Targus DOCK120USZ Quick Start Manual

UNIVERSAL
USB 3.0
DV1K-2K COMPACT
DOCKING STATION
QUICK START GUIDE
410-3300-001C / DOCK120USZ
Contents
• Targus Universal USB 3.0 DV1K-2K Compact
Docking Station
• USB 3.0 cable
• AC Power adapter
Workstation Setup
1. Connect all peripheral devices to the docking station
2. Connect the Targus Universal Docking Station to your host device.
Specifications
• DisplayPort (DP++)
• HDMI port
• DVI-I port (supports dual display mode; select any 2 out of 3 video output ports)
• 2 x USB 3.0 downstream ports (port marked with
iOS device charging up to 1.5A max)
• 2 x USB 2.0 downstream ports
• Gigabit Ethernet
• Audio In/Out ports (3.5mm headset connector)
• Security lock slot
• USB 3.0 cable
• 20W AC power adapter
+
supports BC 1.2 and
Features and speci cations are subject to change without notice. Microsoft and
Windows are registered trademarks of Microsoft Corporation in the United States
and/or other countries. All trademarks and registered trademarks are the property
of their respective owners. ©2017 Targus. 1211 North Miller Street, Anaheim, CA
92806
Docking Station Diagram
DVI-I HDMI
USB 2.0
Port
USB 3.0 Port USB 3.0 Port
(supports charging)
System Requirements
Hardware
• USB Port (USB 3.0 recommended)
Operating System (any of the following)
• Microsoft Windows 7, Windows
® ®
• Mac OS ® X v10.8, v10.9, or v10.10
• Android 5.0, 5.1
Visit www.targus.com for a list of the lastest compatible
operating systems
Gigabit
DP++
Ethernet
USB 2.0 USB to Power In
Port Laptop Port
Lock Slot Audio
Headset Connector
8, Windows 8.1, or Windows 10 (32/64-bit)
® ®
