785000
8 0018916000 Strap Button
0018789000
0019056000
9 0038930000 Pickguard, Black, Stevie Ray Vaughan Strat
0018784000
10 0038931000 Pickup, Neck, Texas Special
11 0038932000 Pickup, Middle, Texas Special
12 0038933000 Pickup, Bridge, Texas Special
0027705000
0036481000
13 0013446000 Control, 250K, (3)
0016352000
0022384000
14 0056149000 Knob, Volume, White
15 0056148000 Knob, Tone, White (2)
16 0053291000 Switch, Lever 5-Position
0027705000
0019554000
17 0024832000 Capacitor, .022uf
18 0012869000 Solder Lug
0015116000
19 0021956000 Output Jack
0018824000
0016436000
20 0010280000 Jack Ferrule
0018784000
21 0038959000 Bridge Assy, Vintage Strat
0018787000
0010272100 Tremolo Claw
0015636000
0031643000
0039482000 Tremolo Arm
0019463000
22 0012180000 Spring, Tremolo Arm
23 0038960000 Bridge Plate
0038962000
0038969000
24 0038961000 Bridge Section, (6)
25 0017031000 Intonation Screw, (6)
0019395000
0019394000
26 0026780000 Height Adjustment Screw, 1&6
0038973000
27 0038949000 Back Plate, Tremolo, Black/White Black
0018784000
DESCRIPTION
Mounting Screw
Bushing
Mounting Screw
Mounting Screw
Mounting Screw
Felt Washer, Black
Mounting Screw
Mounting Screw
Tubing, Latex Cut
Mounting Hex Nut
Lock Washer, Intl
Mounting Screw
Knob, White
Mounting Screw
Mounting Hex Nut
Lock Washer, Intl
Mounting Screw
Mounting Screw
Mounting Screw
Tremolo Spring
Knob, Tremolo Arm, White
Tremolo Block
Mounting Screw
Intonation Spring, 5&6
Intonation Spring, 1-4
Height Adjustment Screw, 2-5
Mounting Screw
Body Part Number
0038918500 3 Color Sunburst
Pg. 3 of 4
05-25-2000
