Operating Instructions
Air Conditioner
Model No.
Indoor Unit
Outdoor Unit
CS-RE9PKE-3 CU-RE9PKE-3 CS-
RE12PKE-3 CU-RE12PKE-3 CS-
RE15PKE-3 CU-RE15PKE-3
Operating Instructions
Thank you for purchasing Panasonic Air Conditioner.
Before operating the unit, read these operating instructions
thoroughly and keep them for future reference.
Installation Instructions attached for authorized dealer or
specialist.
Mode d'emploi
Nous vous remercions d'avoir porté votre choix sur un
climatiseur Panasonic.
Avant d'utiliser l'appareil, lisez ce mode d'emploi dans son
intégralité et conservez-le pour toute référence ultérieure.
Instructions d'installation ci-jointes pour un revendeur ou
spécialiste agréé.
Manual de Instrucciones
Muchas gracias por elegir una unidad de aire acondicionado
Panasonic.
Antes de utilizar la unidad, sírvase leer atentamente estas
instrucciones de funcionamiento y conservarlas como futuro
elemento de consulta.
Instrucciones de Instalación adjuntas para el distribuidor
autorizado o especialista.
Istruzioni di funzionamento
Grazie per aver acquistato un climatizzatore Panasonic.
Prima di utilizzare l'unità si prega di leggere attentamente le
istruzioni e di conservare questo opuscolo per potervi fare
riferimento in futuro.
Istruzioni sull'installazione allegate per il concessionario
autorizzato o specialista.
Manual de Utilização
Obrigado por adquirir o Ar Condicionado da Panasonic.
Antes de ligar a unidade, leia cuidadosamente este manual
de utilização e guarde-o para futura referência.
Instruções de Instalação em anexo para representante
autorizado ou especialista.
Инструкции за работа
Благодарим Ви, че закупихте климатик Panasonic.
Преди да задействате климатика, прочетете внимателно
инструкциите за употреба и ги запазете за бъдещи
справки
Приложени са указания за монтаж,
предназначени за използване от официален
представител или
специалист.
2-9
10-17
18-25
26-33
34-41
42-49
F568946
