REFRIGERATOR RT30G/RT30S/RT30D RT31G/RT31S/RT31D RT34G/RT34S/RT34D RT35G/RT35S/RT35D RT37G/RT37S/RT37D RT38G/RT38S/RT38D OWNER`S INSTRUCTIONS Before operating the unit, please read this manual thoroughly, and retain for future reference.
FEATURES Large freezer storage area - Stores large quantities of food in the freezer. Jumbo storage guard - Holds large bottles securely. Adjustable storage guards - Position them for your convenience and according to the height of your food containers. Fresh Bread Zone(option*) - Some kind of bread for long.
Safety precautions Contents Read Instructions FEATURES ........1 Please read all safety and operating SAFETY INSTRUCTIONS....3 instructions before operating this CAUTIONS WHILE USING ....6 appliance. INSTALLATION .........8 Retain Instructions LEVELING THE APPLIANCE ....9 Please keep this Owner's Manual for future BASIC PREPARATION .....9 reference.
SAFETY INSTRUCTIONS The appliance is not intended for use by persons (including children) with reduced physical, sensory or metal capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
Page 5
SAFETY INSTRUCTIONS Ensure that none of the pipes on the back of the appliances are damaged prior to disposal. The pipes shall be broke in the open space. Do not plug several appliances into the same multiple power board. Damage to the cord may cause a short-circuit, fire and/or electric shock...
Page 6
SAFETY INSTRUCTIONS If you experience difficulty when changing the light, contact your service center.
SAFETY INSTRUCTIONS This refrigerator use CycloPentance REMARK as insulation blowing gas. Contains fluorinated greenhouse gases covered by the Kyoto Protocol. Hermetically sealed system. Do not vent gases into the atmosphere. Refrigerant type : R-134a Quantity : 0.16 kg Global Warming Potential (GWP) = 1300 CAUTIONS WHILE USING Do not place carbonated or fizzy drinks in the freezer compartment.
Page 8
CAUTIONS WHILE USING - Do not allow water to splash onto the back of the refrigerator. - Water impairs the insulation of elec- tric parts and may cause an electri- cal short or a shock hazard. - Do not use flammable sprays such as lacquer and paint near the refrig- erator - Heat from the refrigeration unit may...
INSTALLATION Install this refrigerator on a firm, flat surface. For optimum operation, normal room temperature is recommended. Avoid locations affected by draughts or dampness. For optimum operation, normal room temperature is recommended. Avoid locations in direct sunlight, near heaters, rediators, stoves or ovens. Allow a 50mm space between above 300mm the refrigerator and the wall.
Storing food Store food in small portions. Seal food in containers with lids, in plastic wrap or in plastic bags to prevent drying and the mingling of odors. Allow hot food and drinks to cool to room temperature before placing them in the refrigerator or freezer.
HOW TO USE Temperature control Number 6 (COLDER) Turn the Temperature Control to “COLDER” if you: - Want to make ice (freezer) - Require fast freezer (freezer) Number 5 Turn the Temperature Control to number 5 if you: - Have a lot of food to store (refrigerator or freezer) Number 3 Turn the Temperature Control to number 3 for normal refrigerating or freezing mode.
Page 14
080618_Manual_english_REV 0.1.pdf 7/15/2008 4:29:45 PM HOW TO USE Freeze Room Freezer : Adjust the proper temperature by turning the temperature control dial to "COLD" or "COLDER" Mechanical model (RT30/31/34/35/37/38G,D) Electrical model (RT30/31/34/35/37/38S) Refrigerator Room Refrigerator : Adjust the proper temperature by turning the temperature control dial to "COLD"...
Making ice cubes Tray Type(option) Fill the tray ice with water taking care not to overfill. Water level Hold both ends of the ice tray, remove the ice cubes from the tray by twisting it gently. Twist Type(option) Fill the ice cube tray with taking care not to overfill.
Vegetable Bin Chiller Compartment This is compartment helps preserve the This compartment maintains the moisture taste of food and prolongs its freshness and freshness of vegetables. The vegetable by freezing the surface of the food only. bin is enclosed to protect the vegetables Use the chiller for storing cheese, meat, from direct draughts of cold air and to help snacks, fish or any food to be used soon.
REMOVING ACCESSORIES Freezer Shelf - Pull the ice cube tray unit forward and of the freezer compartment. - Lift the front of the freezer shelf upward to release the hooks and pull the shelf out of the freezer. Refrigerator Shelves - Pull the shelves towards you until it meets the stopper.
Page 19
Chiller Compartment - Pull the chiller compartment towards you until it meets the stopper. - Tilt the front upward and continue pulling the compartment out. Adjustable Storage Guard Lift straight upwards to release the tabs, then pull it out of the refrigerator.
BEFORE CALLING SERVICE when the Refrigerator / Freezer when you hear a sound like is not operating or the food water flowing: does not freeze suffciently: - This sound is generated by - Is the plug properly connected? movement of the refrigerant - Is the power fuse blown? and is not a malfunction.
