To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200

Service Manual

For Parts or Service contact

Betson Enterprises at 1(800) 828-2048

(Rev 1.1)

Table of Contents

Need help?

Do you have a question about the NICKTOONS nitro and is the answer not in the manual?

Questions and answers

Summary of Contents for BMI Gaming NICKTOONS nitro

Page 1 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Service Manual For Parts or Service contact Betson Enterprises at 1(800) 828-2048 (Rev 1.1) © Raw Thrills 2008 All Rights Reserved...
Page 2: Safety Instructions
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 CAUTION: • The specifications of this product are subject to change without notice for reasons such as performance. • The content of this game, its main devices and design are protected under each federal law concerning patent, copyright and other intellectual properties.
Page 3: Main Cabinet
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 WARNING: HAZARD TO EPILEPTICS. A very small portion of the population has a condition that may cause them to experience epileptic seizures or have momentary loss of consciousness when viewing certain kinds of flashing lights or patterns that are present in our daily environment.
Page 4: Product Specifications
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PRODUCT SPECIFICATIONS OPERATING REQUIREMENTS ELECTRICAL POWER Domestic 120VAC @ 60 Hz, 5 amps Foreign 240VAC @ 50Hz, 2.5 amps TEMPERATURE 32° F to 100°F (0°C to 38°C) HUMIDITY Not to exceed 95% relative humidity.
Page 5 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 4. Open the top coin door and locate the key for the backdoor and the cashbox. 5. Locate hardware kit: [2] Marquee Support Brackets [2] Base Connect Boards [1] Seat Base Extension [4] ¼-20 x ½”...
Page 6 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Seat Assembly Procedure WARNING: The cabinet is top heavy. Install only on level surface. Use the leg levelers to make sure the cabinet and seat are stable. Do not push against plastic parts during movement.
Page 7 CAT5 grade. Networking Considerations Each Nicktoons Nitro game comes with a network cable. Optionally, a hub can be installed and located remotely to monitor network activity. Take care to protect exposed game wiring from general foot traffic around the game. Use a conduit or wire way to protect the cables as needed.
Page 8: Menu Navigation
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Vol + SETUP AND TEST MENU 0000000 Locate the Service Button Panel. The Service Button Panel is made up of four pushbuttons. Simply press the Service...
Page 9: Diagnostics Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Diagnostics Menu From the Main Menu, select Diagnostics and enter to view options Diagnostics Menu Diagnostics Switch Test DIP Switch Test Sound Test Monitor Test Lamp Test...
Page 10: Dip Switch Test
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 DIP Switch Test From the Diagnostics Menu select and enter DIP Switch Test. Verify correct DIP switch settings. Please refer to Networking Setup on page 7. Press the Service Button to return to Diagnostics Menu.
Page 11: Monitor Test
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Monitor Test From the Audio/Video Options menu, select and enter Color Bars & Purity. Verify correct color and purity for Red, Blue and Green screens Use the convergence screen to also verify linearity. See Appendix n.
Page 12: Watchdog Test
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Coin Meter Test From the Diagnostics Menu select and enter Coin Meter Test. Advance the meter once using by pressing Start. Press the Service or View Button to return to Diagnostics Menu.
Page 13: Reliability Test
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Link System Menu From the Diagnostics Menu, select Link System and enter. Reliability Test and Reset Link System Config. open in new menus. Status shows the Link Status and Show All Machine IDs displays the ID of each machine on its monitor.
Page 14: Game Audits
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Reset Link System Configuration Menu From the Utilities Menu, select Reset Link System Config and enter. This utility allows the communication between linked games to be re-established due to a possible fault other than hardware. Check all network related hardware (cables, router) and make sure that they are connected and then power cycle the games.
Page 15 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 General 1 Audits From the Audits Menu, select General 1 and enter to view general game statistics. Press the Service Button or choose Exit to return to Main Menu.
Page 16 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Course Audits From the Audits Menu, select Courses and enter to view individual information on each course. View how many times each course is selected, as well as its popularity by overall percentage. Press the Service Button or choose Exit to return to Main Menu.
Page 17 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Placings Audit From the Audits Menu, select Placings and enter to view individual count for each standing and percentage information. Use this information to determine game difficulty adjustments to properly reward players and maximize game earning performance.
Page 18 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Items Used Audit From the Audits Menu, select Items Used and enter to view individual count the number of times each item has been used, total number of items picked up, and total number of items used. Press the Service Button to return to Main Menu.
Page 19: Price Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Pricing Adjustment Menu From the Main Menu, select Pricing Adjustment and enter. The Adjustment Menu allows you to customize the game. Each variable will change an aspect of the basic game pricing or player free game reward. Optimizing these settings should result in continued high player interest and game earnings.
Page 20 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Money Unit Menu From the Pricing Menu, select Money Unit and enter. Select the currency that applies to the games location and press Start to select. Press Start to Select. Press Service to Exit.
Page 21 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Coin Per Bill Pulse Menu From the Pricing Menu, select Coin per Bill Pulse Menu and enter. Choose the equivalent coin value based on the bill acceptor currency type or settings.
Page 22 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Credit To Start Menu From the Pricing Menu, select Credit To Start Menu and enter. Choose the number of credits required to start one game. Press Start to Select. Press Service to Exit.
Page 23 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Max Credits Menu From the Pricing Menu, select Max Credit Menu and enter. Choose the number of maximum credits the game will post. Please note that the game will continue to accept and count additional coins with no additional credits added over the maximum number selected.
Page 24: System Adjustments Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Multiplay 1 Place Wins Free Race From the Pricing Menu, select Multiplay 1 Wins Free Race and enter. Select the amount of time in seconds given to the player to reach the first check point.
Page 25 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Attract Audio Menu From the System Adjustment Menu, select Attract Audio and enter. Select option to play game music during standby or attract mode. Press Start to Select. Press Service to Exit.
Page 26: Game Adjustments Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Automatic Volume Sync Menu From the System Adjustment Menu, select Automatic Volume Sync and enter. Select option to synchronize game volume adjustment across all linked or networked games. When active, volume for all linked games can be adjusted to the same level from any one of the games connected to the network.
Page 27 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Start Time Bonus Menu From the Game Adjustment Menu, select Start Bonus Time and enter. Select amount of time given at the start of the race to reach the first Checkpoint. Additional time is given at each Checkpoint. Press Start to Select.
Page 28 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Game Difficulty Menu From the Game Adjustment Menu, select Game Difficulty and enter. The default difficulty level is 5. Press Start to Select. Press Service to Exit.
Page 29 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Autopilot Available Menu From the Game Adjustment Menu, select Autopilot Available and enter. When active, this feature allows the game to run in autopilot mode after 10 seconds has elapsed without player input. This provides an opportunity for younger players to enjoy the game experience as well.
Page 30 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Bonus Stage Unlocked Menu From the Game Adjustment Menu, select Bonus Stage Unlocked and enter. The default setting for this menu is NO. Bonus Stage Unlocked?
Page 31: Utilities Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Utilities Menu From the Test Main Menu, select Utilities and enter. The Utilities Menu contains tools that the operator could use to manage game adjustments or reset key game and player score and statistic information. The option to perform a game factory restore can also be accessed.
Page 32 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Clear Credit Menu From the Utilities Menu, select Clear Credits and enter. Performing Clear Credit will delete any remaining credits posted. Press Start to Select. Press Service to Exit.
Page 33 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Clear High Scores Menu From the Utilities Menu, select Clear High Scores and enter. Performing Clear High Score will clear the all high score tables. Press Start to Select. Press Service to Exit.
Page 34 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Reset Link System Configuration Menu From the Utilities Menu, select Reset Link System Config and enter. This utility allows the communication between linked games to be re-established due to a possible fault other than hardware. Check all network related hardware (cables, router) and make sure that they are connected and then power cycle the games.
Page 35: Calibration Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Copy Audits and Log to Disk Menu From the Utilities Menu, select Factory Restore and enter. Performing Factory Restore will restore game adjustments back to its manufacturer recommended settings and clear all audit information. The game will need to be re-calibrated.
Page 36: Volume Menu
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Volume Menu From the Test Main Menu, select Volume and enter. This refers to the game volume while in play. Use the Volume Up/ Volume Down button on the service panel to adjust volume level. Press Start to Select. Press Service to Exit.
Page 37: Troubleshooting Guide
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Game will not power up Game not plugged in. Plug game into receptacle. Game not turned on. Turn ON main power switch Game fuse is blown Check game fuse.
Page 38: Parts List
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Parts List Part Pic Part Number Part Description Qty. Art – Button Panel NT2-ART-BUTPNLL Left Art – Button Panel NT2-ART-BUTPNLR Right Art – Left Cabinet NT2-ART-CABLEFT Side Art –...
Page 39 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. NT2-ART-MARQUEE Art – Marquee NT2-ART-SEATLFT Art – Seat Base Left NT2-ART-SEATLOW Art – Seat Base Back NT2-ART-SEATRGT Art – Seat Base Right NT2-ART-SEATUPP Art –...
Page 40 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. Art – Speedometer NT2-ART-SPEDPNL Panel Standard 18 Gauge 000-CBL-6PWR18G Powercord, 6’ Long NT2-CBL-ACPOWER Power Wire Harness NT2-CBL-COINDOR Coin Door Harness...
Page 41 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. Cabinet - Wood NT2-CCC-MARQUEE Marquee NT2-CCC-SEATBAS Cabinet - Seat Base Corsair Flash Voyager, 4GB Flash 000-ELE-4GFLASH Drive Corsair Part # CMFUSB2.0-4GB...
Page 42 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. Monitor Glass NT2-GLS-MONGLAS 28 7/16” x 22 1/4” 5V Meter 000-HAP-5VMETER Happ Part # 42-0756-07 Coin Door w/ .25 x 2 label and two .25...
Page 43 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. 270 Degree Steering 000-HAP-STEER5K Mech. w/ 5K Pot Steering Wheel 000-HAP-STERWHL Happ Part # 50-2846-00 Jumbo Round Yellow NT2-HAP-YBUTNLF Button Printed “View”...
Page 44: Part Description
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. 24” Lamp Fixture 000-LMS-24FLORE Duray Part # EE1120 NT2-MLS-STRBRAC Steering Brace Button Counter NT2-MLS-CONTBRK Bracket NT2-MLS-CPUHOLD Computer Hold Down...
Page 45 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. NT2-MLS-PWRSWT Power Switch Plate NT2-MLS-SEATBAK Seat Speaker Grill Coin Door Side Trim NT2-MLS-SIDETRM 19.44” NT2-MLS-SMOUNTU Steering Mount Upper NT2-MLS-SPKGRIL...
Page 46 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. NT2-PCB-SUBAMP CGC Audio Amp Raw Thrills I/O PCB NT2-PCB-IOPCB1 Raw Thrills Part # 2-1-12-00-00-002 Raw Thrills Reset NT2-PCB-RESET Raw Thrills Part #...
Page 47 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Part Pic Part Number Part Description Qty. Speaker, 4 ¾”, 8 Ohm 000-SPK-475IN8O Challenge Electronics Part # 5060CESH-1 Subwoofer, 8” 8 Ohm 000-SPK-8IN8OHM Betson Part # 43-3009-8 Alcoswitch, 16A, Double Pole –...
Page 48: Appendix A: Flash Drive Recovery
Appendix A: Flash Drive Recovery NOTICE: Nicktoons Nitro is shipped with a recovery compact disk. Flash drives have been known to occasionally fail for many reasons. Follow the procedure below to restore data on the flash drive if a disk failure should occur. Use extreme care when performing the following procedure and avoid rough handling of pc or CD.
Page 49: Appendix B: Power Management Setting (Bios)
Appendix B: Power Management Setting (BIOS) NOTE: Nicktoons Nitro is shipped with the correct BIOS settings. Any changes made to the BIOS other than what is described below may adversely affect game functionality This BIOS setting allows the PC to automatically power up when AC power is detected. This eliminates the need to manually turn the PC ON after a power disruption.
Page 50: Appendix C: Basic Display Adjustments
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Appendix C: Basic Display Adjustments WARNING: Extremely high voltage is present on the monitor assembly. The monitor does not contain any user serviceable parts. Do not attempt to service the monitor.
Page 51: Wiring Schematics
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Wiring Schematics Nicktoons Nitro • Copyright 2008 • Raw Thrills • All rights reserved...
