Boom Actuator Service (Machines with Serial Numbers Below 260000000)

70 in–lb
(7.9 N–m)
20 in–lb
(2.3 N–m)
7
6
4
1
2
1. Screw
2. Rear housing
3. Washer
4. Woodruff key
5. Clutch
6. Thin washer
7. Intermediate gear
Spray System
14
12
11
9
10
8
3
5
3
8. Thick washer
9. Hex nut (2 used)
10. Motor gear
11. Housing gasket
12. Front housing
13. Cover tube gasket
14. Motor seal
18
15 16
13
Figure 64
Page 6 – 58
Rev. A
20
17
70 in–lb
(7.9 N–m)
15. Motor assembly
16. Ball screw and brake assembly
17. Washer head screw (4 used)
18. Cover tube
19. O–ring
20. O–ring
Multi Pro 1200/1250
19
