Sony CFD-EX35L Service Manual

Hide thumbs Also See for CFD-EX35L:

Advertisement

Quick Links

Download this manual
Table of Contents
SERVICE MANUAL
Ver 1.0 2002. 04
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance
of about 200 mm from the objective lens surface
on the optical pick-up block with 7 mm
aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm)
(CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM
87.5 - 108 MHz
MW
531 - 1 611 kHz (9 kHz step)
530 - 1 610 kHz (10 kHz step)
LW
153 - 279 kHz
IF
FM: 10.7 MHz
AM/MW/LW: 450 kHz
Aerials
FM: Telescopic aerial
AM/MW/LW: Built-in ferrite bar aerial
Sony Corporation
9-873-984-01
2002D1600-1
Personal Audio Company
© 2002.04
Published by Sony Engineering Corporation
CFD-EX35L
Model Name Using
Similar Mechanism
CD Mechanism Type
Optical Pick-up Type
Tape Transport Mechanism Type
SPECIFICATIONS
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 115 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 70 - 13 000 Hz
General
Speaker
Main speaker: 10 cm (4 in.) dia., 3.2 Ω, cone
type (2)
in.) dia., 4 Ω, cone type
1
Subwoofer: 8 cm (3
⁄
4
(1)
Outputs
Headphones jack (stereo minijack)
For 16 - 68 Ω impedance headphones
Maximum power output
Main speaker: 4 W
Subwoofer: 6 W
Power requirements
For CD radio cassette-corder:
230 V AC, 50 Hz
9 V DC, 6 R20 (size D) batteries
For remote control:
3 V DC, 2 R6 (size AA) batteries
Power consumption
AC 25 W
CD RADIO CASSETTE-CORDER
AEP Model
UK Model
CD Section
CFD-G35
Tape Section
CFD-G35
KSM-213RDP
KSS-213R
MF-V5-117
Battery life
For CD radio cassette-corder:
FM recording
Sony R20P: approx. 4 h
Sony alkaline LR20: approx. 19 h
Tape playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 7 h
CD playback
Sony R20P: approx. 1.5 h
Sony alkaline LR20: approx. 3.5 h
Dimensions
Approx. 456 × 195 × 330 mm (w/h/d)
(18 × 7
× 13 inches) (incl. projecting parts)
3
⁄
4
Mass
Approx. 6.4 kg (14 lb. 2 oz) (incl. batteries)
Supplied accessory
Mains lead (1)
Remote control (1)
Design and specifications are subject to change
without notice.
