For Your Records and
Warranty Assistance
For reference, also attach your receipt or a copy
of your receipt to the manual.
__________________________________________
Viente
Model Name
__________________________________________
21322
Model No.
__________________________________________
Date Purchased
__________________________________________
Where Purchased
Form# 42857-01
20081204
©2008 Hunter Fan Co.
Type A Models
Type A Models
Type A Models
Owner's Guide and Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for Hunter Viente 21322

Summary of Contents for Hunter Viente 21322

  • Page 1 For reference, also attach your receipt or a copy of your receipt to the manual. Owner’s Guide and Installation Manual __________________________________________ Viente Model Name __________________________________________ 21322 Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42857-01 20081204 ©2008 Hunter Fan Co.

  • Page 2: Table Of Contents

    Never insert foreign objects between rotating fan blades. • To reduce the risk of fire, electrical shock, or motor damage, do not use a solid-state speed control with this fan. Use only Hunter speed controls. © 2008 Hunter Fan Company...
  • Page 3 To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls. Low Profile Mounting fits close to the ceiling, recommended for ceilings less...

  • Page 4: Getting Ready

    • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...

  • Page 5: Installing The Hanger Bracket

    Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 3” Wood Screw Steps 2-4 – 2-6 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 6: Assembling And Hanging The Fan

    3-3. Install two locking screws through the holes in the side of the Square Hanger metal bracket to secure the square hanger. Motor Green Assembly Ground Wire Step 3-2 Green Ground Wire Step 3-3 #8-32 x 1” Screw Locking Screw 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 7: Wiring The Fan

    • The black/white wire from the fan to the black/white wire from the ceiling. 4-4. Push all wires and wire connectors back through the ceiling plate hole Wire into the outlet box. Connector 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 8: Installing The Motor Housing

    5-3. Install the two remaining canopy screws into the holes in the fan housing and into the hanger bracket. Securely tighten all screws. 5-4. Install the rubber plugs into the holes over the canopy screws. Step 5-3 Canopy Screw Step 5-4 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 9: Assembling The Blades

    6 • Assembling the Blades Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, Step 6-1 (Detail) insert them by hand into the holes on the blades.

  • Page 10: Completing Your Installation With Or Without A Bowl Light Fixture

    7 • Completing Your Installation With or Without a Bowl Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture.
  • Page 11 Align the side screw holes in the upper and lower switch housings. Attach the lower switch housing to the upper switch housing with three housing assembly screws. Lower Switch Housing Plug Connector Detail Housing Assembly Screw 42857-01 • 12/04/08 • Hunter Fan Company...
  • Page 12 7-15. Thread the light pull chain through Candelabra- the finial and screw the finial onto the Based 60 Watt Maximum) threaded rod end until tight. Metal Disc Threaded Rod Glass Bowl Cover Plate Finial 42857-01 • 12/04/08 • Hunter Fan Company...
  • Page 13 7-21. Install the switch housing cap and plug button to the lower switch housing. 7-22. Once you have uninstalled the light fixture, continue with step 7-6. Step 7-19 Male Dummy Terminal Female Dummy Terminal Plug Button Step 7-22 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 14: Fan

    To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 42857-01 • 12/04/08 • Hunter Fan Company...

  • Page 15: Troubleshooting

    2. Tighten all blade and/or blade iron screws. Problem: Lights dim when turned on or do not turn on 1. Check to make sure the wattage and type of light bulbs installed match the specifications on the light socket. 42857-01 • 12/04/08 • Hunter Fan Company...
