OWNER’S MANUAL WASHING MACHINE Please read this manual carefully before operating your set and retain it for future reference. F1260RD F1260RDW www.lg.com P/No.: MFL51768151...
roduct Feature Direct Drive System The advanced Brushless DC motor directly drives the drum without belt and pulley. Water Circulation Sprays detergent solution and water onto the load over and over. Clothes are soaked more quickly and thoroughly during wash cycle. The detergent suds can be removed more easily by the water shower during rinse cycle.
arnings READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION BEFORE USE For your safety, the information in this manual must be followed to minimize WARNING! the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, or injury to persons when using...
Page 4
arnings To minimize the risk of fire in a tumble dryer, the following should be observed: • Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected items can ignite spontaneously, especially when exposed to heat sources Such as in a tumble dryer.
pecification Power Plug Shipping Bolts • If the supply cord is damaged, it must be replaced by the manufacturer or its authorized Drawer service technician in order to avoid a hazard. Control Panel Drum Door Drain Hose Adjustable Feet Lower Cover Cap Drain Plug Drain Pump Filter Name...
nstallation Install or store where it will not be exposed to temperatures below freezing or exposed to the weather. Properly ground washer to conform with all governing codes and ordinances. The base opening must not be obstructed by carpeting when the washing machine is installed on a carpeted floor.
Page 7
nstallation Installation place requirement Level floor : Drain Hose Allowable slope under entire washer is 1˚ Washer Power outlet : Must be within 1.5 meters of either side of location of washer. Do not overload the outlet with more than Laundry one appliance.
Page 8
nstallation Electrical connection 1. Do not use an extension cord or double adapter. 2. If the supply cord is damaged, it must be replaced by the manufacturer or its service agents or similarly qualified person in order to avoid a hazard. 3.
Page 9
nstallation Normal Tap without thread & screw type inlet hose Unscrew the fixing screw to Push the connector up till the Push the water supply hose attach the tap. rubber packing is in tight contact vertically upwards so that the with the tap.
Page 10
nstallation This equipment is not designed for maritime use or for use mobile installations such as caravans, aircraft etc. Turn off the stopcock if the machine is to be left for any length of time (e.g. holiday), especially if there is no floor drain(gully) in the immediate vicinity. When disposing of the appliance, cut off the mains cable, and destroy the Plug.
Page 11
• If possible install the washer in one of the corners of the room, where the floor is more stable. ※ ※ Insert the rubber cups to reduce vibration. ※ ※ You can obtain the rubber cups (p/no.4620ER4002A) from the LG svc dept. Important! •...
are before washing Before the first washing Select a cycle (COTTON 60°C, add a half load of detergent) allow the unit to wash without clothing. This will remove residues and water from the drum that may have been left during manufacturing.
dding detergent Adding detergent and fabric softener 1. The Dispenser Drawer • Main wash only ➔ • Pre Wash + Main Wash ➔ Detergent for Fabric Detergent for main wash softener pre wash 2. Adding Fabric Softener • Do not exceed the maximum fill line. Close the dispenser drawer slowly.
Page 14
dding detergent ❋ Tips 3. Detergent dosage Full load : according to • The detergent should be used according to the manufacturer’s recommendation. instruction of the detergent manufacture. Part load : 3/4 of the normal amount. • If too much detergent is used, too many suds Minimum load : 1/2 of full load.
unction Recommended courses according to the laundry type Proper Temp. Additional Maximum Program Fabric Type (Option) Option Load - Pre Wash Color fast garments (shirts, night 60˚C - Rinse+Spin dresses, pajamas...) and lightly soiled (Cold, 30˚C, Cotton - Dry Only white cotton (underwear...) 40˚C, 95˚C) - Bio...
ow to use the washer 2. Manual Selecting 1. Cotton automatically selected upon power on. • Press the Power button to start. • Select the conditions which you want to use, • Press the Power button to start. by pressing each button. •...
Page 17
ow to use the washer (8,9,10) (11) (12) (13) (1) Button: Power (5) Child lock (9) Button: Water Plus (13) Dial: Dry (2) Dial: Program (6) Button: Rinse (10) Button: Time Delay (3) Button: Start/Pause (7) Button: Spin (11) Button: Temp. (4) Button: Option (8) Button: Intensive (12) Button: Tub Clean...
Page 18
ow to use the washer Start/Pause Option • By pressing the option button, only one option functions may be selected. 1. Start • This Start/Pause button is used to start wash cycle or pause the wash cycle. 1. Pre Wash 2.
Page 19
ow to use the washer Rinse Child lock • By pressing the Rinse button,the Rinse type can be selected. If you choose to lock the buttons on the control assembly to prevent tampering, this function may be selected. • Child lock can be set by pressing and holding the Option and Rinse button 1.
Page 20
ow to use the washer Spin Water Temp. • By pressing the Spin • By pressing the Temp. button, the spin speed can button, the water be chosen. temperature can be selected. • Water temperature can be selected as 1. Spin selection below according to the program.
Page 21
ow to use the washer Intensive Time Delay • If the laundry is heavily soiled “Intensive” option is effective. • By selecting the Intensive option, the wash time may be extended, depending on the program selected. Preparing washing before starting “Time Delay” •...
Page 22
ow to use the washer NOTE The maximum drying capacity for this 1. Drying Automatic guide model is 5 kg. When loading, please use the maximum drying capacity • Use your Automatic Cycles to dry most loads. indicator behind the door as shown Electronic sensors measures the temperature below.
Page 23
ow to use the washer Fiber glass 2. Manual Drying time guide - Do not dry fiberglass articles in your dryer. • By turning the Dry button, the drying time Glass particles left in the dryer could be picked can be selected. up by your clothes the next time you use the •...
Page 24
ow to use the washer Display 3. Completion of washing • When washing cycle is completed, “ ” is displayed on the “Multi display”. 1. Special function display 4. Time left • When Child lock is selected, the “ ” lamp is •...
aintenance ❋ Before cleaning the washer interior, unplug the electrical power cord to avoid electrical shock to avoid electrical shock hazards. ❋ When disposing of the appliance, cut off the mains cable, and destroy the plug Disable the door lock to prevent young children being trapped inside. The water inlet filter - "...
Page 26
aintenance The drain pump filter ❋ The drain filter collects threads and small objects left in the laundry. Check regularly that the filter is clean to ensure smooth running of your machine. CAUTION First drain using the drain hose and then open the pump filter to remove whatever any threads or objects.
Page 27
aintenance Dispenser drawer ❋ After a while detergents and fabric softeners leave a deposit in the drawer. • It should be cleaned from time to time with a jet of running water. • If necessary it can be removed completely from the machine by pressing the catch downward and by pulling it out.
Page 28
aintenance The water circulation nozzle & steam nozzle • Clean the water circulation nozzle, if clogged. Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent.
roubleshooting guide ❋ This washing machine is equipped with automatic safety functions which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not function at all, check the following points before you contact your service provider. Symptom Possible Cause Solution...
Page 30
roubleshooting guide Symptom Possible Cause Solution Washer does not start • Electrical power cord may not Make sure plug fits tightly in wall be plugged in or connection outlet. may be loose. • House fuse blown, circuit Reset circuit breaker or replace fuse. breaker tripped,or a power Do not increase fuse capacity.
Page 31
roubleshooting guide Symptom Possible Cause Solution Check another tap in the house. • Water supply is not adequate in area Fully open tap. • Water supply taps are not completely open. Straighten hose(s). • Water inlet hose(s) are kinked. Check the filter of the inlet hose(s). •...
erms of Warranty What Is Not Covered: • Service trips to your home to teach you how to use the product. • If the product is connected to any voltage other than that shown on the rating plate. • If the fault is caused by accident, neglect, misuse or Act of God. •...
