Tatung V17AFTW Service Manual

Tatung V17AFTW Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V
1
7
A
F
T
W
V
1
7
A
F
T
W
LCD-TV

Advertisement

Table of Contents
loading

Related Manuals for Tatung V17AFTW

Summary of Contents for Tatung V17AFTW

  • Page 1 LCD-TV...

  • Page 2: Table Of Contents

    Table of contents 1. Precautions & Notice........………………….2 2. Features & Specifications.........………………….4 3. Connection & Applications……………………..…………………..6 4. Controls Location ............…………………..8 5. Remote Control............…………………...9 6. Disassembly Instructions.......………………………………11 7. Block Diagram............………………………14 8. Troubleshooting Flow Chart..........…………..14 9. Electronic Circuit Description........………………14 10. Circuit Diagram...........…………………….14 11. PCB Layout............…………………………14 12.

  • Page 3: Precautions & Notice

    1. Precautions ＆ Notice 1.1 Safety Precautions 1) Cleaning: Unplug the power cord from the AC outlet before cleaning the product. Use a damp cloth to clean the product. Do not use liquid cleaners or aerosol cleaners. 2) Heat sources: Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating products (including amplifiers).
  • Page 4 5) An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

  • Page 5: Features & Specifications

    2. Features ＆ Specifications Specification Screen size 17” wide TFT-LCD Panel 16：9 Aspect Ratio Resolution 1280x768(XGA-Wide) Display Brightness 400 cd/m² (Typical) Viewing Angle Over 160° (Hor.) / 160° (Vert.) OSD Language English TV standard (CCIR) NTSC TV Turning system PLL 181 Ch. TV I/P STEREO MTS+SAP...
  • Page 6 PC I/P Preset Timing Table Analog Input Pixel Mode Name H.Freq. (kHz) H. Polarity Mode No. Resolution V.Freq. (Hz) V. Polarity (MHZ) VGA 70Hz 31.469 25.175 640x350 70.087 VGA 60Hz 31.469 25.175 640x480 59.941 VGA 72Hz 37.861 31.5 640x480 72.81 VGA 75Hz 37.5 31.5...

  • Page 7: Connection & Applications

    3. Connection ＆ Applications...
  • Page 8 Note: Audio out: The level of Audio O/P is constant. It won’t be affected by aligning volume, treble and bass. This connecter should be connected to outer audio amplifier to enlarge the volume. Video O/P: When user wants to connect Audio and Video O/P of our LCD-TV to VCR for recording program, the O/P has only one choice that is TV mode.

  • Page 9: Controls Location

    4. Controls Location The buttons control your TV’s basic features, including the on-screen menu. To use the more advanced features, you must use the remote control. turn on or turn off the LCD TV. POWER: set up the input source (PC, AV, SV, TV or CV.) SOURCE: display the main menu.

  • Page 10: Remote Control

    5. Remote Control The remote control pad works almost same as ordinary TV remote control that includes the basic function needed while viewing a live video. Power ON/OFF Mute Display CH. digital Memory Recall Return Exit S-Video Y PbPr/YCbCr Channel Up Volume Down Menu/Enter Volume Up...
  • Page 11 Summary of Control Buttons Selecting the Signal Source Press TV button Switch to the TV mode. Press AV button Switch to the CVBS mode (Composite Signal). Press SV button Switch to the S-Video mode. Press CV button Switch to the Component mode( YPbPr or YCbCr) Press PC button Switch to the PC mode(VGA).

  • Page 12: Disassembly Instructions

    6. Disassembly Instructions 1. Face down the LCD-TV : Face down the LCD-TV on a smooth plane with a soft material to protect the panel faceplate . 2. Swival Base Removal : 2.1 Remove 2 screws from Neck Cover . (Indicated as “...
  • Page 13 3. Back Cover Removal : 3.1 Remove 6 screws from the back cover . (Indicated as “ ” and “ ”) Then you could take Back Cover apart from the LCD-TV . 4. Right & Left Side Covers and Tuner Board Removal : 4.1 Remove 4 screws from Right &...
  • Page 14 5. Metallic Cover Removal : 5.1 Remove 8 screws from Metallic Covers .(Indicated as “ H”) Then you could take Metallic Cover apart from Main Bracket and the PCB Board will show up .

  • Page 15: Troubleshooting Flow Chart

    8. Troubleshooting Flow Chart (1) Power start NG No picture Appear Is the Voltage of Does the LED Replace F001 L046 12V ? light up? Is the Voltage of Is LED display Replace I014 & D017 L045 5V ? Amber ? Reset the MCU(I012) Is the Voltage of Is it entering into...
  • Page 16 (2) Frame slant The Ver. or Hor. Sync. does not hold in any sou rce. Are the output of Are the cables I019 TP6760 attached firmly at Connect the cable Are the cables normal ? the LCD panel firmly with the attached firmly at ( SHCLK,PVSync, connectors ?
  • Page 17 (3) Picture abnormal Steps to Clean EEPROM : Picture StepsM abnormal 1. Press Power key to turn off the LCD-TV. Does the picture 2. Press Power key quickly to recover normal turn on the LCD-TV and after pressing then press the Aspect Ratio Recall key ? key promptly.
  • Page 18 12. Electrical Parts List 12.1 Main PCB (PWB-0452 ) Specification Part Number Vender 5230682291 PHILIPS C001 Chip capacitor SMD X7R 50V 8200.00pFK T 0603 5230019091 PHILIPS C002 Chip capacitor SMD Y5V 16V 82000.00pFZ T 0603 5230005491 PHILIPS C003 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS C004...
  • Page 19 Specification Part Number Vender 5218007891 TEAPO C032 SMD Electrolytic capacitor 16V 10.00UFM T 4x5 5218007891 TEAPO C033 SMD Electrolytic capacitor 16V 10.00UFM T 4x5 5230005491 PHILIPS C034 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5218014791 TEAPO C035 SMD Electrolytic capacitor 16V 4.70UFM T 4.0x5.5 5230005491 PHILIPS C036...
  • Page 20 Specification Part Number Vender 5230005491 PHILIPS C069 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS C070 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5218007891 TEAPO C071 SMD Electrolytic- capacitor 16V 10.00UFM T 4x5 5230610291 PHILIPS C072 Chip capacitor SMD X7R 50V 1000.00PFK T 0603 5230005491 PHILIPS C073...
  • Page 21 Specification Part Number Vender 5230005491 PHILIPS C102 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5214019102 ENGEL C103 DIP Electrolytic capacitor 16V 1000.00UFM 13x13 5230005491 PHILIPS C104 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5218007991 TEAPO C105 SMD Electrolytic capacitor 16V 100.00UFM T 6.0x5.0 5218007991 TEAPO C106...
  • Page 22 Specification Part Number Vender 5240610191 PHILIPS C137 Chip capacitor SMD NPO 50V 100.00PFJ T 0603 5240610191 PHILIPS C140 Chip capacitor SMD NPO 50V 100.00PFJ T 0603 SMD Electrolytic capacitor 16V 100.00UFM T 5218007991 TEAPO C141 6.0x5.0 5240627091 PHILIPS C142 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C143...
  • Page 23 Specification Part Number Vender 5240627091 PHILIPS C174 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C175 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C176 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C177 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS...
  • Page 24 Specification Part Number Vender 5230005491 PHILIPS C221 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230647391 PHILIPS C222 Chip capacitor SMD X7R 50V 47000.00pFK T 0603 5230647391 PHILIPS C223 Chip capacitor SMD X7R 50V 47000.00pFK T 0603 5230647391 PHILIPS C224 Chip capacitor SMD X7R 50V 47000.00pFK T 0603 5240647091 PHILIPS...
  • Page 25 Specification Part Number Vender 5218014791 TEAPO C284 SMD Electrolytic capacitor 16V 4.70UFM T 4.0x5.5 5240627091 PHILIPS C285 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C286 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C287 Chip capacitor SMD NPO 50V 27.00PFJ T 0603 5240627091 PHILIPS C288...
  • Page 26 Specification Part Number Vender 5230005491 PHILIPS C331 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS C332 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS C333 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS C334 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS...
  • Page 27 Specification Part Number Vender 6613000555 D011 RA DIODE SMD BAV99-7 75V,0.15A SOT-23 REEL 6613003550 D011 RB DIODE SMD MMBD7000LT1 SOT23 100V 0.2A 00 6613000555 D012 RA DIODE SMD BAV99-7 75V,0.15A SOT-23 REEL 6613003550 D012 RB DIODE SMD MMBD7000LT1 SOT23 100V 0.2A 00 6613000555 D013 RA DIODE SMD BAV99-7 75V,0.15A SOT-23 REEL 6613003550...
  • Page 28 Specification Part Number Vender 6622002259 Q006 RC TR NPN SMD MMBT3904-7 SOT-23 40V 0.2A 5054470091 F001 FUSE SMD 125V 7A FB 6.1X2.54X2.54 UL IC A/D CONVERTER 6649001853 I001 AD9883AKST-140 LQFP 80PIN TRAY IC VOLTAGE REGULATOR 6640003858 FAIRCHILD I002 RC1117S33T SOT-223 1A 3.3V IC VOLTAGE REGULATOR 6640003858 FAIRCHILD...
  • Page 29 Specification Part Number Vender IC QUAD BUFFER LINE DRIVER 6646059059 PHILIPS I023 74HC126DT SO14 14PIN IC LINEAR VIDEO SWITCH 6644022451 I024 NJM2244M-TE1 DMP8 8PIN IC MOSFET P-CH 6644075755 SILICONIX I025 SI9933ADY-T1 SO-8 20V 3.4A IC LINEAR OP AMP. LM358DT SO8 8PIN 6644008155 I026 CORE FERRITE BEAD CHIP0805...
  • Page 30 Specification Part Number Vender CORE FERRITE BEAD CHIP0805 5062120132 L014 RA HH-1M2012-301JT 300-OHM 2A CORE FERRITE BEAD CHIP 5062133003 MAGLAYERS L014 RB MLB-201209-0300L-N2 300-OHM 0.6A 0805 CORE FERRITE BEAD CHIP0805 5062120132 L015 RA HH-1M2012-301JT 300-OHM 2A L015 RB CORE FERRITE BEAD CHIP 5062133003 MAGLAYERS MLB-201209-0300L-N2 300-OHM 0.6A 0805...
  • Page 31 Specification Part Number Vender CORE FERRITE BEAD CHIP1806 5062120130 L042 RA HH-1H4516-600JT 60-OHM 3A CORE FERRITE BEAD CHIP 5062132306 MAGLAYERS L042 RB MLB-451616-0080P-N1 80-OHM 4A 1806 CORE FERRITE BEAD CHIP1806 5062120130 L044 RA HH-1H4516-600JT 60-OHM 3A L044 RB CORE FERRITE BEAD CHIP 5062132306 MAGLAYERS MLB-451616-0080P-N1 80-OHM 4A 1806...
  • Page 32 Specification Part Number Vender CORE FERRITE BEAD CHIP0805 5062120132 L062 RA HH-1M2012-301JT 300-OHM 2A CORE FERRITE BEAD CHIP 5062133003 MAGLAYERS L062 RB MLB-201209-0300L-N2 300-OHM 0.6A 0805 CORE FERRITE BEAD CHIP0805 5062120132 L064 RA HH-1M2012-301JT 300-OHM 2A CORE FERRITE BEAD CHIP 5062133003 MAGLAYERS L064 RB...
  • Page 33 Specification Part Number Vender CORE FERRITE BEAD CHIP 5062122981 MAGLAYERS L088 MLB-201209-0120A-N4 120-OHM 0.3A 0805 CORE FERRITE BEAD ARRAY 1206 5062128504 MAGLAYERS LP01 MLB-3216-0030M4-N2 30-OHM 0.35A CORE FERRITE BEAD ARRAY 1206 5062128504 MAGLAYERS LP02 MLB-3216-0030M4-N2 30-OHM 0.35A CORE FERRITE BEAD ARRAY 1206 5062128504 MAGLAYERS LP03...
  • Page 34 Specification Part Number Vender 5056416508 LEOCO P019 BASE AND PIN 15Px1 MDS240315 5056300707 LIH SHENG P020 DC JACK LD-0202-2.5 5056416038 LEOCO P021 BASE & PIN S10B-PH-K WIRE ASS'Y,W/15P CONN 5057415235 PA13 UL1007#24,PH/PH L=80mm EARPHONE JACK,3.5MM 5056302037 LEOCO PJ01 JY-3551-21-070 EARPHON TACK 3.50 5056300105 LEOCO PJ02...
  • Page 35 Specification Part Number Vender 5134300009 YAGEO R037 Chip resistor SMD 0603 1/16W 0.00 J T 5134300009 YAGEO R040 Chip resistor SMD 0603 1/16W 0.00 J T 5134300009 YAGEO R042 Chip resistor SMD 0603 1/16W 0.00 J T 5134300009 YAGEO R043 Chip resistor SMD 0603 1/16W 0.00 J T 5134300009 YAGEO...
  • Page 36 Specification Part Number Vender 5134300009 YAGEO R095 Chip resistor SMD 0603 1/16W 0.00 J T 5134347209 YAGEO R096 Chip resistor SMD 0603 1/16W 4.70KJ T 5134324209 YAGEO R097 Chip resistor SMD 0603 1/16W 2.40KJ T 5134324209 YAGEO R098 Chip resistor SMD 0603 1/16W 2.40KJ T 5134300009 YAGEO R099...
  • Page 37 Specification Part Number Vender 5134356009 YAGEO R147 Chip resistor SMD 0603 1/16W 56.00 J T 5134356009 YAGEO R148 Chip resistor SMD 0603 1/16W 56.00 J T 5134356009 YAGEO R149 Chip resistor SMD 0603 1/16W 56.00 J T 5134310309 YAGEO R153 Chip resistor SMD 0603 1/16W 10.00KJ T 5134300009 YAGEO...
  • Page 38 Specification Part Number Vender 5134368209 YAGEO R209 Chip resistor SMD 0603 1/16W 6.80KJ T 5134300009 YAGEO R210 Chip resistor SMD 0603 1/16W 0.00 J T 5134310309 YAGEO R211 Chip resistor SMD 0603 1/16W 10.00KJ T 5134310309 YAGEO R212 Chip resistor SMD 0603 1/16W 10.00KJ T 5134375009 YAGEO R215...
  • Page 39 Specification Part Number Vender CORE FERRITE BEAD ARRAY 1206 5062128504 MAGLAYERS RP06 MLB-3216-0030M4-N2 30-OHM 0.35A RESISTOR NETWORK SMD 5160310900 YAGEO RP07 YCN164101JR 1/16W 100.00 J X4 RESISTOR NETWORK SMD 5160310900 YAGEO RP08 YCN164101JR 1/16W 100.00 J X4 RESISTOR NETWORK SMD 5160310900 YAGEO RP09...
  • Page 40 Specification Part Number Vender Chip capacitor SMD Y5V DC 16V 2.20uFZ T 0805 5230007791 PHILIPS CT17 SMD Electrolytic capacitor 16V 10.00UFM T 4x5 5218007891 TEAPO CT18 Chip capacitor SMD Y5V 25V 0.10UFZ T 0603 5230005491 PHILIPS CT19 SMD Electrolytic capacitor 16V 4.70UFM T 4.0x5.5 5218014791 TEAPO CT20...
  • Page 41 Specification Part Number Vender 5134300009 YAGEO RT06 Chip resistor SMD 0603 1/16W 0.00 J T 5134300009 YAGEO RT08 Chip resistor SMD 0603 1/16W 0.00 J T 5134382209 YAGEO RT11 Chip resistor SMD 0603 1/16W 8.20KJ T 5134310009 YAGEO RT12 Chip resistor SMD 0603 1/16W 10.00 J T 5134315109 YAGEO RT13...
  • Page 42 12.3 Key PCB (PWB-0475-1) Specification Part Number Vender WIRE ,TIN COATED SOFT COPPER 0.0175 6119210605 J001 WIRE ,TIN COATED SOFT COPPER 0.0175 6119210605 J002 BASE & PIN S10B-PH-K 5056416038 P002 SWITCH ,TACT SPST SKHHAM2520-TT 5054512951 S601 DC12V50MA F=160GF H=5MM SWITCH ,TACT SPST SKHHAM2520-TT 5054512951 S602 DC12V50MA F=160GF H=5MM...
  • Page 43 W661 Speaker SPK-2225(30100PC13B4W-A1) 5055122500 W662 Speaker SPK-2225(30100PC13B4W-A1) 5071000510 JA01 QUICK TIE,PVC 2.5X100MM 5000100038 Remote Control Rev:1.0 CR36CJ0002 ( Tatung ) Forward RT01 5000100050 Remote Control RM-L1701 ( Neutral ) 5061370313 HIPRO AC/DC ADAPTOR , 12V 5A ( 60W ) ADP8...
  • Page 44 14. Mechanical Parts List Parts No. Description MESH SPEAKER 5642382100 FRONT COVER 5642288700 IR LENS 5642382200 LCD MBRACKET 5642722700 RIGHT D-SUB COVER 5642420000 LEFT YPBPR COVER 5642419900 MPCB SHIELD 5646250600 MPCBSHIELD-2 5646250700 5642847100 FUNCTION KEY BACK COVER 5642288800 TUNNER COVER 5642420100 HAND BACK 5642901100...
  • Page 45 P/N : 5030150001...
  • Page 46 13. Mechanical Disassembly...
  • Page 47 7. Block Diagram...
  • Page 48 8.Troubleshooting Flow Chart (1) Power start NG No picture Appear Is the Voltage of Does the LED Replace F001 L046 12V ? light up? Is the Voltage of Is LED display Replace I014 & D017 L045 5V ? Amber ? Is it entering into Reset the MCU(I012) by Is the Voltage of...
  • Page 49 (2) Frame slant The Ver. or Hor. Sync. does not hold in any source Are the cables Are the output of I019 Connect the cables Are the cables attached attached firmly at the TP6760 (SHCLK, firmly with the at firmly at P018 & PDE) LCD Panel PVSync,PHSync,...
  • Page 50 (3) Picture abnormal Steps to clean EEPROM Picture abnormal 1. Press Power key to turn off the LCD-TV. 2. Press Power key quickly to turn on the LCD-TV and then press the Aspect Ratio key Does the picture promptly. recover normal after pressing key ? 3.

  • Page 51: Electronic Circuit Description

    9.Electronic Circuit Description 9.1 Main Board Circuit (1) Power Refer to circuit diagram sheet 7 of PWB-0452-03. The DC +12V output of AC adaptor is applied to the LCD-TV through P020. This supply is fed directly to P017#1、2 (Connector to Inverter). It also provide +9V for I009 (Audio Pre-Amp PT2314) and IT03 (MTS Decoder : TDA9850) through two regulators ( RC1117) I011 and I014 respectively.

  • Page 52: Circuit Diagram

    the I004( EEPROM) and the EDID data is written into the EEPROM in the factory during production. (3) AV Signal Refer to the page 8 in circuit diagram of PWB-0452-03. V17AFTWcan process 4 different Video signals. Includes Composite Video ( CVBS)、Separate Video(S-Video) and Component Video(YUV). Component Video also has Y Cb/Cr and Y Pb/Pr two types.
  • Page 53 Signal enter from P008 / P010 / P011、P012、P014. Enter Pin# A21 / Pin#A12, A22 / Pin# A23,A33,A43. In addition to Audio MPX signal, the process type is the same with TV signal. (C)CV( Y / Pb / Pr ): Signal enter from P011, P012, P014, Then enter Pin#43, 48, 54 of AD9883-110 pass by the matching impedance resister and capacitance.
  • Page 54 Refer to circuit diagrams Sheet 6 of PWB-0452. The signals of panel interface are all from I019 to the LCD Panel. The signal FPVCC (Pin#96 of I019) and MMTB3904( Q003) control the +5V power to the LCD Panel. The signals FPBACK and DVD0( Pin#95、62 of I019) are used for the control of backlight’s On/Off state and Panel luminance.
  • Page 55 +3.3V_AP +3.3V_AP AR[0..7] L001 L002 1M2012 VS_VGA R001 300 RP01 I002 C002 C001 1M2012 R013 0.082U 0.0082U R002 300 HS_VGA R225 75 SCL_IN SCL_A C029 C026 C028 R004 0.1U R003 MLB-3216-30 C318 2.2K CLAMP_VGA RC1117 R015 R005 RP02 SOT_223 SDA_IN R226 SDA_A G84P...
  • Page 56 +3.3V L010 1M2012 +3.3V_AP_B R034 100 +3.3V_AP_B L011 L012 1M2012 C045 R036 C044 BRV[0..7] 0.082U 2.2K 0.0082U R035 100 I007 RP07 1M2012 R052 BRV0 BRV1 G84D_B BRV2 C074 C322 C323 R037 0 CLAMP_VGA BRV3 0.1U C046 C047 C071 C073 0.1U 1000P C048 0.1U...
  • Page 57 +12V C080 R060 2.4K L020 TAUDIO_R TV_R TAUDIO_R 2.2U TAUDIO_R I011 1H4516 C081 TAUDIO_L TAUDIO_L TAUDIO_L TV_L GND-A C115 R079 C116 A-GND D006 2.2U R061 2.4K BAV99 NC R063 R062 R064 R065 C117 2.2K 2.2K 2.2K 2.2K 0.1U MUTE_S MUTE_S RC1117 R080 SOT_223...
  • Page 58 AV1_TV_COM AV1_TV_COM GND-A1 AV1_RCA_COM AV1_RCA_COM AV1_S_LUM AV1_S_LUM D010 R087 BAV99 4.7k AV1_S_CHR AV1_S_CHR Q001 AV-CVBS Y_IN Y_IN RCA JACK P008 L023 1M2012 AV1_RCA_COM ( FROM PAGE 11) Cb_IN Cb_IN L073 1M2012 P009 RCA JACK 3904 C120 C341 R089 Cr_IN R249 75 D031 Cr_IN GND-A1...
  • Page 59 C126 0.1u I012 W78E62BP EA/VP EA/VP P0.0 MSCL MSCL P0.1 AD[0..7] MSDA UCLK MSDA P0.2 P0.3 cable cable P0.4 UCLK2 P0.5 P0.6 P0.7 RESET PWR_Y P2.0 PWR_R R092 R093 P2.1 /INT0 MUTE_S INT0 P2.2 MUTE_S IR_DAT PW_TU INT1 P2.3 MUTE_OUT MUTE_OUT P2.4 cable...
  • Page 60 INVERTER I/F P+12V LP01 LP02 DVD0 B1BLU[0..7] A1BLU[0..7] DVD0 B1BLU7 B2BLU7 A1BLU7 A2BLU7 C141 B1BLU6 B2BLU6 A1BLU6 A2BLU6 FPBACK FPBACK 100U B1BLU5 B2BLU5 A1BLU5 A2BLU5 B1BLU4 B2BLU4 A1BLU4 A2BLU4 P017 GNDP FPVCC FPVCC P+12V P+12V INV_GND L077 2012 SHFCLK SHFCLK C142 C146 INV_GND...
  • Page 61 I014 +12V LM2576 /LM2596 L045 33UH_CHK-409 P020 POWER-JACK F001 L046 FUSE 1H4516 +12v 7A R106 12V-to-5V D016 R107 C193 C194 C196 TO-220 5-Pin 1N5822 C192 C195 470U 100U 0.1U 470U 0.1U D017 B340 R108 If use LM2596-5.0 then: R106 &R107 = 0,R108 +3.3V L048 +2.5V_VP...
  • Page 62 L050 +3.3V AV1_TV_COM 3V3B1 AV1_TV_COM L051 +3.3V AV1_RCA_COM AV1_RCA_COM I017 AV1_S_LUM 1M2012 R113 L052 C204 C205 C331 C332 C333 C334 AV1_S_LUM 1M2012 0.1U 0.1U 0.1U 0.1U 0.1U R117 AV1_S_CHR AV1_S_CHR C203 C218 C219 D036 0.1U GND-B1 MUTE_OUT MUTE_OUT RC1117 R114 3V3A1 Y_IN 1N4148_SMD...
  • Page 63 Chip Interface +2.5V_VP L055 +3.3V CVDD DVDD 1M2012 L056 1M2012 C262 C263 C264 C265 C266 C267 C268 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U +3.3V +2.5V_VP AVDD3 MVDD A1BLU0 MSDA L057 C269 C270 L058 1M2012 A1BLU1 0.1U C271 C272 A1BLU2 R171 0 0.1U 0.1U...
  • Page 64 Tuner Connector ANT1 ANTENNA LT01 +5VTuner UT01 CT02 CT01 0.1U 100U RT08 PT01 +12V MPU_SCL MPU_SDA GNDTi GNDTi GNDTi +5VTuner +12V GNDTi PWOFF_TU FM_R RT09 CT03 FM_R LT02 FM_R MPU_SDA FM_L FM_L 1M2012 RT10 FM_L Tuner_OUT QT01 GNDT CVBS 2SC1815 CVBS TVOUT_R GNDTi...
  • Page 65 OPTION TVIDEO TVIDEO I021 R213 100U V_OUT R193 Tuner_OUT TV_AMP TV_AMP C300 VIN1 VOUT1 R195 VSAG1 R194 0 R196 C302 T-VIDEO Q004 VIN2 VOUT2 V_OUT R197 C301 100U 4.7U GNDT R198 MJN2268 MMBT3904 R199 0 TVIDEO VIN1 VIDEO C298 C299 GNDT R200 0 R202...
  • Page 67 CAM350 V 5.0 : Wed Nov 6 18:36:34 2002 - (Untitled)
  • Page 68 CAM350 V 5.0 : Wed Nov 6 18:33:29 2002 - (Untitled)
  • Page 69 CAM350 V 5.0 : Wed Nov 6 18:41:35 2002 - (Untitled)
  • Page 70 CAM350 V 5.0 : Wed Nov 6 18:43:02 2002 - (Untitled)
  • Page 71 CAM350 V 5.0 : Wed Nov 6 18:39:10 2002 - (Untitled)
