PRO HD CART
Flat Panel Television Cart
OM1004410
OM#
Pro HD Cart = L3-OM1004410-PRO-02010vB
PN #
EN
Instruction Manual
ES
Manual De Instrucciones
FR
Manuel D'instructions
Maximum screen size: 55"
Maximum weight 125 lbs – 56.7 KG
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT
CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE
MAY OCCUR!
EN
Images may differ from actual product
ES
El producto real puede variar respecto a la imagen mostrada.
FR
Le produit réel peut différer de l'illustration.
VERSION
B
Advertisement
Related Manuals for Omnimount PRO HD CART
Summary of Contents for Omnimount PRO HD CART
- Page 1 PRO HD CART Flat Panel Television Cart OM1004410 Pro HD Cart = L3-OM1004410-PRO-02010vB PN # VERSION Maximum screen size: 55” Maximum weight 125 lbs – 56.7 KG CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE...
- Page 2 OmniMount customer service at 800.668.6848 or info@omnimount.com. • Do not install or assemble if the product or hardware is damaged or missing. If you require replacement parts, contact OmniMount Customer Service at 800.668.6848 or Info@omnimount.com. International customers need to contact a local distributor for assistance.
- Page 3 WEIGHT CAPACITY MAXIMUM WEIGHT CAPACITY POUNDS (LBS) / KILOGRAMS (KG) MAXIMUM SCREEN SIZE MÁXIMA CAPACIDAD DE PESO LIBRAS (LB) / KILOGRAMOS (KG) TAMAÑO DE PANTALLA MÁXIMO CAPACITE DE CHARGE MAXIMALE LIVRES (LB) / KILOGRAMMERS (KG) TAILLE D’ÉCRAN MAXIMALE COMPLETE UNIT 125 (LBS) / 56.7 (KG) 55”...
- Page 4 CONTENTS...
- Page 5 CONTENTS Monitor Kit L-U-vB Pouch Location Part # Description Philips screws M4 x 15mm Philips screws M4 x 35mm Philips screws M5 x 15mm Philips screws M5 x 35mm Philips screws M6 x 15mm Philips screws M6 x 35mm Philips screws M8 x 15mm Philips screws M8 x 35mm Oval Spacers: 3/4"...
- Page 6 SYMBOL KEY Drill Level Caution Open-Ended Wrench Options Agujerear Nivel Precaución Llave española Opcional Percer Niveau Attention Clé ouverte Optionnel Tools Needed Pencil Mark Phillips Screwdriver Allen Wrench Destornillador Phillips Herramientas necesarias Marque con lápiz Llave Allen Marque de crayon Tournevis Phillips Clé...
- Page 7 STEP 1 STEP 2 STEP 3...
- Page 8 STEP 4...
- Page 9 STEP 5...
- Page 10 MOUNTING OPTIONS 200mm NOTE: USE OPTION A FOR VESA HOLE PATTERNS OF: 100mm X 200mm 200mm X 200mm 300mm X 200mm MOUNTING OPTIONS 900mm NOTE: USE OPTION B FOR HOLE PATTERNS UP TO: 500mm X 900mm BE SURE TO CENTER ADAPTER ON THE BACK OF THE TV.
- Page 11 NO SPACERS M-A – Attach monitor using monitor hardware, M-A, M-B, etc… Coloque la pantalla utilizando los materiales de instalación de la pantalla, M-A, M-B, etc… Installer le moniteur avec les fixations de moniteur, M-A, M- B, etc… SPACERS M-A – Use spacers for recessed mounting holes or to access A/V inputs Use los espaciadores para agujeros de montaje empotrados o para acceder a las entradas de A/V...
- Page 12 ADJUSTING THE ADAPTER Adjustment May Be Needed Puede necesitarse ajuste Des réglages peuvent être nécessaires...
- Page 13 CONNECT VESA PLATE TO UNIVERSAL ADAPTER...
- Page 14 NO SPACERS M-A – Attach monitor using monitor hardware, M-A, M-B, etc… Coloque la pantalla utilizando los materiales de instalación de la pantalla, M-A, M-B, etc… Installer le moniteur avec les fixations de moniteur, M-A, M-B, etc… SPACERS M-A – Use spacers for recessed mounting holes or to access A/V inputs Use los espaciadores para agujeros de...
- Page 15 STEP 6 Hang with monitor attached Cuelgue con el monitor adherido. Accrochez avec le moniteur installé. Hang with monitor attached Cuelgue con el monitor adherido. Accrochez avec le moniteur installé.
- Page 16 STEP 7 Turn Vuelta Tour Pull Tire Tirer Tilt Mechanism Mecanismo de inclinación Mécanisme d’inclinaison STEP 8 Turn Vuelta Tour Pull Tire Tirer Watch for Pinch Points Tenga cuidado con las partes que pueden apretarle las manos Faites attention aux points de pincement This step may require two people Este paso podría requerir de dos personas.
- Page 17 STEP 9...
- Page 18 STEP 10...
- Page 19 (800.668.6848) o escríbanos a info@omnimount.com. Deberá proporcionar el recibo original. Si fuera necesario enviar el producto a OmniMount para revisarlo, los gastos de envío correrán por su cuenta. El producto de reemplazo que se le envíe se le devolverá con los gastos de envío pagos.
- Page 20 (FR) French MERCI D’AVOIR ACHETÉ UN PRODUIT OMNIMOUNT OmniMount Systems, Inc. 8201 South 48th Street Phoenix, AZ 85044-5355 1-800-MOUNT-IT (1-800-668-6848) www.omnimountpro.com All trademarks are the property of their respective companies. OmniMount is a registered trademark of OmniMount Systems, Inc. © 2006...
