Summary of Contents for Cub Cadet G1332

  • Page 1 G1332, G1336, G1548 Walk-Behind Commercial Rotary Mowers Professional Turf Equipment OPERATOR’S AND SERVICE MANUAL...
  • Page 2: Table Of Contents

    INDEX Foreword ................................3 Safety Precautions ............................. 4 General ................................4 Related to Fuel ............................4 When Mowing ............................. 4 Safety Decals ..............................5-6 Specifications ..............................7 Operating Instructions ............................ 7-9 Controls ................................. 7 Ignition Switch ............................7 Fuel Shutoff Valve ............................
  • Page 3: Foreword

    The list of safety precautions should receive particular attention. This manual presents the operating and maintenance instructions necessary to keep your Cub Cadet Commercial mower at peak efficiency. If properly operated and maintained, your Cub Cadet Commercial mower will give dependable and trouble-free service.
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS A. General: Read this Operator’s Manual completely before starting Watch for holes, sprinkler heads and other hidden the mower. Study the controls and learn the proper hazards. sequence of operation. Retain Operator’s Manual in a Reduce speed when making sharp turns. safe place for future reference.
  • Page 5: Safety Decals

    SAFETY DECALS Keep safety decals clean. Replace any safety decal that is damaged, destroyed, missing, painted over or can no longer be read. Replacement safety decals are available through your dealer. (Left and right sides are determined standing behind the unit in the operating position.) WARNING OPEN BELT DRIVE STOP ENGINE BEFORE...
  • Page 6 SAFETY DECALS DANGER CAUTION To Avoid Injury: • Always connect the “ground” Serious bodily injury may result from failure (Black) cable last and remove it first whenever to follow safe operating procedures. performing any battery 1. Read the Operators Manual before maintenance.
  • Page 7: Specifications

    SPECIFICATIONS POWER UNIT Engine: 13 or 15 HP Kawasaki. Type: 4-cycle, single-cylinder, recoil start. Air Cleaner: Dual element, dry-type. Lube System: Pressurized. Fuel Tank: 5 gallons, polyethylene. Transmission: 5 speeds forward and 1 speed reverse. Traction Drive: Double V-belts. Ground Speed: 2 to 4.5 MPH maximum.
  • Page 8: Blade Clutch

    OPERATING INSTRUCTIONS Releasing the operator presence levers with either the transmission shift lever in gear or the blade clutch engaged will shut off the engine. B. Initial Adjustments Disconnect the spark plug wire. Check the tire pressure. Drive Wheels should be inflated to 25 psi.
  • Page 9 OPERATING INSTRUCTIONS Move the mower outdoors. Check the engine gasoline Push the blade clutch lever forward until it engages and level. When filling the tank, stop when the gasoline the cutter blades start rotating. reaches one inch from the top. This space must be left Shift the transmission into first gear.
  • Page 10: Cutting Height Adjustment Table

    CUTTING HEIGHT ADJUSTMENT TABLE Note: The front edge of the cutting deck should be 1/8” - 1/4” below the rear edge of the deck so that the blades are cutting grass in only the front half of their circular path. This decreases friction and reduces the drive power required. 1/4: Blade Spacers 1/2”...
  • Page 11: Lubrication Chart

    MAINTENANCE D. LUBRICATION CHART: See Figures 3, 4 & 5 for Item Location NUMBER OF GREASING POSITIONS ITEM DESCRIPTION 32” & 36” 48” & 52” DAILY Cutter Blade Spindle Bearings Caster Wheel Bearing Caster Wheel Pivot Shafts EVERY Deck Idler Pulley Pivot Arms Drive Wheel Bearings HOURS Brake Lever Pivots...
  • Page 12: To Change The Transmission Drive Belt

    MAINTENANCE Figure 6 Figure 7 d. Slip the long blade drive belt off of the pulleys. e. (48" ONLY) Loosen the idler pull rod which holds the idler pulley tight against the short blade drive belt. (Item K, Figure 8.) f.
  • Page 13: To Change A Spindle Assembly

    MAINTENANCE 7. TO ADJUST THE LITE-TOUCH (MANUALLY) a.rThree holes in the belt guard allow you to reposition the hex cap screw to adjust the brake lever. The top hole (lite tension), the middle hole (medium tension) and the lower hole (hard tension).
  • Page 14: Suggested Replacement Parts - Mower

    MAINTENANCE SUGGESTED MOWER REPLACEMENT PARTS PART # Description 32" 36" 48" 00021871 Rotary Blade, 16-1/2" 00050125 Rotary Blade, 18" 01007591 Blade Bolt 00011807 Blade Nut 00021924 Blade Spacer 01007578 Drive Belt 00050441 Drive Belt 00021947 Long Drive Belt 00050480 Short Drive Belt 01000194 Transmission Drive Belt 01000151...
  • Page 15 Supplement Parking Instructions All Gear Walk-Behind Mowers INCORRECT Instructions 1. When parking mower on a hill, position mower perpendicular to slope. PARK MOWER FACING DOWN SLOPE. 2. Turn off the engine. 3. Place the Transmission Shift Lever in First Gear. 4.
  • Page 16 MAINTENANCE RECORD DATE WORK PERFORMED DATE WORK PERFORMED...
  • Page 17 MAINTENANCE RECORD DATE WORK PERFORMED DATE WORK PERFORMED...
  • Page 18 MAINTENANCE RECORD DATE WORK PERFORMED DATE WORK PERFORMED...
  • Page 20: Warranty

    Cadet Commercial dealer subject to the above time and coverage limitations. Upon completion of your purchase, the Serial Number/s of the unit will be registered with the Cub Cadet. This will initiate and validate your limited warranty and the applicable Warranty Period.
