Please read the manual carefully before you start assembling
Please inspect box contents to ensure you have received all components
Note: the black circular plastic tops in between the shelves are used only for packaging purposes.
They are NOT NEEDED. Please discard.
D
4-Shelf Corner Storage
Unit
40
C
A
5
Locate the desired position of the bottom shelf (A). Ensure that it is no more
than 6 in. from the floor.
Place two tapered sleeves (B) into the appropriate groove on each pole
assembly. Make sure the "UP" arrow is facing up.
Place the shelf (A) on its side and slide each pole assembly with tapered locks
through the bottom of the shelf (A) until snug. Make sure that the shelf corner
cylinders are positioned over the slip sleeves.
After all pole assemblies are in place, position the unit in the upright position.
Push down on each corner of the shelf (A), ensuring the shelf (A) is in a fully
locked position.
Note: the tapered sleeves must be at the same height for each pole
to ensure the shelf sit on the sleeves levelly.
Between 9 a.m and 4 p.m(Central Time) Monday to Friday
Item #SL-CSUS-114C
Model #1001663098
5
black plastic tops
B
UPSIDE (level side)
HOMEDEPOT.COM
Please contact 1 (855) 439-4663 for further assistance.
