Congratulations on purchasing
your new Hunter® ceiling fan! It will
provide comfort and performance
in your home or office for many
years. This installation and operation
manual contains complete
instructions for installing and
operating your fan.
We are proud of our work and
appreciate the opportunity to
supply you with the best ceiling fan
available anywhere in the world.
What to Expect with
Your Installation
Tools Needed
30 inches
7 feet
2
Downrod
6
Switch Housing
Light Kit
12
1
M3519-01 • 05/14/14 • © Hunter Fan Company
Mounting Options
Ladder
3
Wiring
Canopy
9
Operation, Maintenance
& Cleaning
13
Ceiling Bracket
4
5
Blades
10
11
Troubleshooting
?
?
?
15
17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hunter M3519-01
Summary of Contents for Hunter M3519-01
- Page 1 We are proud of our work and appreciate the opportunity to Downrod Wiring Canopy Blades supply you with the best ceiling fan available anywhere in the world. Operation, Maintenance Switch Housing Light Kit & Cleaning Troubleshooting M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 2 Assess ceiling angle Select a downrod length harmful interference to radio communications. M3519-01 • 05/14/14 • © Hunter Fan Company...
-
Page 3: Tools Needed
“How do I properly install multiple remote- controlled fans?” for more information. Power Drill 9/64” Drill Bit Allen Wrench (optional) (optional) (included) If mounting to a support structure, you will also need these tools. M3519-01 • 05/14/14 • © Hunter Fan Company... -
Page 4: Mounting Options
You need BOTH You need ONLY a Longer a Longer Downrod & Downrod an Angled Mounting Kit *most common M3519-01 • 05/14/14 • © Hunter Fan Company... - Page 5 To avoid possible electrical shock, before installing your fan, disconnect the power by turning off the circuit breakers to the outlet Refer to warning w.1 on pg. 2 box associated with the wall switch location. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 6 Steps 1-5 to remove standard downrod pipe Longer Downrod for angled ceilings or ceilings 10’ or higher Shorter Downrod for fans installed close to ceiling Steps 6-10 to reassemble with new pipe M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 7 (at least 4-5 full turns) and ball assembly. until it stops. 8” 3/8” If the setscrew is not tightened securely, the fan may fall. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 8 Put the wires and downrod and tighten them securely. through the canopy. Let the canopy CANOPY OR WIRES. Place the downrod sit loosely on top of the fan. ball into the slot in the ceiling bracket. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 9 Spread the wires apart, with the grounded wires on one side of Refer to CAUTION c.1 on pg. 2 the outlet box and the ungrounded wires on the other side of the outlet box. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 10 Insert the two canopy screws lifted into place, the canopy fits into the screw holes are aligned. found in the hardware bag. the hanging bracket as shown. Note: Fan style may vary. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 11 Your blades are shielded with Dust Armor® which is a nanotechnology coating that repels dust. For cleaning the fan, use soft brushes or cloths to prevent scratching. Cleaning agents may damage the finishes. M3519-01 • 05/14/14 • © Hunter Fan Company...
-
Page 12: Switch Housing
Make sure the upper switch housing is securely attached to the mounting plate. Failure to properly secure all 3 assembly screws could result in the switch housing fixture falling. M3519-01 • 05/14/14 • © Hunter Fan Company... -
Page 13: Light Kit
Make sure the lower switch housing is securely attached to the upper switch housing. Failure to properly secure all three assembly screws could result in the light fixture falling. M3519-01 • 05/14/14 • © Hunter Fan Company... - Page 14 Attach the glass bowl to replace with bulbs of same wattage. the light kit by twisting it clockwise until it snaps into place. See next page for fan operation instructions. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 15 Note: For rocker-style cover plates, fan, wait 1 minute then try again. If break off the tabs by pushing outward. Turn Power using the transmitter with multiple fans, repeat this process for each fan. M3519-01 • 05/14/14 • © Hunter Fan Company...
- Page 16 Cleaning the lights will be completely off. position. You will need to remove the products may damage the finishes. light kit glass to do so. M3519-01 • 05/14/14 • © Hunter Fan Company...
-
Page 17: Troubleshooting
If so, replace all of your remote controls, please go to switch housing. the blades. www.HunterFan.com/FAQs and click “How do I properly install multiple remote-controlled fans?” for information on how to correct this issue. M3519-01 • 05/14/14 • © Hunter Fan Company...
