Icom IC-E91 Service Manual page 36

[VCO UNIT]
REF ORDER
NO. NO.
Q1 1530003560 S.TR 2SC5195-T1
Q2 1590003280 S.TR UNR9211J-(TX)
Q51 1530003560 S.TR 2SC5195-T1
Q52 1590003280 S.TR UNR9211J-(TX)
Q101 1530003260 S.TR 2SC5006-T1
Q102 1590003280 S.TR UNR9211J-(TX)
Q200 1530003260 S.TR 2SC5006-T1
Q201 1530003260 S.TR 2SC5006-T1
Q202 1530003260 S.TR 2SC5006-T1
D1 1750001270 S.VCP 1SV325 (TPH3)
D2 1790001621 S.DIO 1SV308 (TPL3)
D3 1750001270 S.VCP 1SV325 (TPH3)
D4 1750000940 S.DIO ISS400 TE61
D5 1750001270 S.VCP 1SV325 (TPH3)
D6 1750001270 S.VCP 1SV325 (TPH3)
D51 1750000771 S.VCP HVC376BTRF-E
D52 1790001260 S.DIO MA2S077-(TX)
D53 1750000940 S.DIO ISS400 TE61
D54 1750001270 S.VCP 1SV325 (TPH3)
D55 1720000650 S.VCP 1SV286 (TPH3)
D100 1720000650 S.VCP 1SV286 (TPH3)
D101 1750000721 S.VCP HVC375BTRF-E
D102 1790001260 S.DIO MA2S077-(TX)
D103 1750000940 S.DIO ISS400 TE61
D104 1750000721 S.VCP HVC375BTRF-E
L2 6200011650 S.COL LQW18AN68NG00D
L3 6200011660 S.COL LQW18ANR15G00D
L52 6200010850 S.COL LQW18AN22NG00D
L53 6200012050 S.COL LQW18AN24NG00D
L101 6200011031 S.COL ELJRF R10JFB
L102 6200010120 S.COL LQW18AN5N6C00D
L103 6200012060 S.COL LQW18AN9N1D00D
L200 6200011021 S.COL ELJRF 82NJFB
L201 6200011021 S.COL ELJRF 82NJFB
L202 6200007951 S.COL ELJRF 8N2JFB (8.2)
L203 6200007931 S.COL ELJRF 12NJFB
L204 6200007961 S.COL ELJRF 6N8JFB (6.8)
R1 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R2 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R3 7030004970 S.RES ERJ2GEJ 470 X (47)
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R6 7030005710 S.RES ERJ2GEJ 121 X (120)
R7 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R8 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R9 7030010040 S.RES ERJ2GEJ-JPW
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R50 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R51 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R52 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R53 7030004970 S.RES ERJ2GEJ 470 X (47)
R54 7030005210 S.RES ERJ2GEJ 822 X (8.2 k)
R55 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R56 7030007270 S.RES ERJ2GEJ 151 X (150)
R58 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R59 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R60 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R61 7030007320 S.RES ERJ2GEJ 225 X (2.2 M)
R62 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R100 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R101 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R102 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R104 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
R105 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R106 7030004990 S.RES ERJ2GEJ 221 X (220)
R107 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R108 7030007320 S.RES ERJ2GEJ 225 X (2.2 M)
R109 7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
R110 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R111 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R112 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R114 7030010040 S.RES ERJ2GEJ-JPW
R115 7030010040 S.RES ERJ2GEJ-JPW
R200 7030009160 S.RES ERJ2GEJ 181 X (180)
R201 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R202 7030005300 S.RES ERJ2GEJ 150 X (15)
R203 7030005570 S.RES ERJ2GEJ 820 X (82)
R204 7030005570 S.RES ERJ2GEJ 820 X (82)
R205 7030004970 S.RES ERJ2GEJ 470 X (47)
R206 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R207 7030004970 S.RES ERJ2GEJ 470 X (47)
R208 7030005070 S.RES ERJ2GEJ 683 X (68 k)
C1 4030017460 S.CER ECJ0EB1E102K
C3 4030017690 S.CER ECJ0EC1H121J
DESCRIPTION M.
LOCATION
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
[VCO UNIT]
H/V REF ORDER
NO. NO.
10.4/16.5 C4 4030016790 S.CER ECJ0EB1C103K
4.6/15.1 C5 4030016790 S.CER ECJ0EB1C103K
14/9.6 C6 4030017460 S.CER ECJ0EB1E102K
18.1/17.4 C7 4030017460 S.CER ECJ0EB1E102K
9/2.5 C8 4030016790 S.CER ECJ0EB1C103K
19/1.8 C9 4030017680 S.CER ECJ0EC1H820J
8.8/10.9 C10 4030017460 S.CER ECJ0EB1E102K
3.8/3.5 C11 4030017350 S.CER ECJ0EC1H020B
5.6/11.4 C51 4030017460 S.CER ECJ0EB1E102K
C53 4030017660 S.CER ECJ0EC1H330J
C54 4030017460 S.CER ECJ0EB1E102K
3.2/18 C55 4030017460 S.CER ECJ0EB1E102K
7.1/16.3 C56 4030017460 S.CER ECJ0EB1E102K
12.2/15.5 C57 4030017460 S.CER ECJ0EB1E102K
12.8/18.9 C58 4030017460 S.CER ECJ0EB1E102K
4.4/17.3 C59 4030017650 S.CER ECJ0EC1H270J
12.2/14.3 C60 4030017420 S.CER ECJ0EC1H470J
16.5/14.2 C61 4030017520 S.CER ECJ0EC1H0R3B
14.6/17.7 C62 4030016930 S.CER ECJ0EB1A104K
12.4/7.4 C63 4030017530 S.CER ECJ0EC1H0R5B
15.6/12.4 C101 4030017460 S.CER ECJ0EB1E102K
17.4/10.6 C102 4030017500 S.CER ECJ0EC1H560J
17.4/1.6 C103 4030017620 S.CER ECJ0EC1H100C
12.2/2.2 C104 4030017460 S.CER ECJ0EB1E102K
16.8/5.4 C105 4030017460 S.CER ECJ0EB1E102K
7.4/1.6 C106 4030017460 S.CER ECJ0EB1E102K
13.9/3.1 C107 4030017460 S.CER ECJ0EB1E102K
C108 4030017460 S.CER ECJ0EB1E102K
C109 4030017390 S.CER ECJ0EC1H180J
6.8/18.3 C110 4030017380 S.CER ECJ0EC1H050B
5/19.1 C111 4030017350 S.CER ECJ0EC1H020B
14.7/13.9 C112 4030017530 S.CER ECJ0EC1H0R5B
14.7/15.1 C114 4030017460 S.CER ECJ0EB1E102K
7.6/3.5 C115 4030016930 S.CER ECJ0EB1A104K
12.3/4.7 C116 4030017460 S.CER ECJ0EB1E102K
14.1/5.4 C117 4030018860 S.CER ECJ0EB0J105K
2.3/1.5 C118 4030017640 S.CER ECJ0EC1H150J
4/11.9 C200 4030017460 S.CER ECJ0EB1E102K
3.6/10.1 C201 4030017460 S.CER ECJ0EB1E102K
4.1/1.5 C202 4030017460 S.CER ECJ0EB1E102K
6.3/5 C203 4030017460 S.CER ECJ0EB1E102K
C204 4030017460 S.CER ECJ0EB1E102K
C205 4030017460 S.CER ECJ0EB1E102K
6.2/15 C206 4030017460 S.CER ECJ0EB1E102K
8/15 C207 4030017460 S.CER ECJ0EB1E102K
10.7/18.8 C208 4030017460 S.CER ECJ0EB1E102K
10.7/17.9 C209 4030017380 S.CER ECJ0EC1H050B
9.1/18.8 C210 4030017380 S.CER ECJ0EC1H050B
10/13.8 C211 4030017360 S.CER ECJ0EC1H030B
11.6/12.4 C213 4030017590 S.CER ECJ0EC1H070C
2.8/16.4
11.6/13.3
7.1/15 J1 6510025380 S.CNR AXK716147G
17.5/13.9
16.5/17.2
15.6/16.4
12.8/8.4
15.5/9.5
16.4/9.5
12.3/10.2
18.9/11.8
19.8/10.2
13.8/16.4
19.8/13.4
17.7/12.7
14.3/1.5
17.9/6.5
15.6/6.5
9.2/1
9/4.7
10.2/5.6
18.2/7.4
16.6/7.4
16.6/8.3
18.9/10.2
15.2/3.3
16.6/4.1
20.2/16.2
19.4/3.4
17.8/3.4
7.5/13.2
9.5/9.4
8.9/7
7.7/8.2
7.3/7
2.1/2.7
5.3/3.9
5.9/8.1
5.9/9
3.1/13.6
9.1/17.9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
